Lexus ES300h 2015 Navigation Manual

360
1. LEXUS ENFORM-OVERVIEW
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
3. TYPE B: FUNCTION ACHIEVED BY USING DCM AND THE NAVIGATION SYSTEM
The functionality of Lexus Enform Safety Connect, Lexus Enform Destinations, and
Lexus Insider is made possible through the shared work of the DCM and the naviga-
tion system.
These are subscription-based telematics services that use Global Positioning System
(GPS) data and embedded cellular technology to provide safety and security as well
as convenience features.
These services are available by subscription on select, telematics hardware-equipped
vehicles and supported by Lexus’ designated response center, which operates 24
hours a day, 7 days a week.
No.Name
Lexus’ designated response center
TEL, GPS antenna
DCM
Navigation system

361
1. LEXUS ENFORM-OVERVIEW
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
LEXUS ENFORM
9
zAfter you have signed the Telematics Sub-
scription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms are a va il -
able. Contact your Lexus dealer, call
1-800-25-LEXUS (1-800-255-3987),
or select “Destination Assist” in your vehi-
cle for further subscription details.
( → P.375)
z Destinations is available in the contiguous
United States, Washington D.C. and limited
areas of Alaska for vehicles that contain the
appropriate map data.
z Lexus Insider is available in the contiguous
United States, Wash ington D.C. and
Alaska. z
Enrollment in Lexus Enform Safety Con-
nect (via your dealership) is required to
activate all functions.
BEFORE USING THE
FUNCTION
SUBSCRIPTION
AVAILABILITY OF
FUNCTION(S)
ACTIVATION OF
FUNCTION(S)
zCertification for Lexus Enform Safety
Connect
FCC WARNING
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment and meets
the FCC radio frequency (RF)
Exposure Guidelines in Supplement C
to OET65.
This equipment should be installed and
operated keeping the radiator at least
20cm or more away from person’s
body (excluding extremities: hands,
wrists, feet and ankles).
FCC ID: O6Y-CDMRF101
FCC ID: XOECDMRF101B
FCC ID: N7NGTM2

362
1. LEXUS ENFORM-OVERVIEW
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
INFORMATION
●Exposure to radio frequency signals:
The Lexus Enform system installed in
your vehicle includes a low power radio
transmitter and receiver. The system
receives and also sends out radio fre-
quency (RF) signals.
● In August 1996, the Federal Communi-
cations Commission (FCC) adopted RF
exposure guidelines with safety levels for
mobile wireless phones. Those guidelines
are consistent with the safety standards
previously set by both U.S. and interna-
tional standards bodies.
• ANSI (American National Standards
Institute) C95.1 [1992]
• NCRP (National Council on Radiation Protection and Measurement) Report
86 [1986]
• ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]
● These standards are based on compre-
hensive and periodic evaluations of the
relevant scientific literature. Over 120
scientists, engineers, and physicians from
universities, government health agen-
cies, and industry reviewed the available
body of research to develop the ANSI
Standard (C95.1).
● The design of Lexus Enform system com-
plies with the FCC guidelines in addition
to those standards.
INFORMATION
●Available beginning Fall 2009 on select
Lexus models. Contact with the Lexus
response center is dependent upon the
telematics device being in operative con-
dition, cellular connection availability,
navigation map data, and GPS satellite
signal reception, which can limit the abil-
ity to reach the response center or
receive support. Enrollment and Telemat-
ics Subscription Service Agreement
required. A variety of subscription terms
are available; charges vary by subscrip-
tion term selected.
● The Lexus response center offers sup-
port in multiple languages.
● Select Lexus Enform Safety Connect-
subscribed vehicles are capable of com-
municating vehicle information. Please
see the terms and conditions for addi-
tional details.
Owners who do not wish to have their
vehicle transmit this information can opt
out at the time of enrollment or by calling
1-800-255-3987 and following the
prompts for Lexus Enform Safety Con-
nect.
● For further details about the service, con-
tact your Lexus dealer.
● Lexus Enform functions are not subject to
section 255 of the Telecommunications
Act and the system is not TTY compati-
ble.

363
1. LEXUS ENFORM-OVERVIEW
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
LEXUS ENFORM
9
4. TYPE C: FUNCTION ACHIEVED BY USING DCM
The functionality of Lexus Enform Safety Connect is made possible by the use of a
DCM.
For details, refer to “Owner’s Manual”.

