LEXUS GS400 2000 Service Repair Manual

I05320
Radio Assembly
Antenna Choke Coil
Antenna Cable
Motor Antenna
TAIWAN Models
± BODY ELECTRICALANTENNA
BE±223
2524 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

BE0GA±03
I04291
D
A
BCE
View ºAº View ºBº
View ºDº
View ºEºView ºCº
Connector Earth Nut
Connector (Orange)
Connector (White)Connector
Earth Bolt
Connector
Choke Coil Antenna
: Clamp
BE±224
± BODY ELECTRICALANTENNA
2525 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
COMPONENTS

BE0N6±04
I05587
2 5
I05580
2 5
Z08688
2 13
45 768 Wire Harness Side
± BODY ELECTRICALANTENNA
BE±225
2526 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. Auto Antenna Models:
INSPECT ANTENNA MOTOR
(a) Connect the positive (+) lead from the battery to terminal
2 and the negative (±) lead to terminal 5.
(b) Check that the motor turns (moves upward).
NOTICE:
These tests must be done quickly (within 3 ± 5 seconds) to
prevent the coil from burning out.
(c) Then, reverse the polarity, check that the motor turns the
opposite way (moves downward).
NOTICE:
These tests must be done quickly (within 3 ± 5 seconds) to
prevent the coil from burning out.
2. Auto Antenna Models:
INSPECT ANTENNA MOTOR CONTROL RELAY CIR-
CUIT
Disconnect the connector from the relay and inspect the con-
nector on wire harness side, as shown in the chart below.
Tester connectionConditionSpecified condition
7 ± GroundConstantContinuity
1 ± GroundIgnition switch ACC or ON,
and radio switch ON and OthersNo voltage
1 ± GroundIgnition switch ACC or ON,
and radio switch ON and AMBattery positive voltage
2 ± GroundIgnition switch ACC or ON,
and radio or tape or CD switch OFFNo voltage
2 ± GroundIgnition switch ACC or ON,
and radio or tape or CD switch ONBattery positive voltage
3 ± GroundConstantBattery positive voltage
4 ± GroundIgnition switch ACC or ON,
and radio switch ON and OthersNo voltage
4 ± Ground
Ignition switch ACC or ON,
and radio switch ON and
AM or FM (87.9 ± 96.0 MHz)
Battery positive voltage
5 ± GroundIgnition switch ACC or ON,
and radio switch OFFNo voltage
5 ± GroundIgnition switch ACC or ON,
and radio switch ONBattery positive voltage

BE±226
± BODY ELECTRICALANTENNA
2527 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)6 ± Ground
Ignition switch ACC or LOCKNo voltage
6 ± GroundIgnition switch ONBattery positive voltage
8 ± GroundIgnition switch LOCKNo voltage
8 ± GroundIgnition switch ACC or ONBattery positive voltage
If circuit is as specified, replace the relay.

BE0G0±05
1
CLOCK WILL NOT OPERATEPASSENGER SEAT BELT WARNING LIGHT DOES NOT OPERATE
I04264
Wire Harness Side5
4
3
6
1RAD NO.2 Fuse
DOME Fuse
Combination
Meter
Body ECU
No.2
Ground ACC
+B
PBEW
ILL
E Clock Assembly
± BODY ELECTRICALCLOCK
BE±227
2528 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
CLOCK
TROUBLESHOOTING
HINT:
Troubleshoot the clock according to the table below.
TroubleshootingNo.
Passenger seat belt warning light does not light up.1
Clock will not operate1
Clock loses or gains time2
± 1.5 seconds / day
INSPECT CLOCK CIRCUIT
(See page DI±849)
TROUBLESHOOTING NO.1
(a) Check that the battery positive voltage is 10 ± 16 V.
If voltage is not as specified, replace the battery.
(b) Check that the DOME and RAD NO.2 fuses are not
blown.
If the fuse is blown, replace the fuse and check for short.
(c) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.

