5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Connect the jumper cables according to the following proce-
dure:
Connect a positive jumper cable clamp to the exclusive jump
starting terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the
positive (+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery ter-
minal on the second vehicle.
Connect the clamp at the other end of the negative cable to a
solid, stationary, unpainted metallic point away from the
STEP3

622
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors of your vehicle with the
“POWER” switch off.
Maintain the engine speed of the second vehicle and start
the hybrid system of your vehicle by turning the
“POWER” switch to ON mode.
Make sure the “READY” indicator light comes on. If the
indicator light does not come on, contact any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
Once the hybrid system has started, remove the jumper
cables in the exact reverse order from which they were
connected.
To install the engine cover, conduct the removal proce-
dure in reverse. After installing, check that the fixed pins
are inserted securely.
Once the hybrid system starts, have the vehicle inspected at any
th i d L d l i th d l lifi dSTEP4
STEP5
STEP6
STEP7
STEP8
STEP9

5
623
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is
off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
When the 12-volt battery is removed or discharged
The hybrid system may not start. (P. 499)
If the 12-volt battery discharges while the shift position is in P, it may not
be possible to shift the shift position to other positions. In this case, the
vehicle cannot be towed without lifting both front wheels because the
front wheels will be locked. (P. 551)
When the 12-volt battery is reconnected, start the hybrid system and
confirm that the shift position can be changed to each position using the
shift position indicator.
Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time,
the 12-volt battery may discharge, and the hybrid system may be unable to
start. (The 12-volt battery recharges automatically while the hybrid system
is operating.)

624
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
CAUTION
Avoiding 12-volt battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flam-
mable gas that may be emitted from the 12-volt battery:
Make sure each jumper cable is connected to the correct terminal and that
it is not unintentionally in contact with any other than the intended termi-
nal.
Do not allow the other end of the jumper cable connected to the “+” termi-
nal to come into contact with any other parts or metal surfaces in the area,
such as brackets or unpainted metal.
Do not allow the + and - clamps of the jumper cables to come into contact
with each other.
Do not smoke, use matches, cigarette lighters or allow open flame near the
12-volt battery.

5
625
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
CAUTION
12-volt battery precautions
The 12-volt battery contains poisonous and corrosive acidic electrolyte,
while related parts contain lead and lead compounds. Observe the following
precautions when handling the 12-volt battery:
When working with the 12-volt battery, always wear safety glasses and
take care not to allow any battery fluids (acid) to come into contact with
skin, clothing or the vehicle body.
Do not lean over the 12-volt battery.
In the event that battery fluid comes into contact with the skin or eyes,
immediately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention
can be received.
Always wash your hands after handling the battery support, terminals, and
other battery-related parts.
Do not allow children near the 12-volt battery.
After recharging the 12-volt battery
Have the 12-volt battery inspected at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
If the 12-volt battery is deteriorating, continued use may cause the 12-volt
battery to emit a malodorous gas, which may be detrimental to the health of
passengers.
When replacing the 12-volt battery
P. 5 0 1

626
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
NOTICE
When handling jumper cables
When connecting the jumper cables, ensure that they do not become entan-
gled in the cooling fans or belt.
To prevent damaging the vehicle
The exclusive jump starting terminal is to be used when charging the 12-
volt battery from another vehicle in an emergency. It cannot be used to jump
start another vehicle.

5
627
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
If your vehicle overheats
Correction procedures
If the high coolant temperature warning light comes on or
flashes
Stop the vehicle in a safe place and turn off the air condi-
tioning system.
Check to see if steam is coming out from the engine area.
If you see steam:
Stop the hybrid system. Carefully lift the hood after the
steam subsides and then restart the hybrid system.
If you do not see steam:
Leave the hybrid system operating and carefully lift the
hood.
Check to see if the cooling fans are operating.
If the fans are operating:
Wait until the high coolant temperature warning light goes
off and then stop the hybrid system.
If the fans are not operating:
Stop the hybrid system immediately and call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
The following may indicate that your vehicle is overheating:
The high coolant temperature warning light comes on or
flashes:
The engine may be overheating.
“HYBRID SYSTEM OVERHEAT” is shown on the multi-
information display:
STEP1
STEP2
STEP3

628
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)After the hybrid system has
cooled down sufficiently, check
the engine coolant level and
inspect the cooling system for
leaks.
If the engine compartment
cover needs to be removed: P.
486
Add engine coolant if neces-
sary.
Water can be used in an emer-
gency if engine coolant is
unavailable. (P. 645)
Have the vehicle inspected at the nearest authorized Lexus dealer
or repairer, or another duly qualified and equipped professional as
soon as possible.
STEP4
STEP5

5
629
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)If “HYBRID SYSTEM OVERHEAT” is shown on the multi-
information display
Stop the vehicle in a safe place and turn off the air condi-
tioning system.
Leave the hybrid system operating and carefully lift the
hood.
Check if the cooling fans are operating.
If the fans are operating:
Wait until the “HYBRID SYSTEM OVERHEAT” message
disappears and then stop the hybrid system.
If the message does not disappear, call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
If the fans are not operating:
Stop the hybrid system immediately and call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
After the hybrid system has
cooled down, check the power
control unit coolant level and
inspect the cooling system for
leaks.
If the engine compartment
cover needs to be removed: P.
486
STEP1
STEP2
STEP3
STEP4

630
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)Add power control unit coolant
if necessary.
Water can be used in an emer-
gency if power control unit
coolant is unavailable. (P.
645)
Have the vehicle inspected at the nearest authorized Lexus dealer
or repairer, or another duly qualified and equipped professional as
soon as possible.
STEP5
Overheating
The following symptoms may occur when your vehicle is overheating:
Hybrid system output decreases.
Steam comes out from under the hood.
