BE±4
± BODY ELECTRICALTROUBLESHOOTING
2305 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) ºHI±Beamº does not light (One side).
1. Bulb
2. H±LP L±UPR Fuse
3. H±LP R±UPR Fuse
4. Wire Harness±
BE±21
BE±21
±
ºFlashº does not light.
1. H±LP L±UPR Fuse
2. H±LP R±UPR Fuse
3. Headlight Dimmer Switch
4. *Light Control ECU
5. Wire HarnessBE±21
BE±21
BE±37
±
±
ºFlashº does not light.
1. Bulb
2. *Light Control ECU
3. Wire Harness±
±
±
Headlight does not come on.
1. Headlight Control Relay
2. Light Control Switch
3. *Light Control ECU
4. Wire HarnessBE±37
BE±37
±
±
Headlight does not come on.
1. Bulb
2. *Light Control ECU
3. Wire Harness±
±
±
Headlight flickers.
1. Bulb
2. *Light Control ECU
3. Wire Harness±
±
±
Headlight is dark.
1. Bulb
2. *Light control ECU
3. Wire Harness±
±
±
Only one taillight comes on.1. Bulb
2. Wire Harness±
±
Taillight does not come on.
(Headlight is normal)
1. TAIL Fuse
2. GAUGE Fuse
3. Taillight Control Relay
4. Light Failure Relay
5. Light Control Switch
6. Wire HarnessBE±21
BE±21
BE±37
BE±92
BE±37
±
Taillight does not come on.
(Headlight does not light)1. Light Control Switch
2. Wire HarnessBE±37
±
Rear combination light does not come on.
1. Light Failure Relay
2. Wire Harness
3. BulbBE±92
±
±
*: HID Type
CANADA:
SymptomSuspect AreaSee page
Only one headlight comes on.
1. Daytime Running Light No.2, 3, 4 Relay
2. Daytime Running Light Main Relay
3. Bulb
4. *Light Control ECU
5. Wire HarnessBE±37
BE±37
±
±
±
ºLO±Beamº does not light (All).
1. Headlight Control Relay
2. *Light Control ECU
3. Wire HarnessBE±37
±
±
ºLO±Beamº does not light (One side).
1. Bulb
2. H±LP L±LWR Fuse
3. H±LP R±LWR Fuse
4. *Light Control ECU
5. Wire Harness±
BE±21
BE±21
±
±

± BODY ELECTRICALTROUBLESHOOTING
BE±5
2306 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) ºHI±Beamº does not light (All).
1. Headlight Dimmer Switch
2. Daytime Running Light Main Relay
3. Wire HarnessBE±37
BE±37
±
ºHI±Beamº does not light (One side).
1. Bulb
2. H±LP L±UPR Fuse
3. H±LP R±UPR Fuse
4. Daytime Running Light No.3 Relay
5. Wire Harness±
BE±21
BE±21
BE±37
±
ºFlashº does not light.
1. Headlight Dimmer Switch
2. Daytime Running Light Main Relay
3. Wire HarnessBE±37
BE±37
±
Headlight does not come on.
1. Headlight Control Relay
2. Daytime Running Light Main Relay
3. Daytime Running Light No.2, 3, 4 Relay
4. Headlight Dimmer Switch
5. Light Control Switch
6. Wire Harness
7. *Light Control ECU
8. BulbBE±37
BE±37
BE±37
BE±37
BE±37
±
±
±
Headlight does not come on with light control switch in HEAD.
1. Light Control Switch
2. *Light Control ECU
3. Wire HarnessBE±37
±
±
Headlight does not go out with light control switch in OFF.
1. Headlight Control Relay
2. *Light Control ECU
3. Wire HarnessBE±37
±
±
Headlight flickers.
1. Bulb
2. *Light Control ECU
3. Wire Harness±
BE±37
±
Headlight is dark.
1. Bulb
2. *Light control ECU
3. Wire Harness±
±
±
Taillight does not come on with light control switch in TAIL.
1. Taillight Control Relay (Instrument Panel J/B)
2. Light Control Switch
3. Wire HarnessBE±37
±
±
Taillight does not go out with light control switch in OFF.
1. Taillight Control Relay
2. Light Control Switch
3. Wire HarnessBE±37
BE±37
±
Headlight does not come on with engine running and light control
switch in OFF.
1. ECU±B Fuse
2. GAUGE Fuse
3. Daytime Running Light Main Relay
4. Daytime Running Light No.2, 3, 4 Relay
5. Generator L Terminal
6. Parking Brake Switch
7. Wire HarnessBE±21
BE±21
BE±37
BE±37
DI±853
BE±92
±
*: HID Type