Ye s
Ye sNo
No
Is there battery positive voltage between terminal +B and
body ground?
Is there battery positive voltage between terminal ACC and
body ground?
Replace clock.+B wire harness faulty.
Ye sNo
Is there continuity between terminal GND and
body ground?Ground wire harnss faulty. ACC wire harness faulty.
2 CLOCK LOSES OR GAINS TIME
I04264
Wire Harness Side5
4
3
6
1RAD NO.2 Fuse
DOME Fuse
Combination
Meter
Body ECU
No.2
Ground ACC
+B
PBEW
ILL
E Clock Assembly
Ye s
Is there battery positive voltage between terminal +B and
body ground?
Adjust or replace clock.Bellow 10 V
Locate cause and repair, or recharge battery.
Ye s
Is there battery positive voltage between terminal ACC and
body ground?Bellow 10 V
Locate cause and repair, or recharge battery.
BE±228
± BODY ELECTRICALCLOCK
2529 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
TROUBLESHOOTING NO.2
(a) Check that the battery positive voltage is 10 ± 16 V.
If voltage is not as specified, replace the battery.
(b) Inspect the error of the clock.
Allowable error (per day): ± 1.5 seconds
If the error exceeds the allowable error, replace the clock.
(c) Check that the clock adjusting button is sticking in posi-
tion and has failed to return.
If the error exceeds the allowable error, replace the clock.
(d) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.

BE0G1±08
I01374
Ignitioin SwitchClock Assembly
Driver Side Junction Block

SRS ACC Fuse
Passenger Side
Junction Block

DOME Fuse
± BODY ELECTRICALCLOCK
BE±229
2530 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
LOCATION

BE0G2±03
I04191
BE±230
± BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
2531 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
GARAGE DOOR OPENER SYSTEM
REGISTRATION PROCEDURE
1. NEW CODE REGISTRATION
NOTICE:

If pressing the switch of the original transmitter to
register the code, the system might operate.

When registering the transmitter codes such as for
garage or gate, check that there is nobody around
those places then register.
(a) Press the switch for the item to be registered for 20 se-
conds
HINT:
When transferring to registration mode, LED (red) blinks in 1 Hz
cycle.
(b) In the condition of (a), bring the original transmitter to with-
in 1±inch area around the garage door opener and press
the switch. (code transmitting).
HINT:
When code registration completes correctly, LED (red) blinks in
5.6 Hz cycle.

I03487
GARAGE DOOR
OPENER SWITCH
LEARN MODE
LED
OPERATION
ORIGINAL
TRANSMITTERPRESSED
ENTER
EXIT
ON
OFF20 sec
LED flashes
at a rate of 1 Hz
LED flashes at a
rate of 5.6 Hz PRESSED
ON
OFF
± BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE±231
2532 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
New code registration timing chart.
If a code can not be registered, observe the following condi-
tions.
HINT:

If the battery of original transmitter is consumed.

Press the switch of the transmitter repeatedly in registra-
tion mode, as some transmitters stop transmitting for 1 to
2 seconds.

This system is not applicable to the garage door opener
which had been made before 1982.
2. CODE DELETION
(a) Press the switches at both ends of garage door opener
simultaneously for 20 seconds.
HINT:
When transferring to deletion mode, LED (red) blinks in 6 Hz
cycle.
(b) When releasing the switch within 10 seconds after trans-
ferring to deletion mode, all the registered codes will be
erased.
HINT:
Press the switch until blinking in 6 Hz cycle stops, so that the
default code for check is set.

I03488
LED
OPERATION GARAGE DOOR
OPENER SWITCH
(Switch at either end)
ON
OFF CLEAR/DEFAULT
MODEPRESSED
LOAD DEFAULT
LED flashes at a rate of 6 HZ 10 SEC
20 SEC PRESSED
ON
OFFEnter in erase mode to erase all 3 channels BE±232
± BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
2533 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
Code deletion timing chart
