3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Using the Bluetooth® audio system for the first time
Before using the Bluetooth
® audio system, it is necessary to regis-
ter a Bluetooth® enabled portable player in the system. Follow the
procedure below to register (pair) a portable player:
Press
(type A) or (type B) and select “BTA
MENU” using .
Press the talk switch or select “BTA Setup” using .
The introductory guidance and portable player name registration
instructions are heard.
Select “Pair Audio Player (Pair Audio)” using a voice com-
mand or .
Register a portable player name by either of the following
methods:
a. Select “Record Name” using , and say the name
to be registered.
b. Press the talk switch and say the name to be registered.
A voice guidance instruction to confirm the input is heard.STEP1
STEP2
STEP3
STEP4

398
3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Menu list of the Bluetooth® audio system
First menuSecond
menuThird menuOperation detail
“BTA
MENU”“BTA
Setup”
“Pair Audio”Registering a portable audio
player
“Select Audio”Selecting a portable audio
player to be used
“Change Name”Changing the registered
name of a portable player
“List Audios”Listing the registered porta-
ble players
“Set Passkey”Changing the passkey
“Delete Audio”Deleting a registered porta-
ble player
Operations that cannot be performed while driving
Operating the system with
Registering a portable player to the system
Changing the passkey
P. 4 0 6

403
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
Setting up a Bluetooth® enabled portable player
Registering a portable audio player in the Bluetooth® audio system
allows the system to function. The following functions can be used for
registered portable players:
Functions and operation procedures
To enter the menu for each function, follow the steps below.
Press
(type A) or (type B) and select “BTA
MENU” using or press the off-hook switch (P.
419) and select “Setup” using .
Select “BTA Setup” using .
Select one of the following items using :
Registering a portable player
“Pair Audio”
Selecting a portable player to be used
“Select Audio”
Changing the registered name of a portable player
“Change Name”STEP1
STEP2
STEP3

404
3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Registering a portable player
Select “Pair Audio” using , and perform the procedure for
registering a portable player. (P. 396)
Selecting a portable player to be used
Select “Select Audio” using .
Select the portable player to be used using .
Select “From Car” or “From Audio” using .
If “From Car” is selected, the portable player will be automati-
cally connected whenever:
The “POWER” switch is in ACCESSORY or ON mode.
Listing the registered portable players
“List Audios”
Changing the passkey
“Set Passkey”
Deleting a registered portable player
“Delete Audio”
STEP1
STEP2
STEP3

406
3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Listing the registered portable players
Select “List Audios” using . The list of registered portable
players will be read aloud.
When listing is complete, the system returns to “BTA Setup”.
Changing the passkey
Select “Set Passkey” using .
Select a 4 to 8-digit number using .
The number should be input 1 digit at a time.
When the entire number to be registered as a passkey has
been input, press again.
If the number to be registered has 8 digits, pressing of the knob is
not necessary.
STEP1
STEP2
STEP3

408
3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Bluetooth® audio system setup
System setup items and operation procedures
To enter the menu of each setting, follow the steps below.
Press the off-hook switch (P. 419) and select “Setup”
using .
Select “System Setup” using .
Select one of the following items using :
Setting voice guidance volume
“Guidance Vol” (P. 436)
Displaying the Bluetooth
® device address and name
“Device Name” (P. 436)
Initializing the system
“Initialize” (P. 437)
STEP1
STEP2
STEP3

409
3
Interior features
CT200h_OM_OM76067E_(EE)
3-4. Using the hands-free phone system (for cellular phones)
Hands-free system for cellular phone
The hands-free system is a function that allows you to use your cellu-
lar phone without touching it.
This system supports Bluetooth
® cellular phones. Bluetooth® is a
wireless data system that allows the cellular phone to wirelessly con-
nect to the hands-free system and make/receive calls.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
Hands-free system quick guide
Setting a cellular phone. (P. 420)
Adding an entry to the phonebook. (Up to 20 names can
be stored.) (P. 438)
Dialing by inputting a name. (P. 425)
Hands-free function list
TitlePage
Using the hands-free system
Using the hands-free phone system for
the first time
P. 4 2 0
STEP1
STEP2
STEP3

410
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
TitlePage
Making a phone call
Making a phone call
• Dialing by inputting a name
• Speed dialing
•Redial
• Call back
Receiving a phone call
• Answering the phone
• Refusing the call
Transferring a call
Using a call history memory
• Dialing
• Storing data in the phone book
• Deleting
P. 4 2 4
Setting a cellular phone
Functions and operation proceduresP. 4 2 9
Security and system setup
Security setting items and operation
procedure
System setup items and operation
procedure
P. 4 3 3

411
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
TitlePage
Using the phone book
Adding a new phone number
Changing the registered name in the
phone book
Listing the registered data
Setting speed dials
Deleting the registered data
Deleting speed dials
P. 4 3 8

412
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Conditions under which the system will not operate
If using a cellular phone that does not support Bluetooth®
If the cellular phone is switched off
If you are outside service range
If the cellular phone is not connected
If the cellular phone’s battery is low
If the cellular phone is behind the seat or in the glove box or console box
If metal is covering or touching the phone
Signal status
This display may not correspond exactly with the cellular phone itself.
When using the hands-free system
The audio system and voice guidance are muted when making a call.
If both parties speak at the same time, it may be difficult to hear.
If the incoming call volume is overly loud, an echo may be heard.
Try to face toward the microphone as much as possible when speaking.
In the following circumstances, it may be difficult to hear the other
party:
• When driving on unpaved roads
• When driving at high speeds
• When a window is open
• When the air conditioning is blowing directly on the microphone
• When the air conditioning is set to high
