reset LAND ROVER FREELANDER 2001 Workshop Manual

BRAKES
REPAIRS 70-13
Switch - stop light
$% 70.35.42
Remove
1.Disconnect brake light switch multiplug.
2.Release bayonet fitting on brake light switch
and remove switch.
Refit
1.Position switch and secure bayonet fitting.
2.Connect brake light switch multiplug.
3.Depress and hold brake pedal.
4.Reset switch by pulling plunger fully out.
5.Release brake pedal slowly to set switch
adjustment.
Sensor - brake pedal position
$% 70.35.44
Remove
1.Release bayonet fitting on brake light switch
and remove switch.
2.Release sensor from mounting bracket.
3.Disconnect sensor multiplug and remove
sensor.
4.Remove sensor mounting from bracket.
Refit
1.Position sensor to mounting bracket and
connect multiplug.
2.Position switch and secure bayonet fitting.
3.Hold brake pedal depressed and push sensor
fully into bracket, release pedal slowly to set
sensor position.

DOORS
REPAIRS 76-1-33
Handle - exterior - tail door
$% 76.58.05
Remove
1.Remove tail door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
tail door.
2.Raise glass by clicking latch.
3.Remove 3 nuts securing tail door handle to tail
door.
4.Release handle from tail door.
5.Disconnect 2 Lucars from number plate lamp.
6.Disconnect multiplug and remove handle from
door.7.Collect gasket.
8.Remove nut from lock barrel.
9.Remove lock barrel from handle.
Refit
1.Fit lock barrel to handle.
2.Fit gasket to handle.
3.Position handle and connect Lucars and
multiplug.
4.Fit handle to door and tighten nuts to 5 Nm (3.5
lbf.ft).
5.Fit tail door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
tail door.
6.Reset latch to lower glass.
7.Close door.
