Lexus CT200h 2011 Owner's Manual (in English)

5
581
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Interior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure
Once
Con-
tinu-
ous
(Flashes)
• An attempt was
made to lock
the doors using
the smart entry
& start system
while the elec-
tronic key was
still inside the
vehicle.
• An attempt was
made to lock
either front
door by open-
ing a door and
putting the
inside lock but-
ton into the
lock position,
then closing
the door by
pulling on the
outside door
handle with the
electronic key
still inside the
vehicle.
Retrieve the
electronic key
from the vehicle
and lock the
doors again.

582
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Interior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure
Once
(Flashes)
•When the
doors were
unlocked with
the mechanical
key and then
the “POWER”
switch was
pressed, the
electronic key
could not be
detected in the
vehicle.
• The electronic
key could not
be detected in
the vehicle
even after the
“POWER”
switch was
pressed two
consecutive
times.
Touch the elec-
tronic key to the
“POWER”
switch while
depressing the
brake pedal.
Once
(Flashes)
An attempt was
made to start the
hybrid system
with the shift
position in N.Shift the shift
position to P and
start the hybrid
system.

5
583
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Interior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure

Power was
turned off due to
the automatic
power off func-
tion.
Next time when
starting the
hybrid system,
increase the
engine speed
slightly and
maintain that
level for approx-
imately 5 min-
utes to recharge
the 12-volt bat-
tery.
Once
The electronic
key has a low
battery.Replace the
electronic key
battery. (P.
515)

584
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Interior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure
Once
(Flashes)
The driver’s
door was opened
and closed with
the “POWER”
switch turned
off and then the
“POWER”
switch was put
in ACCES-
SORY mode
twice without
the hybrid sys-
tem being
started.
Press the
“POWER”
switch while
depressing the
brake pedal.
During a hybrid
system starting
procedure in the
event that the
electronic key
was not func-
tioning properly
(P. 617), the
“POWER”
switch was
touched with the
electronic key.
Press the
“POWER”
switch within 10
seconds of the
buzzer sound-
ing.

5
585
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Warning message in radar cruise mode
In the following cases, the warning message may not be displayed even if
vehicle-to-vehicle distance decreases:
When your vehicle and the vehicle ahead are traveling at the same speed
or the vehicle ahead is traveling more quickly than your vehicle
When the vehicle ahead is traveling at a very low speed
Immediately after cruise control speed is set
At the instant the accelerator pedal is depressed

586
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If you have a flat tire (vehicles with a spare tire)
Remove the flat tire and replace it with the spare tire provided.
Before jacking up the vehicle
Stop the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift position to P.
Stop the hybrid system.
Turn on the emergency flashers.
Location of the spare tire, jack and tools
Center auxil-
iary
Jack Spare Jack han- Wheel
nut
Towing eye-

5
587
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Taking out the jack
Remove the center deck board.
Remove the center auxiliary
box.
Take out the jack.
For loosening
For tightening
STEP1
STEP2
STEP3

588
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Taking out the spare tire
Remove the center deck board and center auxiliary box.
(See “Taking out the jack” for details.)
Loosen the center fastener that
secures the spare tire.
STEP1
STEP2

5
589
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Replacing a flat tire
Chock the tires.
For vehicles with 15 inch
wheels, remove the wheel orna-
ment using the wrench.
To protect the wheel ornament,
place a rag between the wrench
and the wheel ornament.
Slightly loosen the wheel nuts
(one turn).
STEP1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the front left-hand side tire
STEP2
STEP3

590
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)Turn the tire jack portion “A”
by hand until the notch of the
jack is in contact with the jack
point.
The jack point guides are
located under the rocker panel.
They indicate the jack point
positions.
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and
the tire.
When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.
STEP4
STEP5
STEP6
