Lexus GS350 2013 Opening, closing and locking the doors and trunk / LEXUS 2013 GS350 QUICK GUIDE (OM30C68U) Manual Online

81
GS350_QG_U (OM30C68U)
●eDestination 
With the eDestination feature, you can go online, via the Lexus.com owner’s Web site, to
select and organize destinations of your choice and then wirelessly send them to your
vehicle’s navigation system. 
You can store up to 200 locations online to access and update at any time. 
Your locations can be organized into up to 20 personalized folders.
You must first go online at www.lexus.com/drivers/
to view the Owners site where you
will need to register and log in. After this, you can create your personalized folders con-
taining the locations you wish to send to your vehicle. (See Lexus Enform with Safety
Connect Guide for more information.)
● Lexus Insider 
Lexus Insider is an optional service that can send audio messages, or articles, to partici-
pating owners’ vehicles via the navigation sy stem. Potential Lexus Insider subjects might
include, for example, Lexus vehicle technology tips, updates on regional Lexus events, or
audio excerpts from Lexus Magazine articles. Up to 20 articles can be stored at a time.
You may opt out of receiving Lexus Insider messages at any time.
■Subscription
After you have signed the Telematics Subscription Service Agreement and are enrolled,
you can begin receiving services. A variety of subscription terms is available for purchase.
Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987), or select the “Des-
tination Assist” in your vehicle for further subscription details.
■ Function achieved by using DCM
■
Services
Of the functions included with Lexus Enform with Safety Connect, Safety Connect can be
achieved by using DCM.
● Safety Connect ( P. 7 8 )

82
GS350_QG_U (OM30C68U)
XM Services (if equipped)
■Services
With an active XM subscription, the following features are available:
● XM Sports and Stocks
*1
XM Sports and Stocks is a service included with an XM Satellite Radio subscription. This
service is also available with an XM TravelLi nk subscription. With this service, you can
receive updates via the navigati on system on your personally selected sports teams and
stocks.
● XM Fuel Prices
*2
XM Fuel Prices is a service included with an XM TravelLink subscription. It enables the
navigation system to display current fuel pr ices and gas station locations, which can be
set as a destination if desired.
● XM NavWeather
TM*2
The subscription-based XM NavWeatherTM service allows the navigation system to dis-
play weather information on the map screen.
● XM NavTraffic
®*2
The subscription-based XM NavTraffic® service allows the navigation system to display
traffic information on the map screen.
*1: Available at no extra charge with an active XM Satellite Radio subscription.
*2: Available via separate XM subscription(s).
■ Subscription
XM NavTraffic®, XM NavWeatherTM and XM TravelLink require separate XM subscrip-
tion(s). XM Sports
*, XM Stocks* and XM Fuel Prices are available with an XM TravelLink
subscription. After a 90-day trial, you must contact XM and set up the appropriate XM
subscription(s) to continue receiving these services.
*: XM Sports and XM Stocks are included wi th an XM Satellite Radio subscription.
XM services are subscription-based XM Sate llite Radio services to provide convenient
features to subscribers.
For details, refer to the “Owner’s Manual” and “Navigation System Owner’s Manual”.

83
GS350_QG_U (OM30C68U)
Door Locks
■Door lock switch
Locks all the doors
Unlocks all the doors
■Inside lock button
Locks the door
Unlocks the door
The front doors can be opened by pull-
ing the inside handle even if the lock
buttons are in the lock position.
The vehicle can be locked and unlocked using the entry function, wireless remote control
or door lock switches. 
For details the entry function or wireless remote control ( P.9 , 1 0 )
1
2
1
2

84
GS350_QG_U (OM30C68U)
■Rear door child-protector lock
The door cannot be open ed from inside the
vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent chil-
dren from opening the rear doors.
Push down on each rear door switch to
lock both rear doors.
1
2

85
GS350_QG_U (OM30C68U)
Powe r Wi n d ows
■Po w e r w i n d o w s w i t c h e s
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: Pushing the switch in the opposite direc-
tion will stop window travel partway.
■ Window lock switch
Press the switch down to lock the passen-
ger window.
The indicator will come on.
Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
1
2
3
4
Indicator

86
GS350_QG_U (OM30C68U)
Moon Roof
■Opening and closing
Opens the moon roof*
The moon roof stops slightly before the
fully open position to reduce wind
noise.
Press the switch again to fully open the
moon roof.
Closes the moon roof
*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
■ Tilting up and down
Tilts the moon roof up*
Tilts the moon roof down*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
1
2
1
2

87
GS350_QG_U (OM30C68U)
Fuel Tank Cap
■Before refueling the vehicle
● Close all the doors and windows, and turn the engine switch off.
● Confirm the type of fuel.
■Opening the fuel tank cap
With the doors unlocked, press the
center of the rear ed ge of the fuel filler
door.
Push until you hear a click and take
your hand away to slightly open the fuel
filler door. Then open the door fully by
hand.
Turn the fuel tank cap slowly to open.
Hang the fuel tank cap on the back of
the fuel filler door.1
2
3

88
GS350_QG_U (OM30C68U)
Trunk
■Opening the trunk
● From inside the vehicle
Press the opener switch.If the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully
Turn the main switch in the glove box off to
disable the trunk opener. On
Off
The trunk lid cannot be opened even with
the wireless remote control or the entry
function.
● From outside the vehicle
• Entry function
 P.1 0
• Wireless remote control  P.9
■Trunk easy closer (vehicles with power trunk opener and closer)
In the event that the trunk lid is left slightly open, the trunk easy closer will automatically
close it to the fully closed position.
■ Trunk closer switch (vehicles with power trunk opener and closer)
Pressing the switch closes the trunk lid
automatically. (A buzzer sounds.)
Pressing the switch while the trunk lid is
closing opens the trunk lid again.
1
2

What to do if...
89
GS350_QG_U (OM30C68U)
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
Brake system warning light
(Canada)
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
Malfunction 
indicator lamp
Slip indicator
(Canada)
(Flashes)
“AFS OFF” indicator 
(if equipped)
SRS warning light(Flashes)(U.S.A.)
Parking brake 
indicator
(U.S.A.)
ABS warning light(Flashes)
(Canada)
(Canada)Brake system warning light
Electric power steering 
system warning light(Blinking and then continu-
ously on)Tire pressure warning light
(Flashes)
“PCS” warning light 
(if equipped)
For further information, re fer to the Owner’s Manual.

90
What to do if...
GS350_QG_U (OM30C68U)
*: It also comes on due to natural causes such as natural air leaks and tire inflation pressure changes caused by temperature. Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn off even if the tire
inflation pressure is adjusted, have th e system checked by your Lexus dealer.
Follow the correction procedures.
Open door warning lightMaster warning light
Low fuel level warning light
(Illuminates
without
blinking)Tire pressure warning light*
Seat belt reminder light
See the Owner’s Manual
Tu r n s i g n a l i n d i c a t o rIntuitive parking assist 
indicator (if equipped)
Headlight indicator (U.S.A.)“AFS OFF” indicator 
(if equipped)
Tail light indicator (Canada)
(Flashes)
Slip indicator
Headlight high beam indicatorVSC OFF indicator
Front fog light indicator 
(if equipped)
(Flashes faster)
“PCS” warning light 
(if equipped)
Cruise control indicatorParking brake indicator
(U.S.A.)
Radar cruise control 
indicator (if equipped)Parking brake indicator 
(Canada)
Cruise control “SET” indicator“A I R B A G O N /
OFF” indicator
LKA (Lane-Keeping assist)
indicator (if equipped)
For further information, re fer to the Owner’s Manual.
