GAUGES, METERS AND SERVICE REMINDER INDICATORS
34
When the ºABSº warning light is on (and the brake system warning light is
off), the brake system operates conventionally but anti±lock brake system i\
s
not assisting brake performance so that the wheels could lock up during a
sudden brake or braking on slippery road surfaces.
(i) Open Door Warning Light
This light remains on until all the doors are completely closed.
(j) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at the f\
irst or
second
clickstop), it indicates that one or more of the tail lights are burned\
out.
If it comes on when the brake pedal is depressed, one or more stop light\
s are
burned out.
Have defective bulbs replaced as soon as possible.
(k) ºTRAC OFFº Indicator/Warning Light
This light comes on when the ignition key is turned to ºONº, and will \
go off
after 3 seconds. This means that the system is operating properly.
If the light flashes, this indicates a malfunction in the traction control\
system.
Contact your Lexus dealer as soon as possible to service the vehicle.
(l) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes nearly empt\
y.
Fill the tank as soon as possible.
(m) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes nearly empty. Fill
the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank, the low fu\
el
level warning light may come on earlier than usual.
(n) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the driver's door
with the ignition key in the ºACCº or ºLOCKº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS35
How to check all the service reminder indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It goes off when
you close the door completely.
3. Turn the ignition key to ºACCº.
The following service reminder indicator should come on. It goes off after 6
seconds.
4. Turn the ignition key to ºONº.
The following service reminder indicators should come on.
or

or

The following service reminder indicators go off after a few seconds.
or

5. Turn the ignition key to ºSTARTº.
The following service reminder indicators should come on.

If any service reminder indicator or warning buzzer does not function, e\
ither
the bulb is burned out or circuit is in need of repair. Have it checked by your
Lexus dealer as soon as possible.
INSTRUMENT PANEL LIGHT CONTROL
13E005
To adjust the brightness of the instrument panel lights, turn the knob.

SECTION 1 ± 4
36
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Interior light 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Personal light 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Ignition switch light 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Clock 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Cigarette lighter and ashtray 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 41
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Glovebox 41
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Cup holder 41
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Overhead console box 43
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Floor mat 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Luggage stowage precautions 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

COMFORT ADJUSTMENT
96
By repeating these two steps and pressing the remaining button, the driv\
ing
position for another driver can be recorded.
To set a new memorized position, select the desired position and perform s\
tep
2. The previous memory will be erased and the new position will be set.
To make only slight changes to an already memorized position, the easiest
way is to first activate the memorized position, then make the desired changes\
and perform step 2 above.
Activating a memorized position
16E048
When you push button º1º or º2º, the driving position will be
automatically adjusted to the position recorded for that button.
Conditions for memorized position activation

Ignition key ºONº and shift lever in ºPº position
All parts of the memorized positions can be activated.
However, if the brake pedal is being depressed, the seat position will not
change.
 Key not in ignition switch and within 30 seconds of opening driver's door.
The memorized position can be activated.
If any driving position memory switch is pushed while one of the memorized\
driving position profiles is being activated, the operation will stop.
To activate the system, push the desired button (º1º or º2º)\
again.
The driving position memory control system cannot be operated while the
vehicle is moving.
If the vehicle's battery is disconnected, the computer's memory will be erased
and the memorized positions will have to be set again.

THEFT DETERRENT99
THEFT DETERRENT SYSTEM
To deter theft of the vehicle, this system is designed to give an alarm if\
any
of the doors, trunk or hood is forcibly unlocked or the battery terminal
is disconnected and then reconnected while the vehicle is locked.
The alarm blows the horn intermittently and flashes the headlights, tail li\
ghts
and other exterior lights.
17E001±1
Setting the system
1. Turn the ignition key to the ºLOCKº position and remove it.
2. Close and lock all the doors, trunk and hood using an ignition key or
wireless remote control. If you lock them with wireless remote control, the turn signals flash on\
ce.
The indicator light will come on when all the doors, trunk and hood are clo\
sed
and locked.
3. After 30 seconds, the indicator flashes and the system is set.
Cancelling the system
When you unlock any door or trunk using an ignition key or wireless
remote control, the system is cancelled.
If you unlock any door or trunk with wireless remote control, the turn sig\
nals
flash twice.
Activating the system
The alarm sounds for 60 seconds if any of the following are operated:


Unlocking any door or trunk without using an ignition key or wireless
remote control.

Opening the hood forcibly.

Reconnecting the battery.
If any door is unlocked and the ignition key is not in the ignition switch\
during
the alarm sounding, its door is automatically locked.

THEFT DETERRENT
100
To stop the alarm: Use either of the following methods.


Unlock the door or trunk using an ignition key or wireless remote control.

Turn the ignition switch on.
Testing the system
1. Open all the windows.
2. Set the system as described above.
The front doors should be locked with the ignition key or wireless remote
control. Be sure to wait until the indicator light starts flashing.
3. Unlock one of the doors from the inside.
The system should activate the alarm.
4. Unlock any of the doors with a key or the wireless remote control to
cancel the system.
5. Repeat this operation for the other doors and hood.
When testing the hood, also check that the system is activated when the batte\
ry
terminal is disconnected and then reconnected.
If the system does not work properly, have it checked by your Lexus dealer.
NOTICE
Disconnecting the battery may result in the erasure of information you
have set in the computer memory. After reconnecting the battery, check
that the memorized data has been retained. If it has been erased, input
it into the computer once more.

