Lexus ES350 2016 Quick Guide / LEXUS 2016 ES350 OWNERS MANUAL QUICK GUIDE (OM33B82U)

90
ES350_QG_OM33B82U_(U)
Trunk Storage Extension
Fold down the armrest.
Fold down the handle and open the
armrest door.
Long objects can be loaded into the vehicle by utilizing the trunk space and rear
seat area.
1
2

91
ES350_QG_OM33B82U_(U)
Garage Door Opener
nProgramming HomeLink®
The HomeLink® wireless control system in your vehicle has 3 buttons which can be
programmed to operate 3 di fferent devices. Refer to the programming methods on
the following pages to determine the method which is appropriate for the device.
HomeLink
® indicator light
Garage door operation indicators
HomeLink
® icon
Illuminates while HomeLink
® is
operating.
Buttons
n Programming HomeLink®
Press and release the HomeLink® button you want to program and check that
the HomeLink
® indicator light flashes (orange).
Perform within 60 seconds of , or the indicator light will stop flashing and
programming will not be able to be completed.
Point the remote control transmitter
for the device at the rear view mir-
ror, 1 to 3 in. (25 to 75 mm) from
the HomeLink
® buttons.
Keep the HomeLink
® indicator
light in view while programming.
For U.S.A. owners Press and hold the handheld trans-
mitter button until the HomeLink
®
indicator light changes from slowly
flashing orange to rapidly flashing
green (rolling code) or continu-
ously lit green (fixed code), then
release the button.
The garage door opener can be programmed to operate garage doors, gates, entry
doors, door locks, home lighting systems, security systems, and other devices.
1
2
3
4
1
31
2
3

92
ES350_QG_OM33B82U_(U)
Programming an entry gate (for U.S.A. owners)/Programming a device in the
Canadian market
Press and release the remote control transmitter button at 2 second intervals,
repeatedly, until the HomeLink
® indicator light changes from slowly flashing
(orange) to rapidly flashing (green) (rolling code) or continuously lit (green)
(fixed code).
Test the HomeLink
® operation by pressing the newly programmed button and
observing the indicator light:
l Device with fixed code: If the indicator light is solid/continuous, program- ming has been completed and your garage door or other device should oper-
ate when the HomeLink
® button is pressed and released.
l Device with rolling code: If the indicator light flashes rapidly, your garage door opener motor (or other device) is equipped with a rolling code. Com-
plete the programming process by firmly pressing and holding the pro-
grammed HomeLink
® button for 2 seconds and then release the button.
l If the garage door or other device doe s not operate, proceed to “Program-
ming a rolling code system”.
Repeat the steps above to program an other device for any of the remaining
HomeLink
® buttons.
n Programming other devices
For U.S.A. owners:
To program an entry gate, see the OWNER’S MANUAL.
To program other devices, contact your Lexus dealer.
For Canadian owners: To program all other devices, follow the same procedure as for garage door pro-
gramming.
n Operating HomeLink®
Press the appropriate HomeLink® button. The HomeLink® indicator light should
turn on.
3
4
5

93
ES350_QG_OM33B82U_(U)
LEXUS Enform Safety Connect
(for U.S.A., if equipped)
nSystem components
“SOS” button
LED light indicators
Microphone
Safety Connect is a subscription-based te lematics service that uses Global Posi-
tioning System (GPS) data and embedded cellular technology to provide safety
and security features to s ubscribers. Safety Connect is supported by Lexus’ des-
ignated response center, which operates 24 hours per day, 7 days per week.
Safety Connect service is available by subscription on select, telematics hard-
ware-equipped vehicles.
1
2
3

94
ES350_QG_OM33B82U_(U)
nServices
Subscribers have the following Sa fety Connect services available:
l Automatic Collision Notification
*
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the resp onse center. The responding agent receives
the vehicle’s location and attempts to sp eak with the vehicle occupants to assess
the level of emergency. If the occupant s are unable to communicate, the agent
automatically treats the call as an emergency, contacts the nearest emergency ser-
vices provider to describe the situation, an d requests that assistance be sent to the
location.
*: U.S. Patent No. 7,508,298 B2
l Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to assist
them in locating and recovering the vehicl e. After filing a police report, call the
Safety Connect response center at 1-800-25-LEXUS (1-800-255-3987) and fol-
low the prompts for Safety Connect to initiate this service.
In addition to assisting law enforcemen t with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circum-
stances, be shared with third parties to locate your vehicle. Further information is
available at Lexus.com.
l Emergency Assistance Button (SOS)
In the event of an emergency on the ro ad, push the “SOS” button to reach the
Safety Connect response center. The answering agent will determine your vehi-
cle’s location, assess the emergency, and dispatch the necessary assistance
required. If you accidentally press the “SOS” button, tell the response-center agent that
you are not experiencing an emergency.
l Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GPS da ta to the already included warranty-
based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-cen-
ter agent, who can help with a wide range of needs, such as: towing, flat tire, fuel
delivery, etc. For a description of the Ro adside Assistance services and their lim-
itations, please see the Safety Connect Terms and Conditions, which are avail-
able at Lexus.com.
n Subscription
After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms are available. Contact your Lexus dealer, call 1-800-
25- LEXUS (1-800-255- 3987) or push the “SOS” button in your vehicle for further
subscription details.

