Lexus CT200h 2013 Owner's Manual (in English)

3385-7. Setup menu
CT200h_OM_OM76102E_(EE)
Select “Initialize” and then “Confirm” using the “TUNE•SEL” knob.
Select “Confirm” again using the knob.
Initialization
The following data in the system can be initialized:
• Phone book
• Outgoing and incoming call history
• Speed dials
• Registered cellular phone data
• Security code
• Registered Bluetooth
® enabled portable player data
• Passkeys for the cellular phones
• Passkey for the Bluetooth
® audio players
• Guidance volume
• Receiver volume
• Ring tone volume
Once the initialization has been completed, the data cannot be restored to its
original state.
When the phone book is locked
The following functions cannot be used:
Dialing by inputting a name
Speed dialing
Dialing a number stored in the call history memory
Using the phone book
Initializing the system
1
2

339
5 5-7. Setup menu
Audio system
CT200h_OM_OM76102E_(EE)
Using the phone book
To enter the menu of each setting, follow the steps below.
Press the off-hook switch and select “Phonebook” using the
“TUNE•SEL” knob.
Select one of the following items using the knob.
Adding a new phone number
“Add Entry”
Changing the registered name in the phone book
“Change Name”
Listing the registered data
“List Names”
Setting speed dials
“Speed Dial”
Deleting the registered data
“Delete Entry”
Deleting speed dials
“Del Spd Dial”
The following methods can be used to add a new phone number:
Transferring data from the cellular phone
Inputting a phone number using the “TUNE•SEL” knob
Selecting a phone number from outgoing or incoming call history
Adding procedure
Select “Add Entry” using the “TUNE•SEL” knob.
Use one of the following methods to input a telephone number:
Transferring data from the cellular phone:
STEP2-1 Select “By Phone” and then “Confirm” using the knob.
STEP2-2 When “Transfer” appears in the display, transfer the data
from the cellular phone.
Refer to the manual that comes with the cellular phone for the
details of transferring data.
STEP2-3 Select the desired data using the knob.
Adding a new phone number
1
2
1
2

3405-7. Setup menu
CT200h_OM_OM76102E_(EE)
Inputting a phone number using the knob:
STEP2-1 Select “Manual Input” using the knob.
STEP2-2 Input a phone number using the knob, and press the knob
again.
Input the phone number 1 digit at a time.
Selecting a phone number from outgoing or incoming call history:
STEP2-1 Select “Call History” using the knob.
STEP2-2 Select “Outgoing” or “Incoming” using the knob.
STEP2-3 Select the desired data using the knob.
Select “Record Name” using the knob, and say the desired name
after the beep.
The name to be registered will be repeated aloud.
Select “Confirm” using the knob.
Select “Confirm” again using the knob.
In , selecting “Speed Dial” instead of “Confirm” registers the newly
added phone number as a speed dial.
Select “Change Name” using the “TUNE•SEL” knob
Select the desired name to be changed using the knob.
Select “Record Name” using the knob, and say the new name after the
beep.
The name to be registered will be repeated aloud.
Select “Confirm” using the knob.
Selecting “List Names” using the “TUNE•SEL” knob. The list of the reg-
istered data will be read aloud.
When listing is complete, the system returns to “Phonebook”.
Pressing the off-hook switch while an entry is being read aloud selects the
entry, and calls the registered phone number.
Changing the registered name in the phone book
Listing the registered data
3
4
5
5
1
2
3
4

3415-7. Setup menu
5
Audio system
CT200h_OM_OM76102E_(EE)
Select “Speed Dial” using the “TUNE•SEL” knob
Select the desired data using the knob.
Select the desired preset button, and register the data into speed dial by
either of the following methods:
a. Press the desired preset button, and select “Confirm” using the knob.
b. Press and hold the desired preset button.
Select “Delete Entry” using the “TUNE•SEL” knob
Select the desired data to be deleted using the knob.
Select “Del Spd Dial” using the “TUNE•SEL” knob.
Press the preset button to which the desired speed dial is registered
after the beep.
The name to be deleted will be heard.
Select “Confirm” using the knob.
Adding an entry to the phonebook
Up to 20 names can be stored.
Limitation of number of digits
A phone number that exceeds 24 digits cannot be registered.
Setting speed dials
Deleting the registered data
Deleting speed dials
1
2
3
1
2
1
2
3

