Lexus ES300 1998 s (in English) Owner's Guide

KEYS AND DOORS13
If the remote control features do not function correctly, or do not operate from
a normal distance, the battery may have been consumed. Contact your Lexu\
s
dealer.
For vehicles sold in U.S.A.
FCC ID: HYQ1512P MADE IN JAPAN
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
CAUTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
For vehicles sold in Canada
This device complies with RSS±210 of Industry and Science Canada.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
DOORS
Locking with key
11L026

1 Lock 2Unlock
Turn the key towards the front of the vehicle to lock and towards the back
to unlock.
The doors lock and unlock simultaneously with either front door. In the
driver's door lock, turning the key once will unlock the driver's door and twice
in succession will unlock all doors simultaneously. In the passenger's door
lock, turning the key once will unlock all doors simultaneously.

KEYS AND DOORS
14
Locking with inside lock button
11E004

1Lock 2Unlock
Push in the lock button to lock and unlock the door.
When locked, the door cannot be opened with either the outside or inside door\
handle.
Closing the door with the lock button pushed in will also lock the door. Be
careful not to lock your keys in the vehicle. The door will not lock if the ke\
y
is left in the ignition switch when closing the front doors.
CAUTION
Before driving, make sure the doors are closed and locked,
especially when small children are in the vehicle. Along with
the proper use of seat belts, locking the doors helps prevent the
driver and passengers from being thrown out from the vehicle
during an accident. It also helps prevent the doors from being
opened unintentionally.
Locking with power door lock switch
11E005±1

1 Lock 2Unlock
To lock all the doors simultaneously, push the power door lock switch on
the front side. Pushing on the rear side will unlock them.
The same switch is also equipped on the front passenger's side.

KEYS AND DOORS15
Locking with rear door child±protector
11E006±2

1Lock 2Unlock
Whenever small children are in the vehicle, lock the rear door so that it
does not open from the inside. To do this, move the knob to the lock
position as shown on the label next to the knob.

SECTION 1 ± 2
16
INSTRUMENTS AND CONTROLS
Switches
Headlight switch17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . Headlight dimmer and turn signal switch
. . . . . . . . . . . . . . . . . . . . 18
Fog light switch19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Windshield wiper and washer switch 20
. . . . . . . . . . . . . . . . . . . . . . . Rear window and outside rear view mirror
defogger switch
22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Power window switches 23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat heater switches 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \

SWITCHES17
HEADLIGHT SWITCH
12E001±1
To turn the lights on, twist the knob on the end of the lever.
FIRST CLICKSTOP: Only the parking, tail, license plate, side marker and
instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (ºAUTOº): The headlights and all other lights
automatically turn on depending on the darkness of the surroundings.
Vehicles sold in U.S.A.: When the headlights are on, the headlight indicator
lights up in the instrument cluster.
Vehicles sold in Canada: When the tail lights are on, the tail light indicator
lights up in the instrument cluster. Manually twist the knob to the second clickstop to turn on the headlights
if they are needed immediately when entering a dark tunnel, parking
structure, etc.
When the headlight switch is turned to the first or second clickstop, the
brightness of the instrument cluster will be reduced slightly unless the
instrument panel light control knob is turned fully on.
12E002
The automatic light control sensor is on top of the driver's side instrument
panel.
Do not place anything on the instrument panel, and/or do not affix anything
on the windshield to block this sensor.
The lights automatically turn off when the driver's door is opened with the
ignition
key turned to the ºACCº or ºLOCKº position. To turn them on again,
turn the ignition key to the ºONº position, or turn the headlight switc\
h off and
then twist the knob until the first or second clickstop. If you are going to park
for over one week, make sure the headlight switch is off.

