Lexus GS350 2013 Opening, closing and locking the doors and trunk / LEXUS 2013 GS350 QUICK GUIDE (OM30C68U) Repair Manual

61
GS350_QG_U (OM30C68U)
■Calling by speed dial
Press the “MENU” button on the
Remote Touch.
Please refer to P.47 for the Remote
To u c h o p e r a t i o n .
Select “Phone”.
Select “Speed Dials”.
Select the desired number to call.21
2
3
4
3
4

62
GS350_QG_U (OM30C68U)
■Calling using SMS/MMS message
Press the “MENU” button on the
Remote Touch.
Please refer to P.47 for the Remote
To u c h o p e r a t i o n .
Select “Phone”.
Select “Messages”.
Select “SMS/MMS” tab.
Select the desired received message
from the displayed list.
Press on the steering wheel.21
2
3
4
5
6
3
The tab display may vary depending on the type of cellular phone.

63
GS350_QG_U (OM30C68U)
■Receiving a call
When a call is received, this screen is
displayed with a sound.
Press on the steering wheel to
talk on the phone.
To refuse the call, press on the steer-
ing wheel.
■ Steering switches
Sending/Receiving/“Phone” screen
display
End call/Refuse call
Start the voice command system
Return to the previous screen
Increases/decreases volume
11
2
2
1
2
3
4
5

64
GS350_QG_U (OM30C68U)
Audio System
■Audio control screen
Follow the procedure below to display the audio control screen.
Press the “MENU” button on the
Remote Touch.
Please refer to page 47 for the Remote
To u c h o p e r a t i o n .
The “Menu” screen will be displayed.
Using the Remote Touch, select
“Radio” or “Media” and select each tab.
■Side Display (vehicles with a navigation system)
Operations such as selecting a preset sta-
tion or track are carried out on the screen.
Changing the audio sources
Station selector/selecting a track/file/
chapter
■Remote control (steering wheel switches)
Some audio features can be controlled using the switches on the steering wheel.
Radio mode: Selects a radio station
Audio CD mode: Selects a track
MP3/WMA disc mode: Selects a file
and folder
DVD mode: Selects a chapter
iPod mode: Selects a song
Increases/decreases volume
Turns the power on, selects an audio
source
1
2
1
2
1
2
3

65
GS350_QG_U (OM30C68U)
■Basic operation
Sound quality modes
Audio sources
AM: AM radio
FM: FM radio
SAT: Satellite radio
Apps (if equipped): Internet radio
broadcast
DISC: DVD player/CD player
iPod: iPod
USB: USB memory
BT Audio: Bluetooth
® audio
AUX: Auxiliary audio device
Pow e r/ Vo l u m e
■ Radio
Station selector
Scanning for receivable stations
Using HD Radio
TM Te c h n o l o g y ( i f
equipped)
Adjusting the frequency
Preset turning/seeking the frequency
■Entering station presets
Select the desired station by using the tune, the seek or the scan function.
Using the Remote Touch, select one of the left side screen buttons (1-6) and hold it until
a beep is heard, indicating that the station has been set.
There are 6 sets of 6 presets. There is a total of 36 presets.
1
2
3
1
2
3
4
5
1
2

66
GS350_QG_U (OM30C68U)
■DVD player/CD player
■
Playing an audio CD
Random playback
Repeat play
Playback/pause
Selecting a track
CD eject
■Playing a CD with MP3/WMA files
Random playback
Repeat play
Playback/pause
Selecting a file
Folder selection
CD eject
1
2
3
4
5
1
2
3
4
5
6

67
GS350_QG_U (OM30C68U)
■Playing a DVD
Image display (full screen)
Reverse
Stop
Playback/pause
Fast for ward
Chapter selection
DVD eject
■Operating an iPod
Shuffle playback
Repeat play
Playback/pause
Select play mode
Song selection
■Rear seat audio controls (if equipped)
Some front audio features can be controlled from the rear seats.
Preset station or folder etc.
Track or file etc.
Vo l u m e
Audio sources
Pow e r
1
2
3
4
5
6
7
1
2
3
4
5
1
2
3
4
5

68
GS350_QG_U (OM30C68U)
Front Air Conditioning System
Without rear air conditioning system
With rear air conditioning system
Outside temperature
Passenger’s side temperature control
Passenger’s side temperature display
Front seat air outlet selector
Windshield wiper de-icer
Micro dust and pollen filter
Outside air or recirculated mode
Rear window and outside rear view
mirror defoggers
S-FLOW mode
Off
Automatic mode
Driver’s side temperature displayDriver’s side temperature control
Windshield defogger
DUAL mode
Cooling and dehumidification func-
tion on/off
Fan speed control
Air flows to the feet and the wind-
shield defogger operates
Rear air conditioning operation
screen
Passenger’s side air outlet selector
3-ZONE mode
Driver’s side air outlet selector1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

69
GS350_QG_U (OM30C68U)
■Side Display (vehicles with a navigation system)
Without rear air conditioning system
Operations such as changing the air outlets
or fan speed are carried out on the screen.
Fan speed control
Passenger’s side temperature control
Passenger’s side temperature display
DUAL mode
Automatic mode
Cooling and dehumidification function
on/off
Driver’s side temperature display
Driver’s side temperature control
Front seat air outlet selector
Passenger’s side air outlet selector
3-ZONE mode
Driver’s side air outlet selector
With rear air conditioning system
1
2
3
4
5
6
7
8
9
10
11
12

70
GS350_QG_U (OM30C68U)
■Using the automatic mode
Press the automatic mode button to turn on the airflow and the driver’s side temperature
control buttons to adjust the temperature.
■Adjusting the temperature
Without rear air conditioning system
In dual mode, driver and passenger side temp erature settings can be adjusted separately.
Press the passenger’s side temperature control buttons to adjust the temperature for the
passenger side.
To cancel the dual mode, press the DUAL mode button.
With rear air conditioning system
In individual mode, the temperature for the driv er’s, front passenger’s and rear seats can be
adjusted separately.
Press the passenger’s side temperature control buttons to adjust the temperature for the
passenger side.
To adjust the temperature for the rear seats, see page 71.
To cancel the individual mode, press the 3-ZONE mode button.
■ Using the S-FLOW mode
Press the S-FLOW mode button to operate
the system.
When the S-FLOW switch is pressed,
the airflow changes as follows.
Without rear air conditioning system: Air
flows to the front seats only.
With rear air conditioning system: Air
flows to the front seats only, and if the
passenger seat is unoccupied, the set
temperature, outside humidity and tem-
perature inside the cabin are assessed,
and air flows to the driver seat only.
