A84917
64 (653, 47)
64 (653, 47)
Front Fender Apron
Seal RH
Vane Pump V Belt
V Belt No. 1
Generator Bracket No. 2
Engine Mounting Stay No. 2 RHEngine Moving Control Rod
23 (235, 17)
58 (591, 43)
28 (286, 21)
N´m (kgf´cm, ft´lbf)
: Specified torque
Exhaust Pipe
Assy Front
Exhaust Pipe No. 1
Support Bracket Front
Exhaust Pipe Gasket
Non-reusable part
33 (337, 24)
56 (571, 41)
33 (337, 24)
Exhaust Pipe No. 1
Support Bracket Rear
Exhaust Pipe
Gasket
Exhaust Pipe Gasket
62 (633, 46)
62 (633, 46)
Radio Setting Condenser
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
14-1 15
2207 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
Page 492 of 969
A78383
N´m (kgf´cm, ft´lbf)
: Specified torque
8.5 (87, 75 in.Vlbf)
220 (2,250, 162)
8.5 (87, 75 in.Vlbf)
28 (286, 21)
27 (280, 20)
Timing Belt Tensioner Assy Crankshaft PulleyTiming Belt No. 1 Cover
Timing Belt Guide No. 2
Engine Mounting Bracket RH Timing Belt No. 2 Cover
Timing Belt
Engine Wire
Protector
14-1 16
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
2208 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
Page 493 of 969
A78384N´m (kgf´cm, ft´lbf)
: Specified torque
8.5 (87, 75 in.Vlbf)
43 (438, 32)
Timing Belt Idler
Sub-assy No. 2x6Timing Belt No. 3 Cover
CollarGasket
Bushing
Camshaft Timing Pulley
125 (1,275, 92)
Engine Wire
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
14-1 17
2209 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
Page 494 of 969
A84918
N´m (kgf´cm, ft´lbf)
: Specified torque
Non-reusable part Exhaust Manifold to Head Gasket
43 (439, 32)
Exhaust Manifold Heat Insulator No. 1
Exhaust Manifold Sub-assy RH
Vane Pump Assy
43 (439, 32)
8.5 (87, 75 in.Vlbf)
49 (500, 36)
x3
x6 14-1 18
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
2210 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
Page 495 of 969
A78390
Camshaft Bearing Cap No. 2
Camshaft Bearing Cap No. 3
Camshaft Bearing Cap No. 6
Camshaft Bearing Cap No. 5
16 (163, 12)
x10
Camshaft
8.0 (80, 71 in.Vlbf)
8.4 (85, 74 in.Vlbf)
8.0 (80, 71 in.Vlbf)
16 (163, 12)
Ignition Coil AssyEngine Wire
Engine Wire
Cylinder Head Cover Gasket Cylinder Head Cover Sub-assy
Camshaft Bearing
Cap No. 2
x10Camshaft Bearing Cap No. 4
Camshaft Bearing Cap No. 2
No. 2 CamshaftCamshaft Bearing Cap No. 1
N´m (kgf´cm, ft´lbf)
: Specified torque
Non-reusable part Camshaft Setting
Oil Seal
19 (189, 14)
Cylinder Head GasketCylinder Head Sub-assy
1st: 54 (550, 40)
2st: Turn 90 See page 14-120
x9
x8
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
14-1 19
2211 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
Page 496 of 969
141JH-01
A86571
14-120
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
2212 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See page 11-1)
2. DISCONNECT BATTERY NEGATIVE TERMINAL
3. DRAIN ENGINE COOLANT (See page 16-9)
4. DRAIN ENGINE OIL (See page 17-20)
5. REMOVE FRONT WHEEL RH
6. REMOVE FRONT SUSPENSION UPPER BRACE CENTER (W/O TEMS) (See page 10-1 1)
7. REMOVE V-BANK COVER SUB-ASSY (See page 10-1 1)
8. REMOVE AIR CLEANER CAP SUB-ASSY (See page 10-1 1)
9. REMOVE EMISSION CONTROL VALVE SET (See page 11-13)
10. REMOVE INTAKE AIR SURGE TANK (See page 11-13)
11. REMOVE INTAKE MANIFOLD (See page 10-16)
12. REMOVE WATER OUTLET (See page 10-16)
13. REMOVE FRONT FENDER APRON SEAL RH
14. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See page 14-5)
15. REMOVE VANE PUMP V BELT (See page 14-5)
16. REMOVE ENGINE MOVING CONTROL ROD (See page 14-79)
17. REMOVE ENGINE MOUNTING STAY NO.2 RH (See page 14-79)
18. REMOVE GENERATOR BRACKET NO.2 (See page 14-79)
19. REMOVE CRANKSHAFT PULLEY (See page 14-79)
SST 09213-54015 (91651-60855), 09330-00021, 09950-50013 (09951-05010, 09952-05010,
