1
2
3
4
5
6
7
5
GX460_U.S.A. (OM60J00U)
3-6. Using the storage featuresList of storage features............... 523
• Glove box .................................... 525
• Console box ................................ 526
• Coin holder................................. 528
• Bottle holders/door pockets .......................................... 529
• Cup holders................................ 530
• Auxiliary boxes.......................... 533
3-7. Other interior features Cool box ......................................... 535
Sun visors........................................ 538
Vanity mirror .................................. 539
Clock ................................................ 540
Conversation mirror.................... 541
Power outlet (12 V DC) ............ 542
Power outlet (120 V AC) ......... 544
Heated steering wheel............... 549
Seat heaters and ventilators ..... 551
Armrest ............................................ 554
Coat hooks .................................... 555
Floor mat.......................................... 556
Luggage compartment features......................................... 558
Garage door opener.................. 567
Compass.......................................... 575
Safety Connect ............................ 580 4-1. Maintenance and care
Cleaning and protecting the vehicle exterior.................. 588
Cleaning and protecting the vehicle interior .................... 593
4-2. Maintenance Maintenance requirements ..... 596
General maintenance ............... 598
Emission inspection and maintenance (I/M)
programs ...................................... 602
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ................................. 603
Hood ................................................ 608
Engine compartment................. 609
Tires ................................................... 628
Tire inflation pressure................. 635
Wheels ............................................. 639
Air conditioning filter.................. 642
Electronic key battery ................ 644
Checking and replacing fuses ................................................ 647
Headlight aim (vehicles with low beam halogen bulbs) ............... 660
Light bulbs ....................................... 662
4Maintenance and care

212
2-2. Instrument cluster
GX460_U.S.A. (OM60J00U)
Multi-information display (Accessory meters)∗
∗: If equipped
The multi-information display presents the driver with a variety of driving-
related data including the current outside air temperature.
● Clock ( →P. 540)
Indicates the time.
●Outside temperature
Indicates the outside temperature.
The temperature range that can be displayed is from -40 °F (-40 ° C) to
122 °F (50 ° C).
●Air conditioning system display ( →P. 392)
● Rear view monitor ( →P. 2 8 1 )
Automatically displayed when the shift lever is moved into R.
●Multi-terrain Monitor (if equipped) ( →P. 304)
● Wide view front & side monitor (if equipped) ( →P. 2 8 6 )
● Trip information ( →P. 213)
Displays driving range, fuel consumption and other cruising-related infor-
mation.
●Intuitive parking assist display (if equipped) (→ P. 266)

Interior features3
391
GX460_U.S.A. (OM60J00U)
3-3. Using the Bluetooth® audio
system
Bluetooth
® audio system .... 464
Using the Bluetooth
®
audio system ......................... 468
Operating a Bluetooth
® enabled
portable player ..................... 474
Setting up a Bluetooth
® enabled
portable player .................... 477
Bluetooth
® audio system
setup ....................................... 484
3-4. Using the hands-free system (for cellular phone)
Hands-free system for cellular phones.................... 485
Using the hands-free system (for cellular phones) ........... 489
Making a phone call .............. 497
Setting a cellular phone ...... 502
Security and system setup ........................................ 507
Using the phone book............. 511
3-5. Using the interior lights Interior lights list ...................... 519
• Personal/interior light main switch .............................. 520
• Personal/interior lights ......... 521 3-6. Using the storage features
List of storage features......... 523
• Glove box ................................. 525
• Console box............................. 526
• Coin holder .............................. 528
• Bottle holders/door pockets ....................................... 529
• Cup holders ............................. 530
• Auxiliary boxes ....................... 533
3-7. Other interior features Cool box ................................... 535
Sun visors ................................. 538
Vanity mirror ........................... 539
Clock ......................................... 540
Conversation mirror.............. 541
Power outlet (12 V DC)........ 542
Power outlet (120 V AC) ..... 544
Heated steering wheel ........ 549
Seat heaters and ventilators .............................. 551
Armrest .................................... 554
Coat hooks .............................. 555
Floor mat .................................. 556
Luggage compartment features .................................. 558
Garage door opener ............. 567
Compass ................................... 575
Safety Connect ...................... 580

