set Lexus CT200h 2012 (in English) Repair Manual

278
2-4. Using other driving systems
CT200h_OM_OM76067E_(EE)
Setting up Lexus parking assist-sensor (vehicles with navigation
system)
You can change the warning beep volume and navigation system
screen operating conditions.
Press the “MENU” button on the Remote Touch.
Select “Setup” on the “Menu” screen.
Select “Vehicle” on the “Setup” screen.
Select “LEXUS park assist” on the “Vehicle settings”
screen.
Alert volume setting
Display on/off
Alert distance setting
Make sure to save after chang-
ing settings.
STEP1
STEP2
STEP3
STEP4
The Lexus parking assist-sensor can be operated when
Front corner sensors:
• The “POWER” switch is in ON mode.
• The shift position is in other than P.
• The vehicle speed is less than about 10 km/h (6 mph).
Rear corner and center sensors:
• The “POWER” switch is in ON mode.
• The shift position is in R.

280
2-4. Using other driving systems
CT200h_OM_OM76067E_(EE)
Navigation system screen display (if equipped)
If an obstacle is detected while the vehicle is reversing, the warning indica-
tor will appear in the top right of the screen even if the display setting has
been set to off.
If a message is displayed
P. 5 7 8
CAUTION
Caution when using the Lexus parking assist-sensor
Observe the following precautions.
Failure to do so may result in the vehicle being unable to be driven safely
and possibly cause an accident.
Do not use the sensor at speeds in excess of 10 km/h (6 mph).
Do not attach any accessories within the sensor range.

281
2-4. Using other driving systems
2
When driving
CT200h_OM_OM76067E_(EE)
NOTICE
Notes when washing the vehicle
Do not apply intensive bursts of water or steam to the sensor area.
Doing so may result in the sensor malfunctioning.
Conditions possibly indicating system malfunctions
If any of the following occurs, the system may be malfunctioning due to a
sensor failure etc. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
The buzzer does not sound when the Lexus parking assist-sensor mode is
set.
The sensor operation display flashes and the buzzer sounds even when no
obstacle is detected.
An area of the sensors is hit or subjected to a strong impact.
Either bumper is hit.
The sensor operation display remains on even though no buzzer sounds.

311
2-5. Driving information
2
When driving
CT200h_OM_OM76067E_(EE)
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropriate
to the prevailing weather conditions.
Pre-winter preparations
Use fluids that are appropriate to the prevailing outside
temperatures.
• Engine oil
• Engine/power control unit coolant
• Washer fluid
Have a service technician inspect the condition of the 12-
volt battery.
Have the vehicle fitted with four snow tires or purchase a
set of tire chains for the front tires.
Ensure that all tires are the same size and brand, and that chains
match the size of the tires.

312
2-5. Driving information
CT200h_OM_OM76067E_(EE)
Before driving the vehicle
Perform the following according to the driving conditions:
Do not try to forcibly open a window or move a wiper that
is frozen. Pour warm water over the frozen area to melt the
ice. Wipe away the water immediately to prevent it from
freezing.
To ensure proper operation of the climate control system
fan, remove any snow that has accumulated on the air inlet
vents in front of the windshield.
Check for and remove any excess ice or snow that may
have accumulated on the exterior lights, vehicle’s roof,
chassis, around the tires or on the brakes.
Remove any snow or mud from the bottom of your shoes
before getting in the vehicle.
When driving the vehicle
Accelerate the vehicle slowly, keep a safe distance between
you and the vehicle ahead, and drive at a reduced speed suit-
able to road conditions.
When parking the vehicle
Park the vehicle and shift the shift position to P and block the
wheel under the vehicle without setting the parking brake.
The parking brake may freeze up, preventing it from being

3Interior features
317
CT200h_OM_OM76067E_(EE)
3-3. Using the Bluetooth® audio
system
Bluetooth
® audio system . 388
Using the Bluetooth®
audio system .................. 394
Operating a Bluetooth
®
enabled portable
player ............................. 399
Setting up a Bluetooth
®
enabled portable
player ............................. 403
Bluetooth
® audio system
setup ............................... 408
3-4. Using the hands-free phone
system (for cellular phones)
Hands-free system for
cellular phone................. 409
Using the hands-free system
(for cellular phone) ........ 418
Making a phone call ......... 424
Setting a cellular phone.... 429
Security and system
setup ............................... 433
Using the phone book ...... 4383-5. Using the interior lights
Interior lights list ............. 445
• Personal/interior light
main switch.................... 446
• Front personal/interior
lights .............................. 446
• Rear interior light .......... 447
3-6. Using the storage features
List of storage features .... 448
• Glove box ...................... 449
• Console box ................... 450
• Cup holders.................... 451
• Bottle holders................. 452
• Auxiliary boxes ............. 453
3-7. Other interior features
Sun visors ........................ 457
Vanity mirrors .................. 458
Clock................................ 459
Power outlet ..................... 460
Heated steering wheel...... 463
Seat heaters ...................... 465
Floor mat.......................... 467
Luggage compartment
features .......................... 469

318
CT200h_OM_OM76067E_(EE)
3-1. Using the air conditioning system and defogger
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according to the
temperature setting.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
The illustration below is for left-hand drive vehicles.
The button positions and shapes may differ slightly for right-
hand drive vehicles.
Automatic mode but-
“OFF” but-
Fan speed control but-
Air outlet selector buttonOutside/recirculated air mode but-Cooling and dehumidifica-
tion Dual mode but- Driver’s side temperature control buttons
Fan speed dis- Driver’s side tempera-
ture
Windshield
defogger but-Passenger’s side temperature control but-
Air outlet dis-Passenger’s side tempera-
ture
Pollen removal
mode button

319
3-1. Using the air conditioning system and defogger
3
Interior features
CT200h_OM_OM76067E_(EE)
Using automatic air conditioning system
Press .
The air conditioning system begins to operate. Air outlets
and fan speed are automatically adjusted according to the
temperature setting.
Press to increase the temperature and to
decrease the temperature.
When is pressed (the indicator on is on) or the pas-
senger’s side temperature control button is pressed, the tempera-
ture for the driver and passenger seats can be adjusted separately.
Press .
The cooling and dehumidification function switches between on
and
off each time the button is pressed.
STEP1
STEP2
STEP3

320
3-1. Using the air conditioning system and defogger
CT200h_OM_OM76067E_(EE)
Adjusting the settings manually
Basic setting
To turn on the air conditioning system and adjust the fan
speed, press to increase the fan speed and
to decrease the fan speed.
Press to turn the fan off.
To adjust the temperature setting, press to increase
the temperature and to decrease the temperature.
When is pressed (the indicator on is on) or the pas-
senger’s side temperature control button is pressed, the tempera-
ture for the driver and passenger seats can be adjusted separately.
STEP1
STEP2

325
3-1. Using the air conditioning system and defogger
3
Interior features
CT200h_OM_OM76067E_(EE)
Registering air conditioning settings to electronic keys (vehicles with smart
entry & start system)
Unlocking the vehicle using an electronic key and turning the “POWER”
switch to ON mode will recall that key’s registered air conditioning set-
tings.
When the “POWER” switch is turned off, the current air conditioning
settings will automatically be registered to the electronic key that was
used to unlock the vehicle.
The system may not operate correctly if more than one electronic key is in
the vicinity or if the smart entry & start system is used to unlock a passenger
door.
Settings for the electronic key and the corresponding door can be changed.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