364
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
2. LEXUS ENFORM OPERATION
1. LEXUS Enform Remote
zAfter you sign the Telematics Subscription Service Agreement (see the LEXUS Enform
Safety Connect section in “Owner’s Manual”), download the LEXUS Enform Remote
app from your cellular phone’s app store, and register within the app (or enroll and com-
plete registration at the dealer), you can begin using these services.
z A variety of subscription terms are available. Contact your Lexus dealer, or call
1-800-25-LEXUS (1-800-255-3987) for further subscription details.
z Lexus Enform Remote is available in the co ntiguous United States, Washington D.C.,
and Alaska.
For details about the functions and services provided by this app, refer to
http://www.lexus.com/enform/
.
SUBSCRIPTION
AVAILABILITY OF FUNCTION
INFORMATION
● Lexus Enform Remote should only be used by authorized users.
● Laws in some communities may require that the vehicle be within view of the user when
operating Lexus Enform Remote.
In some states, use of Lexus Enform Remote may violate state or local laws. Before using
Lexus Enform Remote, check your state and local laws.
● Any malfunction of the Lexus should be repaired by your Lexus dealer.
● Lexus Enform Remote is designed to work at temperatures above -22 °F (-30 °C). This
specification is related to the Lexus Enform Remote operation, but is dependent on the
vehicle’s operating temperature range which may be different.
● Content is subject to change without notice.
● Some features of the Lexus Enform Remote may not be available on some models.
● Additional information can be found at www.lexus.com/enform/
.

365
2. LEXUS ENFORM OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
LEXUS ENFORM
9
2. LEXUS App Suite
1Press the “MENU” button on the
Remote Touch.
2Select “LEXUS App Suite” .
3Select the desired application screen
button.USING LEXUS App Suite
App Suite is a function that enables ap-
plicable apps installed on a cellular
phone to be displayed on and operated
from the navigation screen. Before App
Suite can be used, a few settings need to
be performed. (→P.359)
For details about the functions and ser-
vices provided by each application, re-
fer to http://www.lexus.com/enform/
.No.FunctionPage
Select to activate an appli-
cation.
Select to update the appli-
cations.366
Select to change the order
of the applications.368
Displays the number of new
notifications for the appli-
cation


366
2. LEXUS ENFORM OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
■DOWNLOADING UPDATE
1Select “Update” .
2Check that downloading starts.
“Download in Background” : Select to op-
erate other functions while downloading.
“Cancel” : Select to cancel updating.
3Check that downloading is complete.
X From the “Update” screen
X From other screensUPDATING AN APPLICATION
When App Suite is activated, an applica-
tion may need to be updated. By updat-
ing the application, it can be kept to the
latest version. To update an application,
it is necessary to download update data
and install it.
If an update is available, “Update” can
be selected.
No.Function
Select to install later. When this
screen button is selected, the screen
will return to the last displayed
screen. To install the update data:
→ P.367
Select to display detailed informa-
tion on the update data.
Select to install the update data. Fol-
low the steps “INSTALLING THE
UPDATE DATA” from “STEP 2”.
(→ P.367)

367
2. LEXUS ENFORM OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
LEXUS ENFORM
9
■INSTALLING THE UPDATE DATA
1Select “Install” .
2Select “Continue” .
“Later” : Select to postpone the installation
of the update data and go back to the previ-
ous screen.
3Check that installing is started.
“Install in Background” : Select to operate
other function while installing.
4Select “OK” after the installing is com-
plete.
After the downloading is complete,
“Update” will be changed to “Install”.
INFORMATION
●The App Suite function cannot be oper-
ated while installing.

368
2. LEXUS ENFORM OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
1Display the “LEXUS App Suite” screen.
(→ P.365)
2Select “Reorder” .
3Select the desired application to be
moved.
4Select “<<” or “>>” to move the applica-
tion, and select “OK”.
REORDERING THE
APPLICATIONS
Order of the applications can be
changed.

369
2. LEXUS ENFORM OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
LEXUS ENFORM
9
IF A MESSAGE APPEARS ON THE SCREEN
When problems occur with starting the application player, a message will appear on
the screen. Referring to the table below, identify the problem and take the suggested
corrective action.
MessageDisplay conditionsCorrective action
“This feature is unavailable
during an emergency call.”Safety Connect is being im-
plemented.After the Safety Connect call
is finished, perform the opera-
tion again.
“This feature is unavailable
while transferring contacts.”Contacts are being trans-
ferred manually from the
phonebook.When the transfer of contacts
is complete, perform the op-
eration again.
“Unable to connect to a
Bluetooth* phone. For trou-
bleshooting assistance,
please visit the Lexus website
or contact your dealer.”
The cellular phone cannot be
connected.
Refer to http://
www.lexus.com/enform/ to
confirm if the phone is com-
patible or not.
“This feature is unavailable
during a handsfree call.”A hands-free call is in
progress.After the hands-free call is fin-
ished, perform the operation.
“To use the services, an active
application needs to be run-
ning on your phone. For more
information, please visit
lexus.com.”The LEXUS App Suite appli-
cation cannot be connected
to Bluetooth
® SPP.
Refer to http://www.lexus.com/enform/ to
confirm if the phone is
Bluetooth
® SPP compatible
or not, and then activate the
App Suite application.
“Communication error.
Please try again.”Communication was discon-
nected.After a few moments, retry the
operation.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
