GX460_U.S.A. (OM60E69U)
3-6. Using the storage featuresList of storage fe atures................ 515
• Glove box ..................................... 516
• Console box ................................. 517
• Coin holder................................... 519
• Bottle holders/ 
door pockets .............................. 520
• Cup holders................................. 522
• Auxiliary boxes........................... 525
3-7. Other interior features Cool box ......................................... 528
Sun visors.......................................... 531
Vanity mirror .................................. 532
Clock ................................................ 533
Conversation mirror ................... 534
Power outlet (12 V DC) .................................... 535
Power outlet  (120 V AC [type A]) ................ 537
Power outlet  (120 V AC [type B]) ................ 542
Heated steering wheel............... 549
Seat heaters and 
ventilators ...................................... 551
Armrest ............................................ 554
Coat hooks .................................... 555
Floor mats........................................ 556
Luggage compartment 
features.......................................... 557
Garage door opener.................. 567
Compass.......................................... 575
Safety Connect ............................ 580 4-1. Maintenance and care
Cleaning and protecting 
the vehicle exterior.................. 588
Cleaning and protecting 
the vehicle interior .................... 592
4-2. Maintenance Maintenance requirements.............................. 595
General maintenance ................ 597
Emission inspection and 
maintenance (I/M) 
programs ....................................... 601
4-3. Do-it-yourself maintenance Do-it-yourself service 
precautions .................................. 602
Hood ................................................. 607
Engine compartment................. 608
Tires ................................................... 627
Tire inflation pressure................. 634
Wheels ............................................ 638
Air conditioning filter.................. 640
Electronic key battery ................ 642
Checking and replacing 
fuses ................................................ 645
Headlight aim (vehicles with low 
beam halogen bulbs) ............. 658
Light bulbs ....................................... 660
4Maintenance and care

TABLE OF CONTENTSIndex
6
GX460_U.S.A. (OM60E69U)
5-1. Essential informationEmergency flashers..................... 674
If your vehicle needs 
to be towed .................................. 675
If you think something is 
wrong .............................................. 681
Fuel pump shut off system ....... 682
Event data recorder ................... 683
5-2. Steps to take in an emergency If a warning light turns on or a 
warning buzzer sounds... ...... 686
If a warning message is 
displayed ...................................... 698
If you have a flat tire..................... 720
If the engine will not start .......... 734
If the shift lever cannot be 
shifted from P .............................. 736
If you lose your keys .................... 737
If the electronic key does 
not operate properly ............... 738
If the vehicle battery is 
discharged .................................... 741
If your vehicle overheats ........... 744
If the vehicle becomes 
stuck................................................ 747 6-1. Specifications
Maintenance data 
(fuel, oil level, etc.)..................... 750
Fuel information ............................ 762
Tire information............................. 765
6-2. Customization Customizable features................ 781
6-3. Initialization Items to initialize ............................ 801
Reporting safety defects 
for U.S. owners.......................... 804
Seat belt instructions 
for Canadian owners 
(in French) ................................... 805
Abbreviation list....................... 808
Alphabetical index .................... 810
What to do if... ........................... 820
5When trouble arises6Vehicle specifications
7For owners
Index

26
GX460_U.S.A. (OM60E69U)
1-1. Key information
Keys
Using the mechanical keyTo take out the mechanical key,
slide the release lever and take the
key out.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the entry
function does not operate properly,
you will need the mechanical key.
(P. 7 3 8 )
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart access system with push-
button start ( P. 2 9 )
• Operating the wireless
remote control function
( P. 4 8 )
Mechanical keys
Key number plate

37
1-2. Opening, closing and locking the doors and trunk
1
Before driving
GX460_U.S.A. (OM60E69U)
AlarmSituationCorrection procedure
Interior and exte-
rior alarms sound
continuously
*1
When the “ENGINE START
STOP” switch is in IGNI-
TION ON or ACCESSORY
mode, the driver’s door was
closed after the key was car-
ried outside the vehicle, and
the shift lever not in P
Shift the shift lever to P,
turn the “ENGINE
START STOP” switch
OFF and close the
driver’s door again
Interior alarm pings
once
*1
The electronic key has a low
batteryReplace the electronic
key battery
An attempt was made to start
the engine without the elec-
tronic key being present, or
the electronic key was not
functioning normally
Start the engine with the
electronic key
present
*2

