Lexus CT200h 2012 Owner's Manual (in English)

101
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
Do not fold the seatbacks down while driving.
Stop the vehicle on level ground, set the parking brake and shift the shift
position to P.
Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
Do not allow children to enter the luggage compartment.
When returning the rear seatback to the upright position
Do not put your hand on the seat belt guide.
Doing so may cause you to trap your hand between the guide and the pillar,
causing an injury.
After returning the rear seatback to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
Check that the seat belts are not twisted or caught in the seatback.
Make sure that the seatback is securely
locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked,
the red marking will be visible behind
the seatback lock release lever. Make
sure that the red marking is not visible.

102
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
Driving position memory
: If equipped
Your preferred driving position (the position of the driver’s seat and
outside rear view mirrors) can be memorized and recalled with the
touch of a button. It is also possible to set this function to activate
automatically when the doors are unlocked.
Three different driving positions can be entered into memory.
Entering a position to memory
Turn the “POWER” switch to ON mode.
Adjust the driver’s seat and outside rear view mirrors to
the desired positions.
While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button 1, 2 or 3
until the signal beeps.
If the selected button has
already been preset, the pre-
viously recorded position
will be overwritten.
Recalling the memorized position
Turn the “POWER” switch to ON mode.
Press button 1, 2 or 3 to
recall the desired position.
STEP1
STEP2
STEP3
STEP1
STEP2

103
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
Linking driving position memory with door unlock operation
(driver’s seat only)
Record your driving position to button 1, 2 or 3 before performing
the following:
Carry only the key (including the card key) to which you want to
link the driving position. If 2 or more keys are in the vehicle, the
driving position cannot be linked properly.
Close the driver’s door and turn the “POWER” switch to
OFF mode.
Press the desired button (1, 2 or
3) to recall the position. Then,
while keep pressing the button,
press the driver’s door lock
switches (either lock or unlock)
until the signal beeps.
The driving position is recalled
when the driver’s door is
unlocked using the entry func-
tion or wireless remote control
and the driver’s door is opened.
To prevent unintended triggering of the alarm, open and close a
door once after a driving position has been recorded. (If a door is
not opened within 30 seconds after door lock switch is pressed, the
doors will be locked again and the alarm will automatically be set.)
In case that the alarm is triggered, immediately stop the alarm.
(P. 143)
STEP1
STEP2

104
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
Operating the driving position memory after turning the “POWER” switch
off
Memorized positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again, even after
turning the “POWER” switch off.
Canceling the linked door unlock operation
Turn the “POWER” switch to ON mode and close the driver’s door.
While pressing the “SET” button, press the driver’s door lock
switches (either lock or unlock) until the signal beeps.
Stopping seat position operation part-way through
Perform any of the following operations:
Press the “SET” button.
Press button 1, 2 or 3.
Adjust the seat using the switches (only cancels seat position recall).
Correct seat position
When the seat is in the most forward or most backward position, and the
seat is being moved in those directions, the system may not correctly recog-
nize the current position and the memorized position will not be correctly
recalled.
CAUTION
Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear pas-
senger or squeeze your body against the steering wheel.
STEP1
STEP2

105
1
1-4. Adjustable components (seats, mirrors, steering wheel)
Before driving
CT200h_OM_OM76067E_(EE)
Head restraints
Head restraints are provided for all seats.
Front seats
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Rear center seat
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Rear outboard seats
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Lock release
button
Lock release but-
Lock release but-

106
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
Removing the head restraints
Installing the head restraints
Adjusting the height of the head restraints (front seats)
Adjusting the rear seat head restraint
Always raise the head restraint one level from the stowed position when
using.
Pull the head restraint up while pressing
the lock release button.
Lock
release
button
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock
release
button
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

107
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
Use the head restraints designed for each respective seat.
Adjust the head restraints to the correct position at all times.
After adjusting the head restraints, push down on them and make sure
they are locked in position.
Do not drive with the head restraints removed.

108
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
Seat belts
Make sure that all occupants are wearing their seat belts before driving
the vehicle.
Correct use of the seat belts
Extend the shoulder belt so
that it comes fully over the
shoulder, but does not
come into contact with the
neck or slide off the shoul-
der.
Position the lap belt as low
as possible over the hips.
Adjust the position of the
seatback. Sit up straight
and well back in the seat.
Do not twist the seat belt.
Fastening and releasing the seat belt
To fasten the seat belt,
push the plate into the
buckle until a click sound
is heard.
To release the seat belt,
press the release button.
Rl b tt

109
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
Seat belt pretensioners (front seats)
The pretensioner helps the seat
belt to quickly restrain the
occupant by retracting the seat
belt when the vehicle is sub-
jected to certain types of severe
frontal collision and severe side
collision.
The pretensioner may not acti-
vate in the event of a minor
frontal impact, a minor side
impact, a rear impact or a vehi-
cle rollover.
Adjusting the seat belt shoulder anchor height (front seats)
Push the seat belt shoulder
anchor down while press-
ing the release button.
Push the seat belt shoulder
anchor up.
Move the height adjuster up
and down as needed until you
hear a click.

110
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
Pre-crash seat belts (front seats of vehicles with pre-crash safety
system)
If the system determines that a collision is unavoidable, the front
seat belts will retract before the collision.(P. 299)
After using the rear center seat belt
Store the buckle into the stor-
age location in the seat cushion.
