Lexus GX460 2013 Owner's Manual

210
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)●
Driving range
● Average fuel consumption after refueling
● Current fuel consumption Displays the estimated maximum distance that can
be driven with the quantity of fuel remaining
• This distance is computed based on your average
fuel consumption. As a result, the actual distance
that can be driven may differ from that displayed.
• When only a small amount of fuel is added to the tank, the display may not be updated.
• When refueling, turn the “ENGINE START STOP” switch off. If the vehicle is refueled without
turning the “ENGINE START STOP” switch off,
the display may not be updated.
Displays the average fuel consumption since the
vehicle was last refueled
Use the displayed average fuel consumption as a ref-
erence.
Displays the current rate of fuel consumption
GX460_OM_OM60J63U_(U).book Page 210 Thursday, March 29, 2012 9:10 AM

211
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)●
Average fuel consumption and Eco Driving Indicator Zone Display
(→ P. 2 1 4 )
● Average vehicle speed
● Elapsed time
● Display off
A blank screen is displayed Displays the average fuel consumption since the
function was reset
• The function can be reset by pressing the
“ENTER” switch for longer than 1 second when
the average fuel consumption is displayed.
• Use the displayed average fuel consumption as a reference.
Displays the average vehicle speed since the
engine was started or the function was reset
The function can be reset by pressing the “ENTER”
switch for longer than 1 second when the average
vehicle speed is displayed.
Displays the elapsed time since the function was
last reset
The function can be reset by pressing the “ENTER”
switch for longer than 1 second when the elapsed
time is displayed.
GX460_OM_OM60J63U_(U).book Page 211 Thursday, March 29, 2012 9:10 AM

212
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)■
Electronic features control contents
●Multi-terrain Select (if equipped) ( →P. 300)
● Intuitive parking assist (if equipped) ( →P. 2 7 0 )
● AFS (Adaptive Front-lighting System) (if equipped) ( →P. 2 2 7 )
● Second start mode ( →P. 1 9 2 )
■ Other contents
●Multi-terrain Select display (if equipped) ( →P. 300)
● Intuitive parking assist display
* (if equipped) ( →P. 2 7 0 )
● Crawl Control display
* (if equipped) ( →P. 3 3 2 )
● Dynamic radar cruise control display
* (if equipped) (→ P. 2 5 4 )
● LDA (Lane Departure Alert) display
* (if equipped) (→ P. 2 7 9 )
● Warning messages ( →P. 705)
Automatically displayed when a malfunction occurs in one of the
vehicles systems.
● Customization
Settings (e.g.available language) can be changed.
(Customizable features →P. 788)
*: Automatically displayed when the system is used
GX460_OM_OM60J63U_(U).book Page 212 Thursday, March 29, 2012 9:10 AM

213
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
■Electronic features control can be turned on/off when
“ENGINE START STOP” switch is in IGNITION ON mode.
■System check display
After turning the “ENGINE START STOP” switch to IGNITION ON mode,
“CHECKING” is displayed while system operation is checked. When the system
check is complete, the normal screen will return.
■Conditions for ending electronic features control
In the following situations, the electronic features control will end automatically:
●The menu switch is pressed
●Intuitive parking assist display starts operating
●The Crawl Control is operated
●The dynamic radar cruise control is operated
●LDA (Lane Departure Alert) is operated
●A warning message appears after the electronic features control screen is dis-
played
GX460_OM_OM60J63U_(U).book Page 213 Thursday, March 29, 2012 9:10 AM

214
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)
■Eco Driving IndicatorEco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), Eco Driving Indicator Light will
turn on.
Eco Driving Indicator Zone Display
Suggests Zone of Eco driving with current
Eco driving ratio based on acceleration.
Zone of Eco driving
Eco driving ratio based on acceleration
If the vehicle exceeds Zone of Eco driving,
the right side of Eco Driving Indicator
Zone Display will blink and Eco Driving
Indicator Light will turn off.
Eco Driving Indicator Light will not operate in
the following conditions:
●The shift lever is in anything other than D.
●The vehicle is set to second start mode.
( → P. 192)
●The vehicle speed is approximately 81 mph
(130 km/h) or higher.
GX460_OM_OM60J63U_(U).book Page 214 Thursday, March 29, 2012 9:10 AM

