key Lexus GS350 2012 Owner's Manual

TABLE OF CONTENTS2
GS350/250_EE (OM30C36E)
For your information...................... 8
Reading this manual .................... 12
How to search .............................. 13
Pictorial index .............................. 14
1-1. For safe use
Before driving ..................... 34
For safety drive ................... 36
Seat belts ............................. 38
SRS airbags ......................... 44
Airbag manual on-off sys-
tem.....................................56
Safety information for chil-
dren...................................58
Child restraint systems ........ 59
Installing child restraints ..... 68
Exhaust gas precautions ...... 79
1-2. Theft deterrent system
Engine immobilizer system. 80
Double locking system ........ 85
Alarm .................................. 86
2. Instrument cluster
Warning lights and indica-
tors.......................................94
Gauges and meters .............. 98
Multi-information display . 101
Head-up display ................ 1093-1. Key information
Keys .................................. 118
3-2. Opening, closing and locking
the doors and trunk
Smart entry & start system 123
Wireless remote control .... 141
Doors ................................. 146
Trunk ................................. 150
3-3. Adjusting the seats
Front seats ......................... 157
Driving position memory .. 161
Head restraints................... 167
3-4. Adjusting the steering wheel and
mirrors
Steering wheel.................170
Inside rear view mirror ...... 171
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows ................. 178
Moon roof ......................... 181
1For safety and security
2Instrument cluster
3Operation of each compo-
nent

5
1
8 7
6
5
4
3
2
GS350/250_EE (OM30C36E)
5-5. Using the interior lights
Interior lights list ............... 611
Interior light ...................... 612
• Personal lights............... 612
5-6. Using the storage features
List of storage features ...... 614
• Glove box...................... 616
• Console box .................. 617
• Cup holders ................... 618
• Auxiliary boxes............. 620
Trunk features ................... 621
5-7. Other interior features
Sun visors and vanity mir-
rors....................................624
Clock ................................. 625
Ashtrays ............................ 626
Power outlets........................627
Heated steering wheel ....... 629
Seat heaters/ seat ventila-
tors.....................................631
Armrest.............................. 635
Rear sunshade/rear door sun-
shades................................636
Trunk storage extension .... 639
Coat hooks......................... 640
Assist grip ......................... 641
Utility hook ....................... 6426-1. Maintenance and care
Cleaning and protecting the
vehicle exterior................644
Cleaning and protecting the
vehicle interior.................648
6-2. Maintenance
Maintenance require-
ments...............................651
6-3. Do-it-yourself maintenance
Do-it-yourself service precau-
tions...................................654
Hood .................................. 657
Positioning a floor jack ..... 658
Engine compartment ......... 660
Tires................................... 672
Tire inflation pressure ....... 689
Wheels............................... 691
Air conditioning filter ....... 693
Electronic key battery ....... 695
Checking and replacing
fuses...................................698
Light bulbs ........................ 7206Maintenance and care

TABLE OF CONTENTS6
GS350/250_EE (OM30C36E)
7-1. Essential information
Emergency flashers ........... 738
If your vehicle has to be stopped
in an emergency.................7397-2. Steps to take in an emergency
If your vehicle needs to be
towed...............................740
If you think something is
wrong................................747
Fuel pump shut off system 748
If a warning light turns on or a
warning buzzer sounds.....749
If a warning message is dis-
played................................757
If you have a flat tire (vehicles
with a spare tire)...............782
If you have a flat tire (vehicles
without a spare
tire).....................................797
If the engine will not start . 815
If the shift lever cannot be
shifted from P....................817
If the parking brake cannot be
released.............................818
If the electronic key does not
operate properly................821
If the vehicle battery is dis-
charged..............................824
If your vehicle overheats ... 829
If your vehicle becomes
stuck...................................832
7When trouble arises

11
GS350/250_EE (OM30C36E)
CAUTION
General precautions while driving
Driving under the influence: Never drive your vehicle when under the
influence of alcohol or drugs that have impaired your ability to operate
your vehicle. Alcohol and certain drugs delay reaction time, impair judg-
ment and reduce coordination, which could lead to an accident that could
result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that
other drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone
or reading can result in a collision with resulting death or serious injury to
you, your occupants or others.
General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof, or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