SWITCHES
18
Daytime Running Light System (Canada only)
The headlights turn on when the parking brake is released with the engine
started,
even with the light switch in the ºOFFº position. They will not g\
o off
until the ignition switch is turned off.
To turn on the other exterior lights and instrument panel lights, twist th\
e knob
to the first clickstop.
Under the daytime running light system, the headlights turn on at reduced
intensity. Twist the knob to the second clickstop to turn to full intensity for
driving at night.
When setting the knob to the third clickstop (ºAUTOº), the headlights will
automatically adjust to full intensity and/or turn on the other lights depending
on the darkness of the surroundings. Likewise, as the surroundings become\
brighter, the headlights will turn to reduced intensity, ultimately turning off
the other lights.
NOTICE
To prevent the battery from being discharged, do not leave the lights on
longer than necessary when the engine is not running.
HEADLIGHT DIMMER AND TURN SIGNAL SWITCH
12E003±1
For high beam, push the lever forward. Pull it back for low beam. For
the headlight flasher, pull it further back.
A blue light in the instrument cluster indicates high beam or headlight f\
lasher
is on.
The headlight flasher works even when the headlight switch is off.

SWITCHES19
12E004±1
For signaling turns, move the lever up or down in the conventional
manner.
The ignition key must be in the ºONº position.
The turn signal is self±cancelling after a turn, but after a lane change\
, you may
have to cancel it by hand. You can also signal a lane change by moving the
turn signal lever partway and holding it there.
If the green light in the instrument cluster flashes faster than normal, it
indicates that the front or rear turn signal bulb has burned out. If this indicator
light does not come on, the fuse or the indicator light itself has probably failed.
FOG LIGHT SWITCH
12E005±1
To turn on the fog lights, turn the switch to the ºONº position. Th\
e fog
lights come on only when the headlights are on low beam.

SWITCHES
20
WINDSHIELD WIPER AND WASHERSWITCH
12E006

1Interval adjuster 2Washer on
To turn the wipers on, move the lever down until you reach the desired
speed setting.
The ignition key must be in the ºONº position.
There are 3 settings: ºINTº position: Intermittent operation
ºLOº position: Low speed operation
ºHIº position: High speed operation
Twist the interval adjuster upward to increase the wiping time interval
between sweeps, and downward to decrease it.
The wiper lever must be in the ºINTº position. To make the washer squirt, pull the lever toward you and release it.
Also, the wipers will automatically operate a couple of times after the washe\
r
squirts even with the lever in the ºOFFº position.
The low washer fluid warning light in the instrument cluster comes on when
the fluid level in the tank becomes nearly empty. For information on adding
washer fluid, see ºAdding washer fluidº on page 227.
In cold weather, warm the windshield with the defroster before using the
washer. This will help prevent icing, which could block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the glass.

SWITCHES21
Shifting the windshield wiper position
12E027±1

1Rest position 2Retracted position
The wiper blades retract under the hood when the wipers are turned off. If
retraction is obstructed by snow, etc., at the bottom of the windshield, the
wipers should be shifted from the retracted position to the rest position abov\
e
the hood level. When the snow season is over, manually return the wipers to
the retracted position following the procedure given below.
12E028±2
To shift the windshield wipers from retracted to rest position, hold the
connection of the wiper arm and wiper blade and pull it upward along the
windshield glass.
NOTICE
To prevent the wiper blades from being deformed, be sure to hold the
connection of the wiper arm and wiper blade securely.
12E029±1
To return the windshield wipers to retracted position, push the
connection of the wiper arm and wiper blade downward.
NOTICE
To prevent the wiper blades from being deformed, be sure to hold the
connection of the wiper arm and wiper blade securely.

SWITCHES
22
REAR WINDOW AND OUTSIDE REARVIEW MIRROR DEFOGGER SWITCH
12E011±1
To turn the electric rear window and outside rear view mirror defogger
on, push the switch.
The ignition key must be in the ºONº position.
The thin heater wires on the inside of the rear window and the heater pa\
nels
in the outside rear view mirrors will quickly clear the surface. An ind\
icator
light is on when the defogger is operating.
The system will automatically shut off when the defogger has operated about
15 minutes.
CAUTION
Since the mirror surfaces can get hot, keep your hands off
them when the switch is on.
If further defrosting or defogging is desired, simply actuate the switch\
again.
When the surface has cleared, push the switch once again to turn the defogge\
r
off. Continuous use may cause the battery to discharge, especially during
stop±and±go driving. The rear window defogger is not designed to dry rain
water or to melt snow.
If the outside rear view mirrors are heavily coated with ice, use a spray d\
e±icer
before operating the switch.
NOTICE
 When cleaning the inside of the rear window, be careful not to scratch
or damage the heater wires.
 To prevent the battery from being discharged, do not operate the
defogger continuously longer than necessary.