09953-05020, 09954-05031)
20. REMOVE TIMING BELT NO.1 COVER
21. REMOVE TIMING BELT NO.2 COVER (See page 14-79)
22. REMOVE ENGINE MOUNTING BRACKET RH (See page 14-79)
23. REMOVE TIMING BELT GUIDE NO.2
24. REMOVE TIMING BELT (See page 14-79)
25. REMOVE TIMING BELT IDLER SUB-ASSY NO.2
26. REMOVE CAMSHAFT TIMING PULLEY (See page 14-93)
SST 09960-10010 (09962-01000, 09963-01000), 09249-63010
27. REMOVE TIMING BELT NO.3 COVER (See page 14-93)
28. SEPARATE VANE PUMP ASSY
29. REMOVE EXHAUST PIPE NO.1 SUPPORT BRACKET FRONT (See page 15-2)
30. REMOVE EXHAUST PIPE NO.1 SUPPORT BRACKET REAR (See page 15-2)
31. REMOVE EXHAUST PIPE ASSY FRONT (See page 15-2)
32. REMOVE EXHAUST MANIFOLD HEAT INSULATOR
NO.1
(a) Disconnect the air fuel ratio sensor connector.
(b) Remove the 3 bolts and exhaust manifold heat insulator.
Page 497 of 969
A86572
1
542
36
A78401
A78716
Front
A78717
Front
1
23
8
7
6
5
4
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
14-121
2213 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
33. REMOVE EXHAUST MANIFOLD SUB-ASSY RH
(a) Using several steps, loosen and remove the 6 nuts in the
sequence shown in the illustration.
(b) Remove the exhaust manifold RH and gasket from the
cylinder head RH.
34. REMOVE IGNITION COIL ASSY
35. REMOVE CYLINDER HEAD COVER SUB-ASSY (See page 14-7)
36. REMOVE CAMSHAFT (See page 14-93)
37. REMOVE NO.2 CAMSHAFT (See page 14-93)
38. REMOVE CYLINDER HEAD SUB-ASSY
(a) Disconnect the VVT sensor connector.
(b) Disconnect the camshaft timing oil control valve connec-
tor.
(c) Remove the nut, then disconnect the engine wire harness
clamp.
(d) Using a socket hexagon wrench 8, remove the hexagon
bolt.
(e) Using several steps, loosen the 8 cylinder head bolts uni-
formly in the sequence shown in the illustration. Remove
the 8 cylinder head bolts and plate washers.
NOTICE:
Be careful not to drop the washers into the cylinder
head.
Head warpage or cracking could result from remov-
ing the bolts in an incorrect order.
39. REMOVE CYLINDER HEAD GASKET
Page 498 of 969
A78721
Tension Portion
A78324
Front
A78717
1
2
3
4
5
67
8
Front
A78730
90
Front
Painted Mark 14-122
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
2214 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
40. INSPECT CYLINDER HEAD SET BOLT
(a) Using vernier calipers, measure the tension portion diam-
eter of the bolt.
Standard outside diameter:
8.95 to 9.05 mm (0.3524 to 0.3563 in.)
Minimum outside diameter: 8.75 mm (0.3445 in.)
If the diameter is less than minimum, replace the bolt.
41. INSTALL CYLINDER HEAD GASKET
(a) Place a new cylinder head gasket on the cylinder block
with the R mark upward.
NOTICE:
Remove any oil from the contact surface.
Be careful of the installing orientation.
Place the cylinder head on the gasket carefully in or-
der not to damage the gasket at the bottom part of the
head.
42. INSTALL CYLINDER HEAD SUB-ASSY
NOTICE:
The cylinder head bolts are tightened in 2 successive
steps.
(a) Apply a light coat of engine oil to the threads of the cylin-
der head bolts.
(b) Install the plate washers to the cylinder head bolts.
(c) Using several steps, install and tighten the 8 cylinder
head bolts uniformly in the sequence shown in the illustra-
tion.
Torque: 54 NVm (550 kgfVcm, 40 ftVlbf)
(d) Mark the front side of each cylinder head bolt head with
paint as shown in the illustration.
(e) Retighten the cylinder head bolts by 90in the same se-
quence as step (c).
(f) Check that each painted mark is now at a 90 angle to the
front.
Page 499 of 969
A78716
Front
A86572
6
235
41
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
14-123
2215 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(g) Using a socket hexagon wrench 8, install the hexagon
bolt.