14Pictorial index
GS350/250_EE (OM30C36E)
Pictorial index
Exterior
Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 146
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 124, 141
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . P. 178
Locking/unlocking by using the mechanical key . . . . . . . . . . . P. 821
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . P. 752, 763
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Opening from inside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 124, 141
Opening by using the mechanical key . . . . . . . . . . . . . . . . . . . P. 822
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . P. 752, 764
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Defogging the mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 4301
2
3

571-1. For safe use
1
For safety and security
GS350/250_EE (OM30C36E)Insert the mechanical key into
the cylinder and rotate to the
“OFF” position.
The “OFF” indicator light turns on
(only when the engine switch is in
IGNITION ON mode).
“PASSENGER AIR BAG” indicator information
If any of the following problems occur, it is possible that there is a malfunc-
tion in the system. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Neither “ON” nor “OFF” comes on.
The indicator light does not change when the airbag manual on-off switch is
switched to “ON” or “OFF”.
Deactivating the front seat passenger airbag, front passenger
knee airbag and front passenger side airbag
CAUTION
When installing a child restraint system
For safety reasons, always install a child restraint system in a rear seat. In
the event that the rear seat cannot be used, the front seat can be used as long
as the airbag manual on-off system is set to off.
If the airbag manual on-off system is left on, the strong impact of the airbag
deployment (inflation) may cause serious injury or even death.
When a child restraint system is not installed on the front passenger seat
Ensure that the airbag manual on-off system is set to on.
If it is left off, the airbag may not deploy in the event of an accident, which
may result in serious injury or even death.

581-1. For safe use
GS350/250_EE (OM30C36E)
Safety information for children
It is recommended that children sit in the rear seats to avoid acci-
dental contact with the shift lever, wiper switch etc.
Use the rear door child-protector lock or the window lock switch
to avoid children opening the door while driving or operating the
power window accidentally.
Do not let small children operate equipment which may catch or
pinch body parts, such as the power window, hood, trunk, seats
etc.
Observe the following precautions when children are in the vehi-
cle.
Use a child restraint system appropriate for the child, until the
child becomes large enough to properly wear the vehicle’s seat
belt.
CAUTION
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

631-1. For safe use
1
For safety and security
GS350/250_EE (OM30C36E)Key of letters inserted in the above table:
U: Suitable for “universal” category child restraint system
approved for the use in this mass group.
UF: Suitable for forward-facing “universal” category child
restraint system approved for the use in this mass group.
L: Suitable for “LEXUS G 0
+, BABY SAFE PLUS with SEAT
BELT FIXATION, BASE PLATFORM” approved for the use
in this mass group.
X: Not suitable seat position for children in this mass group.
NOTE:
*1: When you use a child restraint system in this position, move the seatback
to the most upright position and the seat cushion to the highest position.
*2: When you use a child restraint system in this position, remove the head
restraint.
The child restraint system mentioned in the table may not be avail-
able outside of the EU area.
Other child restraint system which is different from the system
mentioned in the table can be used, but the suitability of the sys-
tems must be carefully checked with the child restraint system
manufacturer concerned and the seller of those seats.

651-1. For safe use
1
For safety and security
GS350/250_EE (OM30C36E)(1) For the child restraint system which do not carry the ISO/XX
size class identification (A to G), for the applicable mass
group, the car manufacturer shall indicate the vehicle specific
ISOFIX child restraint system(s) recommended for each posi-
tion.
Key of letters inserted in the above table:
IUF:Suitable for ISOFIX forward-facing child restraint systems of
universal category approved for use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint sys-
tems in this mass group and/or this size class.
*: When you use a child restraint system in this position, remove the head
restraint.
The child restraint system mentioned in the table may not be avail-
able outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

801-2. Theft deterrent system
GS350/250_EE (OM30C36E)
Engine immobilizer system
The indicator light flashes after
the engine switch has been
turned off to indicate that the
system is operating.
The indicator light stops flashing
after the engine switch has been
turned to ACCESSORY or
IGNITION ON mode to indicate
that the system has been can-
celed.
System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
Conditions that may cause the system to malfunction
If the grip portion of the key is in contact with a metallic object
If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle
The vehicle’s keys have built-in transponder chips that prevent the
engine from starting if a key has not been previously registered in
the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