BE±6
± BODY ELECTRICALTROUBLESHOOTING
2307 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
HEADLIGHT BEAM LEVEL CONTROL SYSTEM
SymptomSuspect AreaSee page
Beam axis is not controlled. (It is not initialized.)
Headlight Beam Level Control System does not operate.
1. ECU±IG Fuse
2. Headight Beam Level Control Actuator
3. Headlight Beam Level Control ECU
4. Wire Harness SideBE±21
BE±50
BE±50
±
Beam axis is not controlled. (It is initialized.)
Headlight Beam Level Control System does not operate.1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Wire Harness SideBE±50
BE±50
±
Controlled angle of head light is unusual.
(The angle is controlled.)
1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Headlights
4. Wire Harness Side±
BE±50
BE±3
±
Beam axis position is not stable during driving.
1. ABS System
2. Headlights
3. Wire HarnessDI±387
BE±3
±
FOG LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Fog light does not light up with light control SW HEAD
(Headlight is normal.)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness
5. Body No.2 ECUBE±21
BE±53
BE±53
±
±
Fog light does not light up with light control SW HEAD
(Headlight does not light).1.*1 Other Parts
2. Wire Harness±
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
*1: Inspect Headlight System
TURN SIGNAL AND HAZARD WARNING SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. GAUGE Fuse
2. TURN HAZ Fuse
3. Ignitioin Switch
4. Turn Signal Flasher Relay
5. Wire HarnessBE±21
BE±21
BE±31
BE±56
±
Hazard warning light does not light up.
(Turn is normal)1. Hazard Warning Switch
2. Wire HarnessBE±56
±
Turn signal does not light up.
(Hazard is normal)1. Turn Signal Switch
2. Wire HarnessBE±56
±
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE±56
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±

± BODY ELECTRICALTROUBLESHOOTING
BE±7
2308 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INTERIOR LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the lights do not come ON.1. DOME Fuse
2. Body ECU NO.2BE±21
±
The light does not come ON when the driver's door is opened.1. Driver's Door Courtesy Switch
2. Wire HarnessBE±60
±
The light does not come ON when the passenger's door is
opened.1. Passenger's Door Courtesy Switch
2. Wire HarnessBE±60
±
The light does not come on when the rear±right door is opened.1. Rear±Right Door Courtesy Switch
2. Wire HarnessBE±60
±
The light does not come on when the rear±left door is opened.1. Rear±Left Door Courtesy Switch
2. Wire HarnessBE±60
±
Only one of the bulbs comes ON.Bulb±
The illumination does not fade out when all the doors are closed.1. Courtesy Switch
2. Wire HarnessBE±60
±
The illumination does not fade out immediately when the ignition
switch is turned to ACC or ON within 15 seconds after all the
doors are closed.1. Ignition Switch
2. RADIO NO.2 Fuse
3. GAUGE Fuse
4. Wire HarnessBE±31
BE±21
BE±21
±
The illumination does not fade out immediately when all the doors
are locked within 15 seconds after they are closed.1. Door Unlock Detection Switch
2. Wire HarnessBE±131
±
Interior light does not light up.
(in front personal light)1. Bulb
2. Front Personal Light
3. Wire Harness±
BE±60
±
Front personal light does not light up.
1. Bulb
2. Front Personal Light
3. Wire Harness±
BE±60
±
Rear personal light does not light up.
1. Bulb
2. Rear Personal Light
3. Wire Harness±
BE±60
±
Vanity light does not light up.
1. Bulb
2. Vanity Light
3. Wire Harness±
BE±60
±
Luggage compartment light does not light up.
1. Bulb
2. Luggage Compartment Door Courtesy Switch
3. Wire Harness±
BE±60
±
Courtesy light does not light up.
1. Bulb
2. Door Courtesy Switch
3. Wire Harness±
BE±60
±