Torque: 19 NVm (189 kgfVcm, 14 ftVlbf)
(h) Connect the engine wire harness clamp with the nut.
Torque: 8.4 NVm (85 kgfVcm, 74 in.Vlbf)
43. INSTALL NO.2 CAMSHAFT (See page 14-93)
44. INSTALL CAMSHAFT (See page 14-93)
45. INSTALL CYLINDER HEAD COVER SUB-ASSY (See page 14-7)
46. INSTALL IGNITION COIL ASSY (See page 14-7)
47. INSTALL EXHAUST MANIFOLD SUB-ASSY RH
(a) Install a new gasket and the exhaust manifold RH with the
6 nuts. Using several steps, tighten the nuts uniformly in
the sequence shown in the illustration.
Torque: 49 NVm (500 kgfVcm, 36 ftVlbf)
(b) Retighten nuts 1 and 2 shown in the illustration.
48. INSTALL EXHAUST MANIFOLD HEAT INSULATOR NO.1
Torque: 8.5 NVm (87 kgfVcm, 75 ftVlbf)
49. INSTALL EXHAUST PIPE ASSY FRONT (See page 15-2)
50. INSTALL EXHAUST PIPE NO.1 SUPPORT BRACKET REAR (See page 15-2)
51. INSTALL EXHAUST PIPE NO.1 SUPPORT BRACKET FRONT (See page 15-2)
52. INSTALL VANE PUMP ASSY (See page 14-29)
53. INSTALL TIMING BELT NO.3 COVER (See page 14-93)
54. INSTALL CAMSHAFT TIMING PULLEY (See page 14-93)
SST 09960-10010 (09962-01000, 09963-01000), 09249-63010
55. INSTALL TIMING BELT IDLER SUB-ASSY NO.2 (See page 14-93)
56. INSPECT TIMING BELT (See page 14-79)
57. INSTALL TIMING BELT (See page 14-79)
SST 09960-10010 (09962-01000, 09963-01000)
58. INSTALL TIMING BELT TENSIONER ASSY (See page 14-79)
59. INSTALL TIMING BELT GUIDE NO.2 (See page 14-79)
60. INSTALL ENGINE MOUNTING BRACKET RH (See page 14-79)
61. INSTALL TIMING BELT NO.2 COVER (See page 14-79)
62. INSTALL TIMING BELT NO.1 COVER (See page 14-79)
63. INSTALL CRANKSHAFT PULLEY (See page 14-79)
SST 09213-54015 (91651-60855), 09330-00021
64. INSTALL GENERATOR BRACKET NO.2 (See page 14-79)
65. INSTALL ENGINE MOUNTING STAY NO.2 RH (See page 14-79)
66. INSTALL ENGINE MOVING CONTROL ROD (See page 14-79)
67. INSTALL VANE PUMP V BELT (See page 14-5)
Page 500 of 969
14-124
- ENGINE MECHANICALCYLINDER HEAD GASKET (3MZ-FE)
2216 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
68. INSTALL V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See page 14-5)
69. INSPECT DRIVE BELT DEFLECTION AND TENSION (See page 14-1)
70. INSTALL WATER OUTLET (See page 10-16)
71. INSTALL INTAKE MANIFOLD (See page 10-16)
72. INSTALL INTAKE AIR SURGE TANK (See page 11-13)
73. INSTALL EMISSION CONTROL VALVE SET (See page 11-13)
74. INSTALL AIR CLEANER CAP SUB-ASSY (See page 10-1 1)
75. CHECK CONNECTION OF VACUUM HOSE (See page 14-29)
76. INSTALL V-BANK COVER SUB-ASSY (See page 10-1 1)
77. INSTALL FRONT SUSPENSION UPPER BRACE CENTER (W/O TEMS) (See page 10-1 1)
78. INSTALL FRONT WHEEL RH (See page 14-5)
79. ADD ENGINE OIL (See page 17-20)
80. ADD ENGINE COOLANT (See page 16-9)
81. CHECK FOR ENGINE OIL LEAKS
82. CHECK FOR ENGINE COOLANT LEAKS (See page 16-1)
83. INSPECT FOR FUEL LEAKS
84. CHECK FOR EXHAUST GAS LEAKS
85. INSPECT IGNITION TIMING (See page 14-1)
SST 09843-18040
86. INSPECT ENGINE IDLE SPEED (See page 14-1)
87. INSPECT COMPRESSION (See page 14-1)
SST 09992-00500
88. INSPECT CO/HC (See page 14-1)
89. SYSTEM INITIALIZATION (See page 19-15)
