Warning lights inform the driver of malfunctions in any of the vehicle’s
systems.
Warning lights
*1Brake system warning
light
(P. 568)*1Slip indicator light
(P. 570)
*1Brake system warning
light
(P. 568)*1
(if
equipped)
Automatic headlight
leveling system warning
light (P. 570)
*1Charging system warning
light (P. 568)*1High coolant temperature
warning light (P. 570)
*1Low engine oil pressure
warning light (P. 568)Open door warning light
(P. 570)
*1Malfunction indicator
lamp
(P. 569)Low fuel level warning
light
(P. 570)
*1SRS warning light
(P. 569)Driver’s and front
passenger’s seat belt
reminder light (P. 570)
*1ABS warning light
(P. 569)*3Rear passengers’
seat
belt reminder lights
(P. 570)
*1Electric power steering
system warning
light (P. 569)*1Master warning light
(P. 570)
*1, 2
(if
equipped)
“PCS” warning light
(P. 569)
*1
(if
equipped)
Tire pressure warning
light
(P. 571)
Page 102 of 688

1022. Instrument cluster
CT200h_OM_OM76102E_(EE)
*1: These lights turn on when the power switch is turned to ON mode to indicate
that a system check is being performed. They will turn off after the hybrid sys-
tem is on, or after a few seconds. There may be a malfunction in a system if
the lights do not turn on, or turn off. Have the vehicle inspected by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
*2: The light flashes to indicate a malfunction.
*3: This light illuminates on the center panel.
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
(P. 209)“ECO MODE” indica-
tor
(P. 265)
Tail light indicator
(P. 211)“SPORT MODE”
indicator (P. 265)
Headlight high beam
indicator (P. 212)
(if
equipped)
Cruise control indicator
(P. 228, 231)
(if
equipped)
Front fog light indicator
(P. 216)
(if
equipped)
Radar cruise control
indicator (P. 231)
Rear fog light indicator
(P. 216)
(if
equipped)
Lexus parking
assist-sensor indicator
(P. 245)
“READY” indicator
(P. 196)
*1, 2Slip indicator light
(P. 268, 271)
EV indicator (P. 79)
*1“TRC OFF” indicator
(P. 268)
Page 103 of 688

1032. Instrument cluster
2
Instrument cluster
CT200h_OM_OM76102E_(EE)
*1: These lights turn on when the power switch is turned to the ON mode to indi-
cate that a system check is being performed. They will turn off after the hybrid
system is on, or after a few seconds. There may be a malfunction in a system
if the lights do not turn on, or turn off. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than
usual to indicate that the system is operating.
*4: This light illuminates on the center panel.EV drive mode indicator
(P. 201)
*1, 3
(if
equipped)
“PCS” warning light
(P. 274)
Shift position indicators
(P. 203)
*1, 4“PASSENGER
AIR BAG” indica-
tor
(P. 56)
WA R N I N G
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS airbag warning light not
come on when you start the hybrid system, this could mean that these systems
are not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional immediately if
this occurs.
Page 104 of 688

1042. Instrument cluster
CT200h_OM_OM76102E_(EE)
Gauges and meters
Vehicles with monochrome display
Vehicles with color display
The units used on the meters may differ depending on the target region.
Page 105 of 688

1052. Instrument cluster
2
Instrument cluster
CT200h_OM_OM76102E_(EE)
Hybrid System Indicator
Displays hybrid system output or regeneration level
Changes to the tachometer depending on the drive mode or setting on the dis-
play. (P. 107, 650)
Tachometer (if equipped)
Displays the engine speed in revolutions per minute
Changes to Hybrid System Indicator depending on the drive mode or setting
on the display. (P. 107, 650)
Shift position indicators
P. 203
Speedometer
Displays the vehicle speed
ECO lamp and SPORT lamp (if equipped)
Changes colors according to driving mode (P. 107)
Fuel gauge
Displays the quantity of fuel remaining in the tank
Multi-information display
Presents the driver with a variety of driving-related data (P. 109, 112)
Displays warning messages in case of a malfunction (P. 575)
Outside temperature
The temperature range that can be displayed is from -40C (-40F) to 50C
(122F)
Odometer and trip meter display
Odometer:
Displays the total distance that the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was
last reset. Trip meters “A” and “B” can be used to record and display
different distances independently.
Odometer/trip meter display change button
P. 106
1
2
3
4
5
6
7
8
9
10
Page 106 of 688

1062. Instrument cluster
CT200h_OM_OM76102E_(EE)
Switches between odometer and
trip meter displays. When the trip
meter is displayed, pressing and
holding the button will reset the trip
meter.
The brightness of the instrument panel lights can be adjusted by turning
the dial.
Brighter
Darker
When the headlight switch is turned
to ON, the brightness will be
reduced slightly unless the control
dial is turned fully up.
When the dial is turned fully down,
the cup holder light and the footwell
lights will turn off. (P. 461)
Changing the display
Instrument panel light control
1
2
Page 107 of 688