458
3-2. Using the audio system
GX460_U.S.A. (OM60J00U)■
Adjusting sound quality
Turning the “TUNE/SEL” knob adjusts the level.
*: The sound quality level is adjusted individually in each audio mode.
Turning the Automatic Sound Levelizer (ASL) on/off
Turning the “TUNE/SEL” knob clockwise turns on the ASL, and turning
the “TUNE/SEL” knob counterclockwise turns off the ASL.
ASL automatically adjusts the volume an d tone quality according to the noise
level as you drive your vehicle.
Mode
displayedSound
quality modeLevelTu r n c o u n t e r - clockwiseTu r n
clockwise
“BAS”Bass*-5 to 5
LowHigh“MID”Mid-range*-5 to 5
“TRE”Tr e b l e*-5 to 5
“FAD”
Front/rear volume
balance
F7 to R7Shifts to rearShifts to front
“BAL”
Left/right volume
balance
L7 to R7Shifts to leftShifts to right

509
3-4. Using the hands-free system (for cellular phone)
3
Interior features
GX460_U.S.A. (OM60J00U)
Setting voice guidance volumeSelect “Guidance Vol” using the “TUNE/SEL” knob.
Change the voice guidance volume.
To decrease the volume: Turn the “TUNE/SEL” knob counterclockwise.
To increase the volume: Turn the “TUNE/SEL” knob clockwise.
Displaying the Bluetooth® device address and name
Select “Device Name” using the “TUNE/SEL” knob.
Turn the “TUNE/SEL” knob to display the Bluetooth
® device
address and name.
Select “Go Back” using the “TUNE/ SEL” knob to return to “Sys-
tem Setup”.
Initializing the system
Select “Initialize” and then “Confirm” using the “TUNE/SEL”
knob.
Select “Confirm” again using the “TUNE/SEL” knob.
STEP1
STEP2
STEP1
STEP2
STEP3
STEP1
STEP2

540
3-7. Other interior features
GX460_U.S.A. (OM60J00U)
Clock
■The clock is displayed when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■When disconnecting and reconnecting battery terminals
The clock data will be reset.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system Adjusts the hours
Adjusts the minutes

558
3-7. Other interior features
GX460_U.S.A. (OM60J00U)
Luggage compartment features
■Cargo hooks
Vehicles without third seats Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Vehicles with third seats
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
When using the deck hooks, the
third seat must be fold down.
(→ P. 7 2 )
■Warning reflector holder
Turn the knob clockwise.
Open the lid.
STEP1

612
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60J00U)■
Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of
the same type as already in the
engine.
Make sure to check the oil type and prepare the items needed before
adding oil.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.
Engine oil selection→P. 7 5 5
Oil quantity (Low → Full)1.6 qt. (1.5 L, 1.3 Imp.qt.)
ItemsClean funnel
STEP1
STEP2
STEP3

622
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60J00U)■
Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turning it counterclockwise.
Wipe the dipstick clean.
Reinstall the cap and remove it again.
Check the fluid level.
Fluid typeAutomatic transmission fluid DEXRON® II or III
ItemsRag or paper, clean funnel (only for adding fluid)
CAUTION
■When checking the reservoir
Take care as the reservoir may be hot.
NOTICE
■When adding fluid
Avoid overfilling, or the power steering may be damaged.
■After replacing the reservoir cap
Check the steering box case, vane pump and hose connections for leaks or dam-
age.
STEP1
STEP2
STEP3
STEP4
STEP5

663
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60J00U)
Replacing light bulbs■ Headlight low beams (vehicles with halogen bulbs)
Turn the cover counterclockwise
and remove it.
■Rear bulb locations
Rear turn signal light
Back-up light
Rear side marker light
STEP1