95
ES350_QG_OM33B82U_(U)
LEXUS Enform (for U.S.A., if equipped)
nFunction achieved by using a cellular phone (with navigation system)
n
Services
Of the functions included with Lexus Enform, only LEXUS App Suite can be
achieved by using a cellular phone.
LEXUS App Suite is a service that enables the usable contents of a cellular phone to
be displayed on and operated from the navigation screen. Before LEXUS App Suite
can be used, a few settings need to be performed.
l LEXUS App Suite
When LEXUS App Suite is activated, an application may need to update. By
updating, an application can be kept the latest version. To updating the applica-
tion, it is necessary to download the updated data and install it.
nSubscription
LEXUS App Suite will be available on a trial period included upon purchase of a
new vehicle. User registration is required to start using the service.
When a trial period has elapsed after purchasing a new vehicle, a fee will be
charged to renew the contract. Services re quiring a separate contract can also be
used. For details, refer to http://www.lexus.com/enform/
or call 1-800-255-3987.
n Function achieved by using DCM and the navigation system
(with navigation system)
n
Services
Of the functions included with Lexu s Enform, LEXUS Enform Destinations
(Destination Assist, eDestination), and Le xus Insider can be achieved by making
DCM cooperate with the navigation system.
These are subscription-based telematics se rvices that use Global Positioning System
(GPS) data, embedded cellular technology to provide safety and security as well as
convenience features to subs cribers. The services are supported by Lexus’ desig-
nated response center, which operates 24 hours a day, 7 days a week.
The services are available by subscription on select, telematics hardware-equipped
vehicles.
Lexus Enform is a service that includes Safety Connect, Remote, Destinations,
Insider and App Suite.
For details, refer to the “OWNER’S MANUAL” and “NAVIGATION SYSTEM
OWNER’S MANUAL”.

96
ES350_QG_OM33B82U_(U)
lDestination Assist
Destination Assist provides you with live assistance for finding destinations via
the Lexus response center. You can request either a specific business, address, or
ask for help locating your desired destination by category, such as restaurants,
gas stations, shopping centers or other points of interest (POI).
After you tell the agent your choice of destination, its coordinates are sent wire-
lessly to your vehicle’s navigation system.
l eDestination
With the eDestination feature, you can go online, and via the Lexus.com owner’s
Web site, select and organize destinations of your choice and then wirelessly
send them to your vehicle’s navigation system.
Up to 200 locations can be stored onli ne and accessed or updated at any time.
Locations can be organized into up to 20 personalized folders.
You must first go online at www.lexus.com/drivers/
to view the Owners site
where you will need to register and log in. After this, personalized folders that
contain the locations to be sent to your vehicle can be created. (See Lexus
Enform Guide for more information.)
l Lexus Insider
Lexus Insider is an optional service that can send audio messages, or articles, to
participating owners’ vehicles via the navigation system. Potential Lexus Insider
subjects might include, for example, Lexus vehicle technology tips, updates on
regional Lexus events, or audio excer pts from Lexus Magazine articles.
nSubscription
After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services . A variety of subscription terms are
available.
Contact your Lexus dealer, call 1-800-25- LEXUS (1-800-255-3987), or select the
“Destination Assist” in your vehicle for further subscription details.
n Function achieved by using DCM
n
Services
Of the functions included with Lexus Enform Safety Connect, Safety Connect can
be achieved by using DCM.
l Lexus Enform Safety Connect ( →P.92)

97
ES350_QG_OM33B82U_(U)
nLEXUS Enform Remote
n
Services
Lexus Enform Remote is a cellular phone application that lets you view and
remotely control certain aspects of your vehicle.
For details about the functions and services of this application, refer to
http://www.lexus.com/enform/
. For further details, contact your Lexus dealer.
Function of the Lexus Enform Remote is achieved by using an embedded cellu-
lar device in the vehicle (DCM: Data Communication Module).
nSubscription
→ P. 9 5
XM Satellite Radio
nSubscription
For XM Services requiring a subscription (such as XM Radio), the following para-
graph shall be included.
Required XM Radio monthly subscription s sold separately after trial period.
Subscription fee is consumer only. All f ees and programming subject to change.
Subscriptions are subject to the Customer Agreement available at
www.siriusxm.com.
(U.S.A.) or www.xmradio.ca (Canada) XM service only
available in the 48 contiguous United States and 10 Canadian provinces.
For more information, program schedules, and to subscribe or extend subscription
after complimentary trial period; more information is available at:
U.S.A. Customers:
Visit www.siriusxm.com
or call 1-877-515-3987
Canadian Customers:
Visit www.xmradio.ca
or call 1-877-438-9677
An XM Satellite Radio is a tuner designe d exclusively to receive broadcasts pro-
vided under a separate subscription.
For details, refer to the “OWNER’S MANUAL” and “NAVIGATION SYSTEM
OWNER’S MANUAL”.

97
ES350_QG_OM33B82U_(U)
Door Locks
nDoor lock switch
Locks all the doors
Unlocks all the doors
nInside lock button
Locks the door
Unlocks the door
The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock posi-
tion.
1
2
1
2

98
ES350_QG_OM33B82U_(U)
nRear door child-protector lock
The door cannot be opened from inside
the vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent
children from opening the rear
doors. Push down on each rear door
switch to lock both rear doors.
Power Windows
n Power window switches
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: To stop the window partway, operate
the switch in the opposite direction.
n Window lock switch
Press the switch down to lock the pas-
senger window.
Use this switch to prevent children
from accidentally opening or closing
a passenger window.
1
2
1
2
3
4