1072. Instrument cluster
2
Instrument cluster
CT200h_OM_OM76102E_(EE)
The meters and display illuminate when
The power switch is in ON mode.
Hybrid System Indicator
Hybrid System Indicator is displayed when the driving mode is in other than the
sport mode.
By keeping the indicator needle within Eco area, more Eco-friendly driving can
be achieved.
Charge area indicates regeneration* status. Regenerated energy will be used to
charge the hybrid battery (traction battery).
*: When used in this manual, “regeneration” refers to the conversion of energy
created by the movement of the vehicle into electrical energy.
Tachometer (if equipped)
The tachometer is displayed when the driving mode is in the sport mode.
ECO lamp and SPORT lamp (if equipped)
When sport mode is selected, the SPORT lamp (red) will illuminate.
When all of the following conditions are satisfied and the Eco-friendly driving,
the ECO lamp (blue) will illuminate:
• Driving with the shift position in D
• Either normal mode or Eco drive mode is selected, and EV drive mode is not
in use (P. 201, 265)
• The vehicle speed is approximately 130 km/h (80 mph) or below. Power area
Shows that an Eco-friendly driving range
is being exceeded (during full power
driving etc.)
Eco area
Shows that the vehicle is being driven in
an Eco-friendly manner.
Hybrid Eco area
Shows that gasoline engine power is not
being used very often.
The gasoline engine will automatically
stop and restart under various conditions.
Charge area
Shows that energy is being recovered via
the regenerative brake.
1
2
3
4
Page 108 of 688

1082. Instrument cluster
CT200h_OM_OM76102E_(EE)
Engine speed
On hybrid vehicles, engine speed is precisely controlled in order to help improve
fuel efficiency and reduce exhaust emissions etc.
There are times when the engine speed that is displayed may differ even when
vehicle operation and driving conditions are the same.
Outside temperature display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 20 km/h [12 mph])
• When the outside temperature has changed suddenly (at the entrance/exit of
a garage, tunnel, etc.)
When “--” or “E” is displayed, the system may be malfunctioning.
Take your vehicle to any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
Customization
Settings (e.g. on/off operation of the ECO lamp) can be changed.
(Customizable features: P. 650)
NOTICE
To prevent damage to the engine and its components
Vehicles with tachometer: Do not let the indicator needle of the tachometer
enter the red zone, which indicates the maximum engine speed.
The engine may be overheating if the high coolant temperature warning light
comes on or flashes. In this case, immediately stop the vehicle in a safe place,
and check the engine after it has cooled completely. (P. 628)
Page 109 of 688

109
2 2. Instrument cluster
Instrument cluster
CT200h_OM_OM76102E_(EE)
Multi-information display (with monochrome
display)
The multi-information display presents the driver with a variety of vehi-
cle data.
Energy monitor
Displays the status of the hybrid sys-
tem. (P. 117)
Drive information
Displays driving range, fuel con-
sumption and other cruising related
information. (P. 1 1 0 )
Setting
Changes instrument cluster display
settings (P. 650)
Lexus parking assist-sensor (if equipped)
Automatically displayed when the system is used (P. 245)
Dynamic radar cruise control display (if equipped)
Automatically displayed when the system is used (P. 231)
Warning messages
Automatically displayed when a malfunction occurs in one of the vehicle’s
systems (P. 575)
: If equipped
Display contents
Page 110 of 688

1102. Instrument cluster
CT200h_OM_OM76102E_(EE)
Items displayed can be switched by
pressing the “DISP” switch.
Energy monitor
P. 1 1 7
Current fuel consumption/Average fuel consumption after refueling
Displays the instant fuel consumption and average fuel consumption
after refueling.
Use the displayed average fuel consumption as a reference.
Average fuel consumption
Displays the average fuel consumption since the function was reset.
• The function can be reset by pressing the “DISP” switch for longer than 1
second when the average fuel consumption is displayed.
• Use the displayed average fuel consumption as a reference.
Cruising range
Displays the estimated maximum distance that can be driven with the
quantity of fuel remaining.
• This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.
• When only a small amount of fuel is added to the tank, the display may not
be updated.
When refueling, turn the power switch off. If the vehicle is refueled with-
out turning the power switch off, the display may not be updated.
Elapsed time
Displays the elapsed time since the hybrid system was started or the
function was reset.
The function can be reset by pressing the “DISP” switch for longer than 1
second when the elapsed time is displayed.
Average vehicle speed
Displays the average vehicle speed since the function was reset.
Drive information
