INSTALLATION
Installation is in the reverse order of removal (See page BR±61).
HINT:
After installation, check speed sensor signal (See page DI±389).

B01985
Water Bypass Outlet
 O±Ring
Engine Wire
Water
Pump
Connector Bracket
Idler PulleyGasket
Timing Belt GuideNo.2 Water Bypass Pipe
Drain Hose
Timing Belt Tensioner
Timing Belt
Drive Belt TensionerOil Filler Cap
No.3 Timing Belt Cover
No.1 Water
Bypass Pipe
 Gasket
Crankshaft PulleyDust Boot
x 5 Thermostat
 O±Ring
 O±Ring
No.2 Timing Belt Cover
Gasket
No.1 Timing Belt Cover
 Gasket
Water Inlet
x 6
35 (350, 26)
21 (210, 15)
21 (210, 15)
27 (270, 20)

N´m (kgf´cm, ft´lbf) : Specified torque
 Non±reusable part

Precoated part
330 (3,300, 243)
Clamp Bracket
Crankshaft Position
Sensor Connector
Gasket
CO±4
± COOLING (2JZ±GE)WATER PUMP
1542 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

CO09Z±03
A02725Turn
Loosen
B01614
Water Bypass Outlet
No.1 Water Bypass Hose
B01638
Clamp Bracket
Connector Bracket
B01572No.2 Water Bypass Pipe
± COOLING (2JZ±GE)WATER PUMP
CO±5
1543 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REMOVAL
1. REMOVE RADIATOR ASSEMBLY
(See page CO±18)
2. REMOVE DRIVE BELT AND WATER PUMP PULLEY
(a) Loosen the 4 nuts holding the water pump pulley to the
water pump.
(b) Loosen the drive belt tension by turning the drive belt ten-
sioner clockwise, and remove the drive belt.
(c) Remove the 4 nuts and water pump pulley.
3. REMOVE TIMING BELT AND IDLER PULLEY
(See page EM±16)
4. REMOVE WATER BYPASS OUTLET AND NO.1
WATER BYPASS PIPE
(a) Remove the 2 bolts, water bypass outlet and No.1 water
bypass pipe.
(b) Remove the 3 O±rings from the water bypass outlet and
No.1 water bypass pipe.
5. REMOVE WATER INLET AND THERMOSTAT
(See page CO±11)
6. REMOVE WATER PUMP
(a) Loosen the nut and remove the bolt, slide the generator
away from the water pump.
(b) Remove the bolt, and disconnect the clamp bracket (for
engine wire).
(c) Remove the bolt, and disconnect the connector bracket
(for crankshaft position sensor connector).
(d) Remove the 2 nuts, and disconnect the No.2 water by-
pass pipe from the water pump.

EC0DF±01
B01589
Air Cleaner, MAF Meter
and Intake Air Resonator
AssemblyPCV Hose
PS Air Hose
Air Cleaner Inlet MAF Meter Connector
Heated Oxygen Sensor
(Bank 1 Sensor 1)EVAP Hose

Gasket
Exhaust Manifold (with Front TWC)
Pipe Support Bracket
N´m (kgf´cm, ft´lbf)

Non±reusable partWire Grommet
Front Exhaust Pipe
: Specified torque
Heated Oxygen Sensor
(Bank 2 Sensor 1)
Heated Oxygen Sensor
(Bank 1 Sensor 2)

Gasket
40 (408, 30)
x 8
45 (450, 32)
44 (440, 32)
Engine Wire Clamp
Case Clamp

Clamp
44 (440, 32)
EC±12± EMISSION CONTROL (2JZ±GE)THREE±WAY CATALYTIC CONVERTER (TWC)
SYSTEM
1463 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
THREE±WAY CATALYTIC CONVERTER (TWC) SYSTEM
COMPONENTS

B08609
N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
44 (440, 32)
Gasket


Gasket

Front Exhaust Pipe
(with Rear TWC)
44 (440, 32)
44 (440, 32)
Pipe Support Bracket Floor Carpet Under CoverHeated Oxygen
Sensor Connector
TWC
± EMISSION CONTROL (2JZ±GE)THREE±WAY CATALYTIC CONVERTER (TWC)
SYSTEMEC±13
1464 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