BE±8
± BODY ELECTRICALTROUBLESHOOTING
2309 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
BACK±UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back±Up Light does not light up.
1. GAUGE Fuse
2. Ignition Switch
3. Wire Harness
4. BulbBE±21
BE±31
±
±
Back±Up Light remains always on.1. Park/ Neutral Position Switch
2. Wire HarnessDI±372
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not light up.
1. STOP Fuse
2. Stop Light Switch
3. Light Failure Relay
4. Wire HarnessBE±21
BE±70
BE±92
±
Stop light always lights up.1. Stop Light Switc
2. Wire HarnessBE±70
±
Only one light always lights up.Wire Harness±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
HEADLIGHT CLEANER SYSTEM
SymptomSuspect AreaSee page
ºHeadlight Cleaner Systemº does not operate
(All)
1. H±LP CLN Fuse
2. WASHER Fuse
3. Ignition Switch
4. Headlight Cleaner Switch
5. Headlight Cleaner Relay
6. Headlight Cleaner Motor
7. Headlight Cleaner Nozzle and Hose
8. Wire HarnessBE±21
BE±21
BE±31
BE±73
BE±73
±
±
±
Washer fluid does not spray.Headlight Cleaner Nozzle and Hose±
WIPER AND WASHER SYSTEM
SymptomSuspect AreaSee page
Wipers and washer do not operate.
1. WIP Fuse
2. Wiper Switch
3. Wiper Motor
4. Wire HarnessBE±21
BE±77
BE±77
±
Wipers do not operate in LO, HI or MIST.
1. Wiper Switch
2. Wiper Motor
3. Wire HarnessBE±77
BE±77
±
Wipers do not operate in INT.
1. Wiper Switch
2. Wiper Motor
3. Wire HarnessBE±77
BE±77
±
Washer motor does not operate.
1. WASHER Fuse
2. Washer Switch
3. Washer Motor
4. Wire HarnessBE±21
BE±77
BE±77
±
Wipers do not operate when washer switch ON.
1. WASHER Fuse
2. Washer Switch
3. Wiper Motor
4. Wire HarnessBE±21
BE±77
BE±77
±

± BODY ELECTRICALTROUBLESHOOTING
BE±9
2310 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Washer fluid does not operate.
Washer Hose and Nozzle±

When wiper switch is in HI position, the wiper blade is in contact
with the body.

When the wiper switch is OFF, the wiper blade does not retract
or the retract position is wrong.
1. Wiper Motor *1
2. Wire harness *1BE±77
±
*1: Inspect wiper arm and blade set positions.
COMBINATION METER
This system uses the multiplex communication system, so check diagnosis system of the multiplex
communication system before you proceed with troubleshooting.
Refer to DI section for warning light or indicator light not described in the table below.
SymptomSuspect AreaSee page
Driver seat belt warning light does not light up.
1. Bulb
2. Driver Buckle Switch CIrcuit
3. Meter Circuit Plate
4. Wire Harness
5. Body No.2 ECU±
BE±92
BE±92
±
DI±820
Passenger seat belt warning light does not light up.
1. Clock System
2. Passenger Buckle Switch CIrcuit
3. Occupant Detection Sensor
4. Meter Circuit Plate
5. Wire Harness
6. Body No.1 ECUBE±227
BE±92
BE±92
BE±92
±
DI±776
SRS warning light does not light up.
1. MPX±B Fuse
2. SRS±B Fuse
3. Bulb
4. Meter Circuit Plate
5. Wire Harness
6. Airbag Sensor AssemblyBE±21
BE±21
±
BE±92
±
DI±550
Hi±beam indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Headlight System±
BE±92
±
BE±3
Turn indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Turn Signal and Hazard Warning System±
BE±92
±
BE±3
ABS warning light does not light up.
1. GAUGE Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. ABS, TRAC and VSC ECUBE±21
±
BE±92
±
DI±387
TRAC warning light does not light up.
1. GAUGE Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. ABS, TRAC and VSC ECUBE±21
±
BE±92
±
DI±473