3425-8. Bluetooth® Audio
CT200h_OM_OM76102E_(EE)
Operating a Bluetooth® enabled portable player
To select the desired album, press the “5” button or the “6” button.
Press “”or “” on the “SEEK•TRACK” button to select the desired
track.
Control panel
Displaying text message
Repeat play
Playback/pause
Album selection
“TUNE•SEL” knob
BT•A menu
PlaybackTrack selection
Random play
Power/volume knob
Press: Turning the audio sys-
tem on
or off
Turn: Adjusting the volume1
2
3
4
5
6
7
8
9
Selecting an album
Selecting tracks

3435-8. Bluetooth® Audio
5
Audio system
CT200h_OM_OM76102E_(EE)
To play or pause a track, press the “3” button.
To fast-forward or rewind, press and hold “”or “” on the
“SEEK•TRACK” button until you hear a beep.
Press the “1” button.
To cancel, press the button again.
Press the “2” button.
To cancel, press the button again.
Press the “TEXT” button.
Each time the button is pressed, the display changes in the following order:
Elapsed time  Album title  Track title  Artist name
Bluetooth® audio system functions
Depending on the portable player that is connected to the system, certain func-
tions may not be available.
Display
P. 304
Error messages
“Memory Error”: This indicates a problem in the system.
Playing and pausing tracks
Fast-forwarding and rewinding tracks
Random play
Repeat play
Switching the display

3445-9. Bluetooth® Phone
CT200h_OM_OM76102E_(EE)
Making a phone call
Making a phone call
Dialing by inputting a name
“Dial by name”
Speed dialing
Dialing a number stored in the outgoing history memory
“Redial”
Dialing a number stored in the incoming history memory
“Call back”
Using the call history memory
Dialing
Storing data in the phone book
Deleting
Press the talk switch and say a registered name.
The desired name or number is displayed.
Dial by one of the following methods:
a. Press the off-hook switch.
b. Select “Dial” using the “TUNE•SEL” knob.
In , if the pronounced name cannot be recognized, select the desired name
using the knob.
Press the off-hook switch.
Press the preset button in which the desired number is registered.
Press the off-hook switch.
Dialing by inputting a name
Speed dialing
1
2
1
1
2
3

3455-9. Bluetooth® Phone
5
Audio system
CT200h_OM_OM76102E_(EE)
Follow the procedure below to use number stored in call history memory:
Press the off-hook switch and select “Redial” (when using a number
stored in the outgoing call history memory) or “Call back” (when using
a number stored in the incoming call history memory) using the
“TUNE•SEL” knob.
Select the desired number using the knob.
The following operations can be performed:
Dialing: Press the off-hook switch or select “Dial” using the knob.
Storing the number in the phone book: Select “Store” and then “Con-
firm” using the knob.
Deleting: Select “Delete” and then “Confirm” using the knob.
Call history
Up to 5 numbers can be stored in each of the outgoing and incoming call history
memories.
Using a call history memory
1
2
3

3465-9. Bluetooth® Phone
CT200h_OM_OM76102E_(EE)
Receiving a phone call
Press the off-hook switch.
Press the on-hook switch.
Answering the phone
Refusing the call

347
5 5-9. Bluetooth® Phone
Audio system
CT200h_OM_OM76102E_(EE)
Speaking on the phone
A call can be transferred between the cellular phone and system while
dialing, receiving a call, or during a call. Use one of the following meth-
ods:
a. Operate the cellular phone.
Refer to the manual that comes with the cellular phone for the operation of
the phone.
b. Press the off-hook switch*.
*: This operation can be performed only when transferring a call from the cel-
lular phone to the system during a call.
When talking on the phone
Do not talk simultaneously with the other party.
Keep the volume of the received voice down. Otherwise, voice echo will
increase.
Transferring a call
