ELECTRICAL COMPONENTS217
No.FUSEAMPERECIRCUIT
1 ABS60Anti±lock brake system
2 DRL NO.25Vehicles sold in Canada
Daytime Running Light System
3 H±LP
LH (LO)10Vehicles sold in Canada
Left±hand headlight (low beam)
4
H±LP
RH(LO)10Vehicles sold in Canada
Right±hand headlight (low beam)
4
A/F HTR25Vehicles sold in California
Air fuel ratio sensor
5 ALT100Charging system
6 CDS NO.230No circuit
7 HTR50Air conditioning system, Seat
heater
8 MAIN40Headlight, Starting system
9 DOME7.5
Theft deterrent system, Clock,
Door courtesy light, Interior light,
Ignition switch light, Vanity light,
Wireless remote control system
10 ECU±B10Cruise control system, Air
conditioning system, Power seat
system
11 RAD NO.120Audio system
12 HAZ10Emergency flashers, Turn signal
lights
13 AM230Starting system
No.FUSEAMPERECIRCUIT
14 TEL5Telephone
15
H±LP LH15Vehicles sold in the U.S.A.
Left±hand headlight (high beam)
15 H±LP
LH HI15Vehicles sold in Canada
Left±hand headlight (high beam)
16 ALT±S5Charging system
17
H±LP RH15Vehicles sold in the U.S.A.
Right±hand headlight (high beam)
17 H±LP RH HI15Vehicles sold in Canada
Right±hand headlight (high beam)
18 EFI15Multiport fuel injection
19 HORN10Theft deterrent system
20 RDI FAN30Electronic cooling fan system
21 CDS30Air conditioning system
22 A/C10No circuit
23 S±HTR20Seat heater system
24 HTR10Air conditioning system
25 GAUGE10
Gauges and meters, service reminder
indicators and warning buzzers, Back±up
light, Door courtesy light, Seat heater, Power
window system
26 WIP20Windshield wipers and washer

ELECTRICAL COMPONENTS
218
No.FUSEAMPERECIRCUIT
27 M/HTR10Outside rear view mirror defogger
28 ECU±IG15
Cruise control system, Anti±lock brake
system, Shift lock system, Power antenna,
Theft deterrent system, Electronic modulated
suspension, Wireless remote control
29 IGN5SRS, Multiport fuel injection
30 STOP15
Stop lights, High mounted stoplight, Cruise
control system, Electronic modulated
suspension, Anti±lock brake system, Shift
lock system, Power seat system, Multiport
fuel injection
31 TAIL10Tail light, Side marker lights, License plate
lights
32 PWR
OUTLET15Power outlet
33 OBD7.5On±board diagnosis system
34 FOG15Fog lights
35 ST5Starting system
36 DOOR25Door courtesy light, Theft deterrent system,
Power door lock system, Trunk lid opener,
Fuel filler door opener
No.FUSEAMPERECIRCUIT
37 PANEL7.5Instrument panel lights, Glovebox light
38 TURN7.5Emergency flashers, Turn signal lights
39 RAD NO.27.5Audio system
40 CIG15Cigarette lighter, Clock, SRS
41 DEF40Rear window defogger, Outside rear view
mirror defogger
42 PWR30Power window, Electronic moon roof, Power
seat system
43 AM140No circuit
SPARESpare fuse

BODY239
Air Conditioning Control Panel, Car Audio, Instrument
Panel, Console Panel, and Switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then lightly wipe off any
dirt.
NOTICE

Do not use organic substances (solvents, kerosene, alcohol, gasoline,
etc.) or alkaline or acidic solutions. These chemicals can cause
discoloring, staining or peeling of the surface.

If you use cleaners or polishing agents, make sure their ingredients do
not include the substances mentioned above.

If you use a liquid car freshener, do not spill the liquid onto the
vehicle's interior surfaces. It may contain the ingredients mentioned
above. Immediately clean any spill using the method mentioned
above.
If you have any questions about the cleaning of your Lexus, your local
Lexus dealer will be pleased to answer them.
