Lexus CT200h 2016 Owner's Manual (in English)

5418-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
An attempt was made to shift the shift position from R to
B. A buzzer also sounds.
The shift position automatically changed to N.
 Shift the shift position to D, and then shift the shift
position to B.
An attempt was made to shift the shift position to D while
the vehicle was moving in reverse.
A buzzer also sounds.
The shift position automatically changed to N.
 Stop the vehicle, and then change the shift position.
An attempt was made to shift the shift position to R while
the vehicle was moving forward.
A buzzer also sounds.
The shift position automatically changed to N.
 Stop the vehicle, and then change the shift position.
Indicates that the P position switch is pressed while the
vehicle is running. A buzzer also sounds.
The shift position automatically changed to N.
 To shift the shift position to P, stop the vehicle com-
pletely and press the P position switch.
 To continue driving, shift th e shift position to D or R.
(If equipped)
Indicates that the radar cruise control sensor is dirty or
covered with ice
A buzzer also sounds.
 Clean the sensor.
(If equipped)
Indicates that the dynamic radar cruise control system is
unable to judge vehicle-to-vehicle distance
A buzzer also sounds.
 If the windshield wipers are on, turn them off or set
them to either intermittent or slow mode.
Wa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)
(Flashes)
(Flashes)

5428-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
Indicates a malfunction in:
• The cruise control system; or
• The dynamic radar cruise control systemPress the “ON-OFF” button once to deactivate the
system, and then press the button again to reactivate
the system.
A buzzer also sounds.
 Have the vehicle inspected by your Lexus dealer.
(If equipped)
Indicates a malfunction in the pre-collision system
A buzzer also sounds.
 Have the vehicle inspected by your Lexus dealer.
(If equipped)
Indicates that the moon roof is not fully closed (with the
power switch off, and the driver’s door open)
A buzzer also sounds.
 Close the moon roof.
Indicates that the hybrid system has overheated
This message may be disp layed when driving under
severe operating conditions. (For example, when driv-
ing up a long steep hill.)
A buzzer also sounds.
 Stop and check. ( P. 5 6 6 )
(If equipped)
Indicates a malfunction in the LED headlight system
A buzzer also sounds.
 Have the vehicle inspected by your Lexus dealer.
Indicates that the wash er fluid level is low
 Add washer fluid.
Wa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)
(Flashes)

5438-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
*1: Refer to the separate “Scheduled Maintenance” or “Owner’s Manual Supplement” for the maintenance interval applicable to your vehicle.
*2: For the EV drive mode operating conditions ( P. 1 6 0 ) .
(U.S.A. only)
Indicates that all maintenance according to the driven
distance on the maintenance schedule
*1 should be per-
formed soon. Comes on approximately 4500 miles (7200 km)
after the message has been reset.
 If necessary, perform maintenance.
(U.S.A. only)
Indicates that all maintenance is required to correspond
to the driven distance on the maintenance schedule
*1.
Comes on approximately 5000 miles (8000 km)
after the message has been reset.
(The indicator will not work properly unless the mes-
sage has been reset.)
 Perform the necessary maintenance. Please reset
the message after the maintenance is performed
( P. 4 6 8 )
(If equipped)
Indicates that the pre-collisio n system is not currently
functional because the grille cover or the sensor is dirty
This message also appears when the pre-collision sys-
tem is not functional due to overheating.
 Check the grille cover and the sensor and clean
them if they are dirty.
In case of overheating, the system will become func-
tional once the system cools down.
Indicates that the EV drive mode is not available*2
The reason the EV drive mode is not available (the
vehicle is idling, battery char ge is low, speed is higher
than the EV drive mode operating speed range, accel-
erator pedal is depressed too much) may be dis-
played.
A buzzer also sounds.
 Use the EV drive mode when it becomes available.
Indicates that the EV drive mode has been automatically
canceled*2
The reason the EV drive mode is not available (the
battery charge is low, sp eed is higher than the EV
drive mode operating speed range, accelerator pedal
is depressed too much) may be displayed.
A buzzer also sounds.
 Drive the vehicle for a while.
Wa r n i n g m e s s a g eDetails/Actions
(Flashes
3 times)

5448-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
■Wa r n i n g m e s s a g e s
The warning message illustrations used are intended as examples, and may differ from
the image that is actua lly displayed on the multi-information display.
■Warning message in radar cruise mode (if equipped)
In the following situations, the warning messag e may not be displayed even if vehicle-to-
vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same speed or the vehicle
ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
■Warning buzzer
 P. 5 3 3
Carrying out the corresponding action turns the message off.
Other displayed message
Displayed messageDetails/Actions
Maintenance of the hybrid battery (traction battery)
cooling component is required
The filter may be clogged, the air intake vent may be
blocked or there may be a gap in the duct.
 Have maintenance performed on the hybrid battery
(traction battery) cooling component at your Lexus
dealer.

