Lexus ES350 2016 Quick Guide / LEXUS 2016 ES350 QUICK GUIDE (OM33B82U) Manual Online
Manufacturer: LEXUS, Model Year: 2016, Model line: ES350, Model: Lexus ES350 2016Pages: 112, PDF Size: 2.11 MB
Page 81 of 112
80
ES350_QG_OM33B82U_(U)
nControl screen
Vehicles with Lexus Display Audio System
Adjust the left-hand side
temperature setting
Adjust the fan speed setting
“AUTO”:Select to set automaticmode on/off
“OFF”: Turn the fan off
: Display the option controlscreen
Select the air flow mode
: Air flows to the upper body
: Air flows to the upper bodyand feet
: Air flows to the feet
: Air flows to the feet and the windshield defogger operates
Adjust the right-hand side
temperature setting
1
2
3
4
5
Page 82 of 112
81
ES350_QG_OM33B82U_(U)
Vehicles with navigation systemAdjust the left-hand side
temperature setting
Adjust the fan speed setting
Select the air flow mode
: Air flows to the upper body
: Air flows to the upper bodyand feet
: Air flows to the feet
: Air flows to the feet and the windshield defogger oper-
ates
Adjust the right-hand side
temperature setting
Display the option control screen
Turn the fan off
Select to set automatic mode on/off
1
2
3
4
5
6
7
Page 83 of 112
82
ES350_QG_OM33B82U_(U)
nOption control screen
Select on the climate screen to disp lay the option control screen. The func-
tions can be switched on and off.
n Using the automatic mode
Press the “AUTO” button to turn on the ai rflow and adjust the temperature setting.
nAdjusting the temperature for driv er and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:
l Press the “DUAL” button.
l Select “DUAL” on the option control screen.
l Adjust the passenger’s side temperature setting.
Vehicles with Lexus Display Audio
system Select to set cooling and dehu-
midification function on/off
Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode)
Prevent ice from building up on
the windshield and wiper blades
(if equipped)
Remove pollen from the air
(micro dust and pollen filter)
Vehicles with navigation system1
2
3
4
Page 84 of 112
83
ES350_QG_OM33B82U_(U)
Voice Command System
nBasic operation
Press the talk switch.
To cancel the voice command sys-
tem, press and hold the talk switch.
After a beep sounds, say the desired
command.
On the list screen, you can select
the desired command.
Continue on to pages 83-86 for a detailed list of Voice Commands for the following
categories: Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.83
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.83
Navi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.83
Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.84
Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.85
Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.85
Other. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.86
1
2
n Important voice comman ds information and tips
• Voice commands can be used while driving.
• You must wait until after the beep to say a command.
• In vehicles with navigation system, a large (TALK icon) will appear on
the navigation screen to prompt you to say a command.
• If you know what command to use, you can press at any time to inter-
rupt the voice guidance.
NOTE: When inputting voice commands you must wait until after the beep to
Page 85 of 112
84
ES350_QG_OM33B82U_(U)
nCommand list
Basic (vehicles with Lexus Display Audio System)
Basic (Vehicles with navigation system)
Apps (vehicles with navigation system) (for U.S.A., if equipped)
Navi (vehicles with navigation system)
*1: For example; “Gas stati ons”, “Restaurants”, etc.
*2: Depending on the search results, a POI list may be provided by a relevant POI
application of the LEXUS App suite.
CommandAction
“Help”Prompts voice guidance to offer examples of
commands or operation methods
“Go Back”Returns to the previous screen
“Go to
CommandAction
“Help”Prompts voice guidance to offer examples of
commands or operation methods
“Go Back”Returns to the previous screen
“Go to
“More Hints”Displays more commonly used commands
“Cancel”Cancels the voice command system
CommandAction
“Launch
CommandAction
“Find
current position
*2
“Enter an Address”Enables setting a destination by saying the
address
“Go Home”Displays the route to home
“Pause Guidance”Stops the route guidance
“Resume Guidance”Resumes the route guidance
“Show
“Delete Destination”Deletes the destination
“Previous Destination”Displays previous destinations
Page 86 of 112
85
ES350_QG_OM33B82U_(U)
PhoneRadio (vehicles with navigation system)
Audio (vehicles with Lexus Display Audio System)
CommandAction
“Redial”Places a call to the phone number of the latest
outgoing call
“Call Back”Places a call to the phone number of latest
incoming call
“Show Recent Calls”Displays the call history screen
“Dial
“Call
from the phone book
CommandAction
“Tune to
quency
“Tune to
“Play
fied genre
“Tune to FM
HD
tion
“Tune to preset
station
“Tune to
with the specified name
“Tune to channel
channel number
“Play
tion”Changes the radio to a satellite radio channel of
the specified genre
CommandAction
“Play Playlist
“Play Artist
“Play Song
“Play Album
“Turn Music On/Off”Turns the audio system on/off
Audio source nameSelects audio source
Page 87 of 112
86
ES350_QG_OM33B82U_(U)
Audio (vehicles with navigation system)
Info (vehicles with navigation system) (for U.S.A., if equipped)
Info (vehicles with Lexus Display Audio System)
CommandAction
“Play Playlist
“Play Artist
“Play Song
“Play Album
CommandAction
“Destination Assist”Connects the system to the Lexus response cen-
ter
“Show Forecast”Displays weather information
“Show Traffic”Displays traffic information
“Lexus Insider”Displays the Lexus insider list
CommandAction
“Show Forecast”Displays weather information
“Show Traffic”Displays traffic information
Page 88 of 112
87
ES350_QG_OM33B82U_(U)
Other (vehicles with navigation system)
*1: Only within the possible temperature range of the air conditioning system
*2: Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.
CommandAction
“Turn Climate Control On”Turns air conditioning system on
“Turn Climate Control Off”Turns air conditioning system off
“Warmer”Increases the temperature of the air conditioning
system
“Cooler”Decreases the temperatur e of the air condition-
ing system
“<#> degrees”Changes the set temperature of the air condition-
ing system to <#> degrees
*1
“Turn Music On”Turns the audio system on
“Turn Music Off”Turns the audio system off
“AM Radio”Selects AM radio mode
“FM Radio”Selects FM radio mode
“Sirius XM”Selects satellite radio mode
“Disc”Selects the selected disc mode
“USB”Selects USB audio mode
“iPod”Selects iPod audio mode
“Bluetooth*2 Audio”Selects Bluetooth® audio mode
“A.V.”Selects VTR mode
“Auxiliary”Selects AUX audio mode
Commands relating to operation of the audio/visual and air conditioning systems
can only be performed when the audio and air conditioning systems are turned
on. Refer to the “OWNER’S MANUAL” and “NAVIGATION SYSTEM
OWNER’S MANUAL”.
Page 89 of 112
88
ES350_QG_OM33B82U_(U)
Portable Audio Device Ports
Open the console box, open the cover
and connect the portable audio device.
Seat Heaters and Ventilators (if equipped)
Heats the seat
The indicator light comes on.
The higher the number of dots, the
warmer the seat becomes.
Blows air from the seat
The indicator light comes on.
The higher the number of dots, the
stronger the airflow becomes.
These ports can be used to connect a portable audio device and listen to it
through the vehicle’s speakers.
1
2
Page 90 of 112
89
ES350_QG_OM33B82U_(U)
Rear Sunshade/Rear Door Sunshades
(if equipped)
nRear sunshade
The rear sunshade can be raised and lowered by operating the button shown
below.
Raise/lower
nRear door sunshades
Pull the tab of the rear door sunshade
and hook the sunshade on the anchors.
To retract the rear door sunshade,
unhook the sunshade and retract it
slowly.
