Lexus CT200h 2012 Owner's Manual (in English)

429
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Setting a cellular phone
Registering a cellular phone in the hands-free phone system allows the
system to function. The following function can be used for registered
cellular phones:
Functions and operation procedures
To enter menu for each function, follow the steps below.
Press the off-hook switch and select “Setup” using
.
Select “Phone Setup” using .
Select one of the following items using :
Registering a cellular phone
“Pair Phone”
Selecting a cellular phone to be used
“Select Phone”
Changing the registered name of a cellular phone
“Change Name”
Listing the registered cellular phones
“List Phones”
Changing the passkey
“Set Passkey”
Deleting a registered cellular phone
STEP1
STEP2
STEP3

430
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Registering a cellular phone
Select “Pair Phone” using , and perform the procedure for
registering a cellular phone. (P. 420)
Selecting a cellular phone to be used
Select “Select Phone” using .
Select the cellular phone to be used using .
Changing the registered name of a cellular phone
Select “Change Name” using .
Select the desired cellular phone name to be changed using
.
Select “Record Name” using , and say the new
name after the beep.
The name to be registered will be repeated aloud.
Select “Confirm” using .
STEP1
STEP2
STEP1
STEP2
STEP3
STEP4

431
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Listing the registered cellular phones
Select “List Phones” using . The list of registered cellular
phones will be read aloud.
When listing is complete, the system returns to “Phone Setup”.
Changing the passkey
Select “Set Passkey” using .
Select a 4 to 8-digit number using .
The number should be input 1 digit at a time.
When the entire number to be registered as a passkey has
been input, press again.
If the number to be registered has 8 digits, pressing of the knob is
not necessary.
STEP1
STEP2
STEP3

432
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Deleting a registered cellular phone
Select “Delete Phone” using .
Select the desired cellular phone to be deleted using
.
If the cellular phone to be deleted is paired as a Bluetooth
® audio
player, the registration of the audio player can be deleted at the
same time.
When “Del Audio?” is displayed, select “Yes” or “No”
using . (Bluetooth
® audio player P. 389)
The number of cellular phones that can be registered
Up to 6 cellular phones can be registered in the system.
STEP1
STEP2
STEP3

433
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Security and system setup
To enter the menu of each setting, follow the steps below.
Security setting items and operation procedures
Press the off-hook switch and select “Setup” using
.
Select “Security” using .
Select one of the following items using :
Setting or changing the PIN (Personal Identification Num-
ber)
“Set PIN”
Locking the phone book
“Phbk Lock”
STEP1
STEP2
STEP3

434
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
System setup items and operation procedures
Press the off-hook switch and select “Setup” using
.
Select “System Setup” using .
Select one of the following items using :
Setting voice guidance volume
“Guidance Vol”
Displaying the Bluetooth
® device address and name
“Device Name”
Initializing the system
“I iti li ”
STEP1
STEP2
STEP3

435
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Setting or changing the PIN
Setting a PIN
Select “Set PIN” using .
Enter a PIN using .
Input the code 1 digit at a time.
Changing the PIN
Select “Set PIN” using .
Enter the registered PIN using .
Enter a new PIN using .
Input the code 1 digit at a time.
Locking or unlocking the phone book
Select “Phbk Lock” or “Phbk Unlock” using .
Input a PIN by using and select “Confirm” using
.
Input the code 1 digit at a time.
STEP1
STEP2
STEP1
STEP2
STEP3
STEP1
STEP2

436
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Setting voice guidance volume
Select “Guidance Vol” using .
Change the voice guidance volume.
To decrease the volume: Turn counterclockwise.
To increase the volume: Turn clockwise.
Displaying the Bluetooth® device address and name
Select “Device Name” using .
Turn to display the Bluetooth
® device address and
name.
Select “Go Back” using to return to “System
Setup”.
STEP1
STEP2
STEP1
STEP2
STEP3

437
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Initializing the system
Select “Initialize” and then “Confirm” using .
Select “Confirm” again using .
Initialization
The following data in the system can be initialized:
• Phone book
• Outgoing and incoming call history
• Speed dials
• Registered cellular phone data
• Security code
• Registered Bluetooth
® enabled portable player data
• Passkeys for the cellular phones
• Passkey for the Bluetooth
® audio players
• Guidance volume
• Receiver volume
• Ring tone volume
Once the initialization has been completed, the data cannot be restored to
its original state.
When the phone book is locked
The following functions cannot be used:
Dialing by inputting a name
Speed dialing
Dialing a number stored in the call history memory
Using the phone book
STEP1
STEP2

438
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Using the phone book
To enter the menu of each setting, follow the steps below.
Press the off-hook switch and select “Phonebook” using
.
Select one of the following items using :
Adding a new phone number
“Add Entry”
Changing the registered name in the phone book
“Change Name”
Listing the registered data
“List Names”
Setting speed dials
“Speed Dial”
Deleting the registered data
“Delete Entry”
Deleting speed dials
“Del Spd Dial”
STEP1
STEP2
