2-4. Using other driving systems
GX460_OM_OM60J63U_(U)
Multi-terrain Monitor∗
∗: If equipped
The Multi-terrain Monitor displays the vehicle surroundings when driving
at low speeds, thus assisting off-ro ad driving and helping the driver to
check the vehicle surroundings.
The Multi-terrain Monitor displays the vehicle surroundings automati-
cally when a mode is being selected on the Multi-terrain Select.
● You can switch between 4 different images (front, side-front, side-
rear and rear) by operating the switch.
● By using the front and side monitors to identify objects in the vicinity
or path of the tires, you can help to prevent the vehicle from becom-
ing stuck unexpectedly while driving.
Multi-information display
Accessory meter (vehicles
without navigation system) or
touch screen (vehicles with
navigation system)
“ENTER” switch
Menu switch
GX460_OM_OM60J63U_(U).book Page 308 Thursday, March 29, 2012 9:10 AM

309
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
■Switching the image
Select any mode using the Multi-terrain Select system.
(→P. 300)
Move the “ENTER” switch
upwards or downwards to
select “CAM. POSITION”, and
press the “ENTER” switch.
The camera view can be
switched by moving the
“ENTER” switch upwards or
downwards.
Each time the switch is oper-
ated, the mark on the multi-
information display will move
and the image displayed on the
monitor will switch.
Front monitor*1
Side-front simultaneous dis-
play monitor
*2
Side-rear simultaneous dis-
play monitor
*2
Rear monitor*3
*1: Cannot be selected if the shift lever is in R.
*2: The displayed icon differs in accordance with shift position.
*3: Cannot be selected if the shift lever is not in R.
STEP1
STEP2
STEP3
GX460_OM_OM60J63U_(U).book Page 309 Thursday, March 29, 2012 9:10 AM

310
2-4. Using other driving systems
GX460_OM_OM60J63U_(U)
Range covered by each cameraFront monitor
Side-front simultaneous display
monitor
Side-rear simultaneous display
monitor
Rear monitor
The illustration shown here is an example. As such, the actual visible area may
be different. See P. 313 for information about the visual range of each camera.
Display■ Front monitor
The image from the front camera is
displayed. Use this monitor to help
check the area in front of the vehi-
cle for safety.
GX460_OM_OM60J63U_(U).book Page 310 Thursday, March 29, 2012 9:10 AM

311
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)■
Side-front simultaneous display monitor
The image from both side cameras
is displayed. Use this monitor to
help check the area on both sides
of the vehicle at the same time, and
to check for objects near the tires
or the sides of the vehicle.
■ Side-rear simultaneous display monitor
The image from both side cameras
is displayed. Use this monitor to
help check the area on both sides
of the vehicle at the same time, and
to check for objects near the tires
or the sides of the vehicle.
GX460_OM_OM60J63U_(U).book Page 311 Thursday, March 29, 2012 9:10 AM

312
2-4. Using other driving systems
GX460_OM_OM60J63U_(U)■
Rear monitor
The image from the rear camera is
displayed. Use this monitor to help
check the area in rear of the vehi-
cle for safety.
■The Multi-terrain Monitor can be operated when
●Any Multi-terrain Select mode is selected.
●The door mirrors are not folded.
●The vehicle speed is less than approximately 7 mph (12 km/h).
■Automatic system cancellation
In the following situations, the image is canceled automatically.
●When the vehicle speed exceeds approximately 7 mph (12 km/h).
After the vehicle speed exceeds approximately 7 mph (12 km/h), the image will
continue to be displayed for a short time.
If the vehicle speed returns to below 7 mph (12 km/h) before the image extin-
guishes, the image will continue to be displayed.
●The Multi-terrain Select is off.
●The door mirrors are folded.
GX460_OM_OM60J63U_(U).book Page 312 Thursday, March 29, 2012 9:10 AM

313
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
■Displayed area
The area covered by the camera is limited. Objects which are close to either corner
of the bumper or under the bumper cannot be seen on the screen.
The area displayed on the screen may vary depending on vehicle orientation or
road conditions.
Front cameraCamera’s field of view
Objects visible to the camera
Objects not visible to the camera
Parts of the vehicle (bumper, grill, etc.)
GX460_OM_OM60J63U_(U).book Page 313 Thursday, March 29, 2012 9:10 AM

314
2-4. Using other driving systems
GX460_OM_OM60J63U_(U)
Side camera (side-front simultaneous display monitor)Camera’s field of view
Objects visible to the camera
Right side of vehicle
Left side of vehicle
GX460_OM_OM60J63U_(U).book Page 314 Thursday, March 29, 2012 9:10 AM

315
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
Side camera (side-rear simultaneous display monitor)
Rear camera
→P. 2 8 5 Camera’s field of view
Objects visible to the camera
Right side of vehicle
Left side of vehicle
GX460_OM_OM60J63U_(U).book Page 315 Thursday, March 29, 2012 9:10 AM

317
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
■Smear effect
■Flicker effect
When the camera is used under fluorescent lights, sodium lights, mercury lights
etc., the lights and the illuminated areas may appear to flicker.
■Display settings
Vehicles without a navigation system
→P. 2 2 1
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”
CAUTION
■When using the Multi-terrain Monitor system
Observe the following precautions to avoid an accident that could result in death or
serious injuries:
●Never depend solely on the monitor system.
●Always check visually and with the mirrors to confirm your intended path is clear.
●Depicted distances between objects and flat surfaces differ from actual dis-
tances.
●Do not use the system if the hood or doors are open.
If a bright light, such as sunlight reflected off
the vehicle body, is picked up by the camera,
a smear effect
* characteristic to the camera
may occur.
*: Smear effect  A phenomenon that
occurs when a bright light is picked up by
the camera; when transmitted by the cam-
era, the light source will appear to have
streaks of light emanating from it. The
streaks will also appear when the light
source is in the vehicle icon area.
GX460_OM_OM60J63U_(U).book Page 317 Thursday, March 29, 2012 9:10 AM

318
2-4. Using other driving systems
GX460_OM_OM60J63U_(U)
CAUTION
■Conditions which may affect the Multi-terrain Monitor system
●If the front or the rear of the vehicle or the outside rear view mirror has been hit,
the camera’s position and mounting angle may have changed. Have the vehicle
inspected by your Lexus dealer.
●As the camera has a water proof construction, do not detach, disassemble or
modify it. This may cause incorrect operation.
●Rapid temperature changes, such as when hot water is poured on the vehicle in
cold weather, may cause the system to function abnormally.
●If the camera lens is dirty, it cannot transmit a clear image. Rinse with water and
wipe with a soft cloth. If the camera lens is extremely dirty, wash with a mild
cleanser and rinse.
●Do not strongly rub the camera lens. If the camera lens is scratched, it cannot
transmit a clear image.
●Do not allow organic solvent, car wax, window cleaner or glass coat to adhere to
the camera. If this happens, wipe it off as soon as possible.
●The displayed image may be darker and moving images may be slightly distorted
when the system is cold.
●Situations unsuitable for Multi-terrain Monitor
• On icy or slick road surfaces, or in snow
•When using tire chains
●When washing the vehicle, do not apply intensive bursts of water to the camera
or camera area. Doing so may result in the camera malfunctioning.