5458-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
Interior buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions

Power was turned off due to the
automatic power off function.
 Next time, start the hybrid sys-
tem and keep it on for approxi-
mately 5 minutes or more to
recharge the 12-volt battery.
Con-
tinuous  The driver’s door was opened while
any shift position other than P was
selected without turning off the
power switch.

Shift the shift position to P.
Con-
tinuousCon-
tinuous
The electronic key was carried out-
side the vehicle and the driver’s door
was opened and closed while any
shift position other than P was
selected without turning off the
power switch.
Shift the shift position to P.
 Bring the electronic key back
into the vehicle.
Once  An attempt was made to start the
hybrid system without the electronic
key being present, or the electronic
key was not functioning normally.

Start the hybrid system with the
electronic key present.
An attempt was made to drive when
the regular key was not inside the
vehicle.
 Confirm that the electronic key
is inside the vehicle.
(Flashes)
(Flashes)
(Flashes)

5468-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
Once3 times
The electronic key was carried out-
side the vehicle and a door other
than the driver’s door was opened
and closed while the power switch
was in a mode other than off.
Bring the electronic key back
into the vehicle.
The electronic key was carried out-
side the vehicle and the driver’s door
was opened and closed while the
shift position P was selected without
turning off the power switch.
Tu r n t h e p o w e r s w i t c h o f f .
 Bring the electronic key back
into the vehicle.
Once
Sounds
once
for 5
sec-
ondsAn attempt was made to exit the
vehicle with the electronic key and
lock the doors without first turning
the power switch off.
Tu r n t h e p o w e r s w i t c h o f f a n d
lock the doors again.
Once
An attempt was made to turn the
power switch off when the shift posi-
tion was not in P.
To turn off the hybrid system,
first shift the shift position to P
and then turn the power switch
off.
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Displayed alternately)
(Flashes)
(Flashes)

5478-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
Once
Sounds
once
for 5
sec-
onds
• An attempt was made to lock the doors using the smart access sys-
tem with push-button start while
the electronic key was still inside
the vehicle.
• An attempt was made to lock either front door by opening a
door and putting the inside lock
button into the lock position, then
closing the door with the elec-
tronic key still inside the vehicle.
 Retrieve the electronic key
from the vehicle and lock the
doors again.
Once
• When the doors were unlocked
with the mechanical key and then
the power switch was pressed, the
electronic key could not be
detected in the vehicle.
• The electronic key could not be
detected in the vehicle even after
the power switch was pressed two
consecutive times.
 Touch the electronic key to the
power switch while depressing
the brake pedal.
Once
The driver’s door was opened and
closed with the power switch turned
off and then the power switch was
put in ACCESSORY mode twice
without the hybrid system being
started.
Press the power switch while
depressing the brake pedal.
During a hybrid system starting pro-
cedure in the event that the elec-
tronic key was not functioning
properly ( P. 561), the power
switch was touched with the elec-
tronic key.
 Press the power switch within 10
seconds of the buzzer sounding.
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)
(Flashes)

5488-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
■Wa r n i n g m e s s a g e s
P. 5 4 4
■Warning buzzer
P. 5 3 3
Once
An attempt was made to start the
hybrid system with the shift position
in N.
 Shift the shift position to P and
start the hybrid system.
OnceThe electronic key has a low battery.
Replace the electronic key bat-
tery. ( P. 5 0 4 )
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)

549
CT200h_OM_OM76197U_(U)
8
When trouble arises
8-2. Steps to take in an emergency
If you have a flat tire
●Stop the vehicle on a hard, flat surface.
●Set the parking brake.
●Shift the shift position to P.
●Stop the hybrid system.
●Turn on the emergency flashers. (P. 522)
Your vehicle is equipped with a spare ti re. The flat tire can be replaced with
the spare tire.
For details about tires: P. 4 9 0
WA R N I N G
■If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat ti re can damage the tire and the wheel beyond
repair, which could result in an accident.
Before jacking up the vehicle

5508-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
Location of the spare tire, jack and tools
Towing eyelet
Jack
Spare tireJack handle
Wheel nut wrench1
2
3
4
5