215
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
■Outside temperature display
In the following situations, the correct outside temperature may not be displayed, or
the display may take longer than normal to change:
●When the vehicle is stopped, or moving at low speeds (less than 12 mph
[20 km/h])
●When the outside temperature has changed suddenly (at the entrance/exit of a
garage, tunnel, etc.)
■When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle Lexus dealer.
■When disconnecting and reconnecting battery terminals
The following information data will be reset:
●Average fuel consumption after refueling
●Average fuel consumption
●Average vehicle speed
●Elapsed time
CAUTION
■The multi-information display at low temperatures
Allow the interior of the vehicle to warm up before using the information display. At
extremely low temperatures, the information display monitor may respond slowly,
and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number
appearing on the display. This lag could cause the driver to downshift again, causing
rapid and excessive engine braking and possibly an accident resulting in death or
serious injury.
GX460_OM_OM60J63U_(U).book Page 215 Thursday, March 29, 2012 9:10 AM

216
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)
Multi-information display (Accessory meters)∗
∗: If equipped
The multi-information display presents the driver with a variety of driving-
related data including the current outside air temperature.
● Clock ( →P. 546)
Indicates the time.
●Outside temperature
Indicates the outside temperature.
The temperature range that can be displayed is from -40 °F (-40 ° C) to
122 °F (50 ° C).
●Air conditioning system display ( →P. 398)
● Rear view monitor ( →P. 285)
Automatically displayed when the shift lever is moved into R.
●Multi-terrain Monitor (if equipped) ( →P. 308)
● Wide view front & side monitor (if equipped) ( →P. 2 9 0 )
● Trip information ( →P. 217)
Displays driving range, fuel consumption and other cruising-related infor-
mation.
●Intuitive parking assist display (if equipped) (→ P. 2 7 0 )
GX460_OM_OM60J63U_(U).book Page 216 Thursday, March 29, 2012 9:10 AM

217
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
Switching the displayItems displayed can be switched
by pressing the “MODE” switch.“MODE” switch
“RESET” switch
“DISP” switch
Display adjustment switch
Display items
■ Driving range
Displays the estimated maximum
distance that can be driven with
the quantity of fuel remaining
• This distance is computed basedon your average fuel consump-
tion. As a result, the actual dis-
tance that can be driven may
differ from that displayed.
• When only a small amount of fuel is added to the tank, the dis-
play may not be updated.
•When refueling, turn the “ENGINE START STOP” switch
off. If the vehicle is refueled with-
out turning the “ENGINE
START STOP” switch off, the
display may not be updated.
GX460_OM_OM60J63U_(U).book Page 217 Thursday, March 29, 2012 9:10 AM

218
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)■
Average fuel consumption after re fueling and current fuel consump-
tion
Displays the average fuel con-
sumption since the vehicle was last
refueled and the current rate of
fuel consumption
Use the displayed average fuel
consumption as a reference.
■Average fuel consumption
Displays the average fuel con-
sumption since the function was
reset
• The function can be reset bypressing and holding the
“RESET” switch when the aver-
age fuel consumption is dis-
played.
• Use the displayed average fuel consumption as a reference.
■Average vehicle speed
Displays the average vehicle
speed since the function was reset
The function can be reset by press-
ing and holding the “RESET” switch
when the average vehicle speed is
displayed.
GX460_OM_OM60J63U_(U).book Page 218 Thursday, March 29, 2012 9:10 AM

219
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)■
Elapsed time
Displays the elapsed time since the
function was last reset
The function can be reset by press-
ing and holding the “RESET” switch
when the elapsed time is displayed.
■Air conditioning system display
→ P. 398
Setting up the display
■ Setting up the information display
To set up the display, press the “DISP” switch until the desired item
appears.
If left idle for approximately 10 seconds, the display will revert to the previous
screen.
●Setting the contrast
Press the display adjustment
switch (“∧” or “ ∨”) to adjust the
contrast.
+: Strengthen
-: Weaken
GX460_OM_OM60J63U_(U).book Page 219 Thursday, March 29, 2012 9:10 AM