BE±10
± BODY ELECTRICALTROUBLESHOOTING
2311 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Malfunction indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. ECM (2JZ±GE)
5. ECM (1UZ±FE)±
BE±92
±
DI±1
DI±156
Fuel level warning light does not light up.
1. Bulb
2. Fuel level warning sensor
3. Meter Circuit Plate
4. Wire Harness±
±
BE±92
±
ELECTRIC TENSION REDUCER SYSTEM
SymptomSuspect AreaSee page
Tension Reducer does not operate.
(Driver's and Passenger's)1. ECU±IG Fuse
2. Wire HarnessBE±21
±
Tension Reducer does not operate.
(Only one side)1. Buckle Switch
2. Tension Reducer Solenoid
3. Wire HarnessBE±92
BE±92
±
DEFOGGER SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Rear window defogger does not operate.
1. HTR Fuse
2. DEF M±Fuse
3. Defogger Relay Circuit
4. Defogger Switch (in A/C Panel Switch)
5. Defogger Wire
6. Wire Harness
7. Body No.1 ECUBE±21
BE±21
DI±812
BE±108
BE±108
±
DI±776
Mirror defogger does not operate.
1. MIR±HTR Fuse (Passenger SIde J/B)
2. Mirror Heater Relay
3. Mirror Heater
4. Wire HarnessBE±21
BE±108
BE±108
±
POWER WINDOW CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power Door Lock System is normal.)
1. PWS terminal circuit
2. Power Window Master Switch
3. Wire Harness
4. Driver Door ECU
5. Body No.1 ECUDI±818
BE±117
±
DI±856
DI±776
Only the driver's window does not operate.
1. Power Window Master Switch
2. Power WIndow Switch
3. Power Window Motor
4. Wire HarnessBE±117
BE±117
BE±117
±
ºWindow lock functionº does not operate.1. Power Window Master SwitchBE±117
Window does not operate with power window master switch.
(Manual or Automatic operation can be performed.)TROUBLESHOOTING NO.1BE±111
Remote control of all windows (Except driver's) does not functions
with master switch.
(Windows operate normally with each of master switch.)
TROUBLESHOOTING NO.2BE±111

± BODY ELECTRICALTROUBLESHOOTING
BE±11
2312 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) The Key related power window operations does not operate with
driver side door key cylinder.
(Master switch operation is normal.)
TROUBLESHOOTING NO.3BE±111
Power window does not operate with multi±function transmitter.
(Windows operate normally with master switch.)TROUBLESHOOTING NO.4BE±111
Window moves down without being ordered during the up opara-
tion.TROUBLESHOOTING NO.5BE±111
POWER DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the doors cannot be locked or unlocked.
(Power Window Control System is normal.)1. Door Lock Control Switch
2. Wire Harness
3. Body No.1 ECUBE±131
±
DI±776
Only one side door lock control does not operate.
1. Door Lock Motor
2. Wire Harness
3. Each Door ECUBE±131
±
±
Door key related function does not operate.
1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Each Door ECU
4. Body No.1 ECUBE±131
±
±
DI±776
Key confinement prevention function does not operate.
1. Key Unlock Warning Switch
2. Door Courtesy Switch
3. Wire Harness
4. Each Door ECUBE±31
BE±60
±
±
Luggage compartment door opener function does not operate.
1. Luggage Compartment Door Opener Switch
2. Luggage Compartment Door Opener Motor
3. Wire Harness
4. Body No.1 ECUBE±131
BE±131
±
DI±776
THEFT DETERRENT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
The system cannot be set.
1. Indicator Light
2. Key Unlock Warning Switch
3. Door Unlock Detection Switch
4. Engine Hood Courtesy Switch
5. Luggage Compartment Door Courtesy Switch
6. Wire Harness
7. Each Door ECU
8. Body No.1 ECUBE±150
BE±31
BE±131
BE±150
BE±60
±
±
DI±776
The system cannot be canceled when the ignition switch is turned
to ON with key.
1. Key Unlock Warning Switch
2. Ignition Switch
3. RAD NO.2 Fuse
4. Wire Harness
5. Body No.1 ECUBE±31
BE±31
BE±21
±
DI±776
The system cannot be canceled when the luggage compartment
door is unlocked with key.1. Luggage Compartment Door Courtesy Switch
2. Wire Harness
3. Body No.1 ECUBE±60
±
DI±776
The system does not operate when the engine hood is opened.
1. Engine Hood Courtesy Switch
2. Wire Harness
3. Body No.1 ECUBE±150
±
DI±776