38
1-2. Opening, closing and locking the doors and trunk
GX460_U.S.A. (OM60E69U)
*1: A message will be shown on the multi-information display in the instrument cluster.
*2: If the engine does not start when the electronic key is inside the vehicle, the electronic key battery may be depleted or there may be difficulties receiving
signal from the key. ( P. 7 3 9 )
■Security feature
If a door is not opened within approx imately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
AlarmSituationCorrection procedure
Interior alarm pings
once and exterior
alarm sounds 3
times
*1
The driver’s door was closed
after the key was carried out-
side the vehicle, and the
“ENGINE START STOP”
switch was not turned OFFTu r n t h e “ E N G I N E
START STOP” switch
OFF and close the
driver’s door again
An occupant carried the
electronic key outside the
vehicle and closed the door
while the “ENGINE START
STOP” switch was not OFF
Bring the electronic key
back into the vehicle

40
1-2. Opening, closing and locking the doors and trunk
GX460_U.S.A. (OM60E69U)
■Battery-saving function
The battery-saving function will be activated in order to prevent the electronic key
battery and the vehicle battery from being discharged while the vehicle is not in
operation for a long time.
●In the following situations, the smart access system with pu sh-button start may
take some time to unlock the doors.
• The electronic key has been left in an area of approximately 6 ft. (2 m) of the
outside of the vehicle for 10 minutes or longer.
• The smart access system with push-button start has not been used for 5 days
or longer.
●If the smart access system with push-but ton start has not been used for 14 days
or longer, the doors cannot be unlocked at any doors except the driver’s door. 
In this case, take hold of the driver’s door handle, or use the wireless remote
control or the mechanical key, to unlock the doors.
■Conditions affecting operation
The smart access system with push-button start uses weak radio waves. In the fol-
lowing situations, the communication betw een electronic key and the vehicle may
be affected, preventing the smart access system with push-button start and wireless
remote control from operating properly. (Way of coping: P. 7 3 8 )

41
1-2. Opening, closing and locking the doors and trunk
1
Before driving
GX460_U.S.A. (OM60E69U)
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large display,
airport or other facility that generates strong radio waves or electrical noise
●When carrying a portable radio, cellular phone, cordless phone or other wire-
less communication devices
●When the electronic key is in contact wi th, or is covered by the following metal-
lic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When multiple electronic keys are in the vicinity
●When another wireless key (that emits radio waves) is being used nearby
●When carrying the electronic key together with the following devices that emit
radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or person al digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or metallic objects are attached to the rear
window

45
1-2. Opening, closing and locking the doors and trunk
1
Before driving
GX460_U.S.A. (OM60E69U)
■Electronic key battery depletion
●The standard battery life is 1 to 2 years.
●If the battery becomes low, an alarm will sound in the cabin when the engine will
stop. (P. 3 4 )
●As the electronic key always transmits radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indicate
that the electronic key battery may be depleted. Replace the battery when nec-
essary. ( P. 6 4 2 )
• The smart access system with push-but ton start or the wireless remote con-
trol does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
●To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of
the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
•Glass top ranges
• Table lamps
■When the electronic key battery is fully depleted
 P. 6 4 2
■Customization
Settings (e.g. smart access system with push-button start) can be changed. 
(Customizable features  P. 7 8 1 )

50
1-2. Opening, closing and locking the doors and trunk
GX460_U.S.A. (OM60E69U)
■Conditions affecting operation
P. 4 0
■If the wireless remote control does not operate properly
Locking and unlocking the doors: Use the mechanical key. ( P. 7 3 8 )
■Key battery depletion
P. 4 5
■When the electronic key battery is fully depleted
P. 6 4 2
■Customization
Settings (e.g. wireless remote control system) can be changed. 
(Customizable features P. 7 8 1 )

118
1-6. Theft deterrent system
GX460_U.S.A. (OM60E69U)
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the
following:
●Nobody is in the vehicle.
●The windows and moon roof are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
■Tr i g g e r i n g o f t h e a l a r m
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
●A person inside the vehicle opens a door or hood.
●The battery is recharged or replaced when the vehicle is locked.
■Alarm memory function
After the alarm is activated, when you unlock any door using a entry function, wire-
less remote control or mechanical key, the tail lights turn on for about 2 seconds to
inform you that the system was activated.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If mo dified or removed, the proper operation
of the system cannot be guaranteed.