AIR CONDITIONING AND AUDIO
108
20E007±1
The air intake control button is used to switch the air intake between the
OUTSIDE AIR mode and RECIRCULATED AIR mode.
With the button in the OUTSIDE AIR mode, the OUTSIDE AIR mode
indicator light will come on and the system will take fresh outside air into the
vehicle.
If quick circulation of cooled air is desired, push the air intake control\
button
for RECIRCULATED AIR. The RECIRCULATED AIR mode indicator light
will come on.
For normal use, it is best to keep the air intake control button set to OUT\
SIDE
AIR mode. If recirculated air is used during heating, the windows will \
fog up
more easily.If the engine coolant temperature becomes extremely high, the
RECIRCULATED AIR mode is automatically selected. This is not a
malfunction. When the engine coolant temperature is lowered, the previous
mode resumes.
If manual on±off of the air conditioning is desired ±
Push the ºA/Cº button to turn the air conditioning on and push it agai\
n to turn
the air conditioning off.
The air conditioning does not work if the outside temperature is lowered do\
wn
to around 0C (32F).
If the system is used for ventilation, heating in dry weather or removing \
frost
or exterior fog on the windshield, turn the air conditioning off once it is no
longer required. This will improve fuel economy. The air conditioning can
be used for year±round automatic temperature control including cooling \
and
dehumidifying operation.
If the air conditioning compressor does not operate, the indicator of the \
ºA/Cº
button will blink. If the indicator of the ºA/Cº button blinks even wh\
en the
ºA/Cº button is pushed again, have the compressor checked by your \
nearest
Lexus dealer.
Displaying the outside temperature ±
When you push the ºOUTSIDE TEMPº knob, the temperature display shows
the outside temperature. To return to the display of the current set
temperature, push the knob again. The temperature display ranges from
±30 C (±22F) up to 50C (122F).

STARTING AND DRIVING
136
HOW TO START THE ENGINE
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in ºPº. If you need to restart the engine \
while the
vehicle is moving, put the selector lever in ºNº. A starter safety devic\
e will
prevent the starter from operating if the selector lever is in any drive positi\
on.
4. Depress the brake pedal and hold it to the floor until you are ready to \
drive
off.
Starting the engine
Before starting the engine, be sure to follow the instructions in ºBefore
crankingº.
Normal starting procedure
The multiport fuel injection system/sequential multiport fuel injection sys\
tem
in your engine automatically controls the proper air±fuel mixture for s\
tarting.
You can start a cold or hot engine as follows:
1. With your foot off the accelerator pedal, crank the engine by turning the
key to ºSTARTº. Release it when the engine starts.
2. After the engine runs for about 10 seconds, you are ready to drive.If the weather is below freezing, let the engine warm up for a few minut\
es
before driving. Do not leave the vehicle while the engine is warming up.
If the engine stalls ...
Simply restart it , using the correct procedure given in normal starting\
.
If the engine will not start
See ºIf your vehicle will not startº on page 162.
NOTICE

Do not crank for more than 30 seconds at a time. This may overheat
the starter and wiring systems.
 Do not race a cold engine.
 If the engine becomes difficult to start or stalls frequently, have the
engine checked immediately.

STARTING AND DRIVING
140
In ºDº position, the automatic transmission system will select the most
suitable
gear for the running conditions such as hill climbing, hard towing, etc.\
If you need to accelerate rapidly while driving, push the accelerator pe\
dal all
the way to the floor. The transmission will automatically downshift to the
third, second or first gear, according to the vehicle speed.
If engine braking is needed, such as in descending a long hill, see º(\
b) Using
engine brakingº.
(b) Using engine braking
31E009±2
To use the braking power of the engine, downshift the transmission in the way
described below:
1 Turn off the overdrive switch. (This is effective only when you are
driving in the ºDº position.) The ºO/D OFFº indicator light in th\
e
instrument cluster will come on and the transmission will downshift to
the third gear and engine braking will be obtained.
When the cruise control is being used, even if you downshift the
transmission by t urning off the overdrive switch, engine braking will not
be applied because the cruise control is not cancelled. If you need to
decrease the vehicle speed, see page 146.
2 Shift into the º2º position. The transmission will downshift to t\
he
second gear when the vehicle speed is lower than 122 km/h (76 mph) and
more powerful engine braking will be obtained.

STARTING AND DRIVING
144
CRUISE CONTROL
The cruise control allows you to cruise the vehicle at a desired speed over
40 km/h (25 mph) with your foot off the accelerator pedal.
Your cruising speed can be maintained although a slight speed change may
occur when driving up or down a gradient, within the limits of engine
performance. On steeper hills, a great speed change will occur so it is better
to drive without the cruise control.
CAUTION
To help maintain maximum control of your vehicle, do not
use the cruise control when driving in heavy or varying
traffic, or on slippery (rainy, icy or snow±covered) or
winding roads.
 Avoid vehicle speed increases when driving downhill. If the
vehicle speed is too fast in relation to the cruise control set
speed, cancel the cruise control then downshift the
transmission to use engine braking to slow down.
Turning on the system
31L013
To operate the cruise control, push the main switch. This turns the syste\
m on.
The indicator light in the instrument cluster shows that you can now set yo\
ur
desired cruising speed. Another push on the switch will turn the system
completely off.
When the ignition key is turned off, the main switch is also automatically
turned off. To use the cruise control again, push the main switch again to turn
it on.
CAUTION
To avoid accidental cruise control engagement, keep the main
switch off when not using the cruise control.