BE±12
± BODY ELECTRICALTROUBLESHOOTING
2313 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) The system does not operate when the ignition switch is turned to
ACC without using a key or transmitter.
1. Ignition Switch
2. Key Unlock Warning Switch
3. Transmitter
4. Wire Harness
5. Body No.1 ECUBE±31
BE±31
BE±157
±
DI±776
Some of the system does not operate.
(Headlight does not light up.)
1. Headlight System
2. Wire Harness
3. Body No.2 ECU
4. Body No.1 ECUBE±3
±
DI±820
DI±776
Some of the system does not operate.
(Taillight does not light up.)
1. Taillight System
2. Wire Harness
3. Body No.2 ECU
4. Body No.1 ECUBE±3
±
DI±820
DI±776
Some of the system does not operate.
(Theft Deterrent Horn or Horn does not sound.)
1. HORN Fuse
2. Theft Deterrent Horn
3. Horn
4. Horn Relay
5. Wire Harness
6. Body No.1 ECUBE±21
BE±150
BE±250
BE±250
±
DI±776
While the warning is given, the system cannot be canceled by
unlocking the door with key or transmitter.1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Body No.1 ECUBE±131
±
DI±776
While the warning is given, the system cannot be canceled by
turning the ignition switch to ACC or ON with key.
1. Ignition Switch
2. Key Unlock Warning Switch
3. RAD NO.2 Fuse
4. ECU±IG Fuse
5. Wire Harness
6. Body No.2 ECU
7. Body No.1 ECUBE±31
BE±31
BE±21
BE±21
±
DI±820
DI±776
The system operates for more than 60 seconds.Body No.1 ECUDI±776
WIRELESS DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
HINT:
Troubleshooting of the wireless door lock control system is based on the premise that the door lock
control system is operating normally. Accordingly, before troubleshooting the wireless door lock control
system, first make certain that the door lock control system is operating normally.
If the trouble still reappears even though there are no abnormalities in any of the other circuits, then
check and replace the Wireless Door Lock Control Receiver as the last step.
SymptomSuspect AreaSee page
All functions of wireless door lock control system do not operate.
1. Transmitter
2. Wireless Door Lock Control Receiver
3. Wire Harness
4. Body No.1 ECUBE±157
BE±157
±
DI±776
Wireless door lock operates, but the buzzer does not sound.
(The buzzer does not sound when the customize function prohib-
its.)1. Wireless Door Lock Buzzer
2. Wireless Door Lock Control Receiver
3. Wire HarnessBE±157
BE±157
±

± BODY ELECTRICALTROUBLESHOOTING
BE±13
2314 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
POWER SEAT CONTROL SYSTEM
SymptomSuspect AreaSee page
Both Driver and Passenger Power seats do not operate.
(Door lock does not operate.)1. ALT M±Fuse
2. Wire HarnessBE±21
±
Driver's seat does not operate.
1. P/SEAT (D) Fuse
2. Power Seat Switch (D)
3. Wire HarnessBE±21
BE±167
±
Passenger's seat does not operate.
1. P/SEAT (P) Fuse
2. Power Seat Switch (P)
3. Wire HarnessBE±21
BE±167
±
ºSlide operationº does not operate.
1. Power Seat Switch (D, P)
2. Wire Harness
3. Slide Motor (D, P)BE±167
±
BE±167
ºFront Vertical Operationº does not operate.
1. Power Seat Switch (D, P)
2. Wire Harness
3. Front Vertical Motor (D, P)BE±167
±
BE±167
ºLifter Operationº does not operate.
1. Power Seat Switch (D, P)
2. Wire Harness
3. Lifter Motor (D, P)BE±167
±
BE±167
ºReclining Operationº does not operate.
1. Power Seat Switch (D, P)
2. Wire Harness
3. Reclining Motor (D, P)BE±167
±
BE±167
ºLumbar Support Operationº does not operate.
1. Power Seat Switch (D, P)
2. Wire Harness
3. Lumbar Support Motor (D, P)BE±167
±
BE±167
(D): Driver's Seat
(P): Passenger's Seat
POWER MIRROR CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
w/ Driving Position Memory System:
SymptomSuspect AreaSee page
Both right and left mirrors do not operate.
1. Mirror Switch
2. Wire Harness
3. Body No.2 ECUBE±176
±
DI±820
Only one side of mirror does not operate.
1. Mirror Motor
2. Wire Harness
3. Driver and Passenger Door ECUBE±176
±
DI±856
DI±889
The mirror does not return to the memorized position.
1. Mirror Position Sensor
(Position is not set)
2. Wire Harness
3. Power Seat Control ECU
BE±176
±
DI±683
The memorized position is moved.
1. Mirror Position Sensor
(Position is not set)
2. Wire Harness
BE±176
±
