4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)■
Rear turn signal and re ar side marker lights
Open the back door.
Left-hand side:
Remove the bolts and lamp assem-
bly.
Right-hand side:
Remove the bolts.
Close the back door half way and
remove the lamp assembly.
STEP1
GX460_OM_OM60J63U_(U).book Page 677 Thursday, March 29, 2012 9:10 AM

678
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)Unplug the connector while push-
ing the lock release.
Turn the bulb bases counterclock-
wise.
Rear turn signal light
Rear side marker light
Remove the light bulb. Rear turn signal light
Rear side marker light
STEP2
STEP3
STEP4
GX460_OM_OM60J63U_(U).book Page 678 Thursday, March 29, 2012 9:10 AM

679
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)■
Back-up lights
Remove the bolts and pull down
the under cover.
Turn the bulb base counterclock-
wise.
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 679 Thursday, March 29, 2012 9:10 AM

680
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)Remove the light bulb.
■ Lights other than the above
If any of the lights listed below has burnt out, have it replaced by your
Lexus dealer.
●Headlight low beams (high-intensity discharge bulbs)
● Side turn signal lights
● High mounted stoplight
● Stop/tail lights
● License plate light
● Outer foot light
STEP3
GX460_OM_OM60J63U_(U).book Page 680 Thursday, March 29, 2012 9:10 AM

681
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
■High-intensity discharge (HID) headlights
If voltage to the high-intensity discharge bulbs is insufficient, the light may not come
on, or may go out temporarily. The high-intensity discharge bulbs will come on
when normal power is restored.
■LED light bulbs
The side turn signal lights, tail/stop lights , license plate light and high mounted stop-
light consist of a number of LEDs. If any LEDs burn out, take your vehicle to your
Lexus dealer to have the light replaced.
If two or more LEDs in a stoplight burn out, your vehicle may not conform to local
laws (SAE).
■Condensation build-up on the inside of the lens
Contact your Lexus dealer for more information in the following situations. Tempo-
rary condensation build-up on the inside of the headlight lens does not indicate a
malfunction.
●Large drops of water are built up on the inside of the lens.
●Water has built up inside the headlight.
GX460_OM_OM60J63U_(U).book Page 681 Thursday, March 29, 2012 9:10 AM

682
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
CAUTION
■Replacing light bulbs
●Turn off the headlights. Do not attempt to replace the bulb immediately after turn-
ing off the headlights.
The bulbs become very hot and may cause burns.
●Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by
the plastic or metal portion.
If the bulb is scratched or dropped it may blow out or crack.
●Fully install light bulbs and any parts used to secure them. Failing to do so may
result in heat damage, fire, or water entering the headlight unit. This may damage
the headlights or cause condensation to build up on the lens.
■High-intensity discharge (HID) headlights
●Contact your Lexus dealer before replacing high-intensity discharge headlights
(including light bulbs).
●Do not touch the high-intensity discharge headlight’s high voltage socket when
the headlights are turned on.
An extremely high voltage of 20000 V will be discharged and could result in
death or serious injury by electric shock.
●Do not attempt to repair or disassemble light bulbs, connectors, electric circuits
or component parts.
Doing so may result in serious injury due to electric shock.
■To prevent damage or fire
●Make sure bulbs are fully seated and locked.
●Check the wattage of the bulb before installing to prevent heat damage.
GX460_OM_OM60J63U_(U).book Page 682 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
703
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
CAUTION
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold
and inflated to the inflation pressure recommended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure label (tire and load information label).
(If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label [tire and load information label], you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire pressure
monitoring system (TPMS-tire pressure warning system) that illuminates a low tire
pressure telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale (tire pres-
sure warning light) illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation
also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling
and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for
proper tire maintenance, and it is the driver’s responsibility to maintain correct tire
pressure, even if under-inflation has not reached the level to trigger illumination of
the TPMS low tire pressure telltale (tire pressure warning light).
GX460_OM_OM60J63U_(U).book Page 703 Thursday, March 29, 2012 9:10 AM

704
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
CAUTION
■Maintenance of the tires
Your vehicle has also been equipped with a TPMS (tire pressure warning system)
malfunction indicator to indicate when the system is not operating properly. The
TPMS (tire pressure warning system) malfunction indicator is combined with the
low tire pressure telltale (tire pressure warning light). When the system detects a
malfunction, the telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon subsequent vehicle
start-ups as long as the malfunction exists. When the malfunction indicator is illumi-
nated, the system may not be able to detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of rea-
sons, including the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS (tire pressure warning system) from functioning
properly. Always check the TPMS (tire pressure warning system) malfunction tell-
tale after replacing one or more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS (tire pressure warning
system) to continue to function properly.
NOTICE
■Precaution when installing a different tire
When a tire of a different specification or maker is installed, the tire pressure warn-
ing system may not operate properly.
GX460_OM_OM60J63U_(U).book Page 704 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
711
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*: Refer to the separate “Scheduled maintenance” or “Owner’s Manual Supple-ment” for the maintenance interval applicable to your vehicle.
Wa r n i n g m e s s a g eDetailsCorrection procedure
Indicates that the washer
fluid level is lowAdd washer fluid.
(U.S.A. only)
Indicates that all mainte-
nance according to the
driven distance on the
maintenance schedule
*
should be performed
soon
If necessary, perform
maintenance.
Comes on approximately
4500 miles (7200 km)
after the maintenance
data has been reset.
(U.S.A. only)
Indicates that all mainte-
nance is required to cor-
respond to the driven
distance on the mainte-
nance schedule
*.Perform the necessary
maintenance. Please reset
the maintenance data
after the maintenance is
performed (→ P. 6 0 5 )
Comes on approximately
5000 miles (8000 km)
after the maintenance
data has been reset. (The
indicator will not work
properly unless the main-
tenance data has been
reset.)
GX460_OM_OM60J63U_(U).book Page 711 Thursday, March 29, 2012 9:10 AM
