Lexus CT200h 2012 Owner's Manual (in English)

131
1
Before driving
CT200h_OM_OM76067E_(EE)
1-6. Refueling
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle
Turn the “POWER” switch off and close all the doors and
windows.
Confirm the type of fuel. (P. 132)
Opening the fuel tank cap
Press the opener to open the
fuel filler door.
Turn the fuel tank cap slowly
to open.
Hang the fuel tank cap on the
back of the fuel filler door.
STEP1
STEP2
STEP3

132
1-6. Refueling
CT200h_OM_OM76067E_(EE)
Closing the fuel tank cap
After refueling, turn the fuel
tank cap until you hear a click.
Once the cap is released, it will
turn slightly in the opposite
direction.
When the fuel filler door cannot be opened by pressing the inside switch
Fuel types
EU area:
Unleaded gasoline conforming to European standard EN228, Research
Octane Number of 95 or higher
Except EU area:
Unleaded gasoline, Research Octane Number of 95 or higher
Fuel tank capacity
Approximately 45 L (11.9 gal., 9.9 lmp. gal.)
Use of ethanol blended gasoline in a gasoline engine
Lexus allows the use of ethanol blended gasoline where the ethanol content
is up to 10%. Make sure that the ethanol blended gasoline to be used has a
Research Octane Number that follows the above.
Remove the cover inside the luggage
compartment and pull the lever.

133
1-6. Refueling
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do
so may result in death or serious injury.
After exiting the vehicle and before opening the fuel door, touch an
unpainted metal surface to discharge any static electricity. It is important
to discharge static electricity before refueling because sparks resulting
from static electricity can cause fuel vapors to ignite while refueling.
Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened.
Wait until the sound cannot be heard before fully removing the cap. In hot
weather, pressurized fuel may spray out of the filler neck and cause injury.
Do not allow anyone that has not discharged static electricity from their
body to come close to an open fuel tank.
Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.
Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible igni-
tion hazard.

134
1-6. Refueling
CT200h_OM_OM76067E_(EE)
CAUTION
When refueling
Observe the following precautions to prevent fuel overflowing from the fuel
tank:
Securely insert the fuel nozzle into the fuel filler neck.
Stop filling the tank after the fuel nozzle automatically clicks off.
Do not top off the fuel tank.
When replacing the fuel cap
Do not use anything but a genuine Lexus fuel tank cap designed for your
vehicle. Doing so may cause a fire or other incident which may result in
death or serious injury.
NOTICE
Refueling
Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the emission control sys-
tem to operate abnormally or damaging fuel system components or the vehi-
cle’s painted surface.

135
1
Before driving
CT200h_OM_OM76067E_(EE)
1-7. Theft deterrent system
Immobilizer system
System maintenance
The vehicle has a maintenance-free type immobilizer system.
Conditions affecting operation
Depending on the surrounding environment and conditions, the immobilizer
system may not operate properly. This may prevent the hybrid system from
starting. (P. 8 6 )
The vehicle’s keys have built-in transponder chips that prevent the
hybrid system from starting if a key has not been previously registered
in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
The indicator light flashes
after the “POWER” switch
has been turned off to indi-
cate that the system is operat-
ing.
The indicator light stops
flashing after the “POWER”
switch has been turned to
ACCESSORY or ON mode

136
1-7. Theft deterrent system
CT200h_OM_OM76067E_(EE)
Certifications for the immobilizer system

137
1-7. Theft deterrent system
1
Before driving
CT200h_OM_OM76067E_(EE)

138
1-7. Theft deterrent system
CT200h_OM_OM76067E_(EE)

139
1-7. Theft deterrent system
1
Before driving
CT200h_OM_OM76067E_(EE)
NOTICE
To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

140
1-7. Theft deterrent system
CT200h_OM_OM76067E_(EE)
Double locking system
Setting the double locking system
Turn the “POWER” switch off, have all the passengers exit the
vehicle and ensure that all the doors are closed.
Using the entry function:
Touch the sensor area on the outside door handle twice within 5
seconds.
Using the wireless remote control:
Press
twice within 5 seconds.
: If equipped
Unauthorized access to the vehicle is prevented by disabling the door
unlocking function from both the interior and exterior of the vehicle.
Vehicles employing this sys-
tem have labels on the win-
dow glass of both front
doors.