EC050±04
B09011
± EMISSION CONTROL (2JZ±GE)THREE±WAY CATALYTIC CONVERTER (TWC)
SYSTEMEC±15
1466 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REPLACEMENT
1. REMOVE ENGINE COVER
2. REMOVE AIR CLEANER INLET
3. REMOVE AIR CLEANER, MAF METER AND INTAKE
AIR RESONATOR ASSEMBLY (See page EM±62)
4. DISCONNECT HEATED OXYGEN SENSORS FROM
EXHAUST MANIFOLD
(a) Disconnect the 3 oxygen sensor connectors.
(b) Disconnect the 2 oxygen sensors (bank 1 sensor 1, 2)
from the exhaust manifold.
5. REMOVE FRONT EXHAUST PIPE (WITH REAR TWC)
(a) Take out the front side of the floor carpet.
(b) Disconnect the oxygen sensor connector.
(c) Remove the 2 bolts and pipe support bracket.
(d) Remove the 5 bolts, front exhaust pipe and 3 gaskets.
6. REMOVE EXHAUST MANIFOLD (WITH FRONT TWC)
(a) Using a 14 mm deep socket wrench, remove the 8 nuts,
the exhaust manifold and 2 gaskets.
(b) Remove the heated oxygen sensor (bank 2 sensor 1)
form the exhaust manifold.
7. REINSTALL NEX EXHAUST MANIFOLD (WITH FRONT
TWC)
(a) Install the heated oxygen sensor (bank 2 sensor 1) to the
exhaust manifold.
Torque: 45 N´m (450 kgf´cm, 33 ft´lbf)
(b) Install 2 new gaskets to the cylinder head.
(c) Using a 14 mm deep socket wrench, install new exhaust
manifold with 8 new nuts. Uniformly tighten the nuts in
several passes.
Torque: 40 N´m (408 kgf´cm, 30 ft´lbf)
8. REINSTALL FRONT EXHAUST PIPE (WITH REAR
TWC)
(a) Reinstall new 3 gaskets, and front exhaust pipe with 5
bolts and support bracket.
(b) Reinstall the pipe support bracket with 2 bolts.
9. RECONNECT HEATED OXYGEN SENSORS TO EX-
HAUST MANIFOLD
(a) Install the 2 oxygen sensors (bank 1 sensor 1, 2) to the
exhaust manifold.
Torque: 45 N´m (450 kgf´cm, 33 ft´lbf)
(b) Connect the 3 oxygen sensor connectors.
10. REINSTALL AIR CLEANER, MAF MATER AND INTAKE
AIR RESONATOR ASSEMBLY (See page EM±68)
11. REINSTALL AIR CLEANER INLET
12. REINSTALL ENGINE COVER

EC04V±06
B08612
PCV Valve VSV for EVAP
Front TWC
EVAP Service Port
Fill Check LineCutoff ValveCharcoal Canister
Air Inlet Line
Vapor Pressure Sensor
Fuel Tank Cap
VSV for Vapor
Pressure Sensor
Purge Line
EVAP Line
Vent Line
Air Drain Hose
Rear TWC
EC±2
± EMISSION CONTROL (2JZ±GE)PARTS LAYOUT AND SCHEMATIC DRAWING
1453 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
PARTS LAYOUT AND SCHEMATIC DRAWING
LOCATION

EC04W±06
B08613
VSV for Vapor Pressure Sensor
Purge Line
Air Inlet LineAir Drain Hose
EVAP Line
Fuel Tank Charcoal Canister VSV for EVAPVapor Pressure Sensor
PCV Valve
Front TWC Front TWC
Vent Line
Fuel Tank
Cap
EVAP
Service
Port
Rear TWC
± EMISSION CONTROL (2JZ±GE)PARTS LAYOUT AND SCHEMATIC DRAWING
EC±3
1454 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
DRAWING

EC053±05
B06731
RH Rear Drive Shaft
Rear Suspension
Member Brace
Charcoal Canister AssemblyVapor Pressure
Sensor Connector
EVAP HoseVSV Connector
for Vapor Pressure
Sensor
Air Inlet Hose
83 (850, 61)
50 (510, 37)
Purge Hose
N´m (kgf´cm, ft´lbf) : Specified torque
Air Drain Hose
Vent Line Hose Canister Tank
EC±6
± EMISSION CONTROL (2JZ±GE)EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
1457 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
COMPONENTS

B06842
Air
Air Inlet Line Hose
B06803
Push
PinchPinch
A A
B06791
B06792Air
Purge Port
Air Drain Port
EVAP Port
Cap
Vent Port
EC±10
± EMISSION CONTROL (2JZ±GE)EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
1461 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
7. CHECK AIR INLET LINE
(a) Disconnect the air inlet line hose from the charcoal canis-
ter.
(b) Check that there is ventilation in the air inlet line.
(c) Reconnect the air inlet line hose to the charcoal canister.
8. REMOVE CHARCOAL CANISTER ASSEMBLY
(a) Disconnect the RH rear drive shaft from the differential.
(See page SA±52)
(b) Remove the charcoal canister assembly.
(1) Disconnect the vapor pressure sensor connector.
(2) Disconnect the VSV connector for vapor pressure
sensor.
(3) Disconnect the purge line hose, EVAP line hose
and air inlet line from the charcoal canister.
(4) Disconnect the vent line hose from the charcoal
canister.
Push the connector deep inside, pinch portion A,
and pull out the connector.
(5) Disconnect the air drain hose from the chanister
tank.
(6) Remove the 3 nuts and the charcoal canister as-
sembly.
9. INSPECT CHARCOAL CANISTER
(a) Visually check the charcoal canister for cracks or dam-
age.
(b) Inspect the charcoal canister operation.
(1) Plug the vent port with a cap.
(2) While holding the purge port closed, blow air (1.76
kPa, 18 gf/cm
2, 0.26 psi) into the EVAP port and
check that air flows from the air drain port.
