Lexus GX460 2013 Specifications /

481
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_OM_OM60J63U_(U)
Selecting an albumTo select the desired album, press the 5 ( ) or 6 ( ) button.
Selecting tracks
Press “ ” or “ ” on the “SEEK•TRACK” button to select the desired track.
Playing and pausing tracks
To play or pause a track, press the 3 ( ) button.
Fast-forwarding and rewinding tracksTo fast-forward or rewind, press and hold “ ” or “ ” on the
“SEEK•TRACK” button until you hear a beep.
Random playback
Press the 1 (RAND) button.
To cancel, press the 1 (RAND) button again.
Repeat playPress the 2 (RPT) button.
To cancel, press the 2 (RPT) button again.

482
3-3. Using the Bluetooth® audio system
GX460_OM_OM60J63U_(U)
Scanning tracksPress the “SCAN” button.
To cancel, press the “SCAN” button again.
Switching the displayPress the “TEXT” button.
Each time the button is pressed, the display changes in the following order:
Elapsed time  Album title  Tr a c k t i t l e  Artist name
Using the steering wheel audio switches
 P. 4 6 6
■Bluetooth® audio system functions
Depending on the portable player that is connected to the system, certain functions
may not be available.
■Display
 P. 4 3 3
■Error messages
“Memory Error”: This indicates a problem in the system.

483
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_OM_OM60J63U_(U)
Setting up a Bluetooth® enabled portable player
Registering a portable player in the Bluetooth® audio system allows the
system to function. The following functions can be used for registered por-
table players:
■ Functions and operation procedures
Pattern A
To enter the menu for each function , follow the steps below using a
voice command or the “TUNE/SEL” knob:
●Registering a portable player
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “Pair Audio Player (Pair Audio)”
● Selecting a portable player to be used
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “Connect Audio Player (Connect)”
● Changing the registered name of a portable player
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “Change Name”
● Listing the registered portable players
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “List Audio Players (List Audios)”
● Changing the passkey
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “Set Passkey”
● Deleting a registered portable player
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)” 
3. “Delete Audio Player (Delete Audio)”

484
3-3. Using the Bluetooth® audio system
GX460_OM_OM60J63U_(U)
Pattern BPress the “TUNE/SEL” knob to select “BT•A MENU”.
Press the talk switch or select “BT•A Setup” using the “TUNE/
SEL” knob.
Select one of the following functions using a voice command
or the “TUNE/SEL” knob.
● Registering a portable player
“Pair Audio Player (Pair Audio)”
● Selecting a portable player to be used
“Connect Audio Player (Connect)”
● Changing the registered name
“Change Name”
● Listing the registered portable players
“List Audio Players (List Audios)”
● Changing the passkey
“Set Passkey”
● Deleting a registered portable player
“Delete Audio Player (Delete Audio)”
STEP1
STEP2
STEP3

485
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_OM_OM60J63U_(U)
Registering a portable playerSelect “Pair Audio Player (Pair Audio)” using a voice command or the
“TUNE/SEL” knob, and perform the pr ocedure for registering a portable
player. ( P. 4 76 )
Selecting a portable player to be used
Select “Connect Audio Player (Connect)” using a voice com-
mand or the “TUNE/SEL” knob.
Pattern A Select the portable player to be used by either of the following
methods, and select “Confirm” by using a voice command or the
“TUNE/SEL” knob:
a. Press the talk switch and say the name of the desired portable
player.
b. Press the talk switch and sa y “List Audio Players”. When the
name of the desired portable pl ayer is read aloud, press the
talk switch.
Pattern B Select the portable player to be used using the “TUNE/SEL”
knob.
STEP1
STEP2
STEP2

486
3-3. Using the Bluetooth® audio system
GX460_OM_OM60J63U_(U)Pattern A
Press the talk switch and say “From Car” or “From Audio player”,
and select “Confirm” by using a voice command or the “TUNE/
SEL” knob.
Pattern B Select “From Car” or “From Audi o”, using the “TUNE/SEL” knob.
If “From Car” is selected, the portable player will be automatically con-
nected whenever the “ENGINE START STOP” switch is in either
ACCESSORY or IGNITION ON mode.
Changing the registered name of a portable player
Select “Change Name” using a voice command or the “TUNE/
SEL” knob.
Pattern A Select the name of the portable player to be changed by either of
the following methods, and sele ct “Confirm” using a voice com-
mand or the “TUNE/SEL” knob:
a. Press the talk switch and say the name of desired portable
player.
b. Press the talk switch and sa y “List Audio Players”. When the
name of the desired portable pl ayer is read aloud, press the
talk switch.
STEP3
STEP3
STEP1
STEP2

487
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_OM_OM60J63U_(U)Pattern B
Select the desired portable player name to be changed using the
“TUNE/SEL” knob.
Press the talk switch or select “Record Name” using the “TUNE/
SEL” knob, and say the new name.
Select “Confirm” using a voice command or the “TUNE/SEL”
knob.
Listing the registered portable players
Select “List Audio Players (List Audi os)” using a voice command or the
“TUNE/SEL” knob. The list of register ed portable players will be read
aloud.
When listing is complete, the system returns to “BT•A Setup”.
Pressing the talk switch while the name of a portable player is being read
aloud selects the portable player, an d the following functions will become
available:
● Selecting a portable player: “Connect Audio Player (Connect)”
● Changing a registered name: “Change Name”
● Deleting a portable player: “Delete Audio Player (Delete Audio)”
STEP2
STEP3
STEP4

488
3-3. Using the Bluetooth® audio system
GX460_OM_OM60J63U_(U)
Changing the passkeySelect “Set Passkey” using a voice command or the “TUNE/SEL”
knob.
Pattern A Press the talk switch, say a 4 to 8-digit number, and select “Con-
firm” using a voice command or the “TUNE/SEL” knob.
Pattern B Select a 4 to 8-digit number using the “TUNE/SEL” knob.
The number should be input 1 digit at a time.
When the entire number to be re gistered as a passkey has been
input, press the “TUNE/SEL” knob again.
If the number to be registered has 8 digits, pressing of the knob is not
necessary.
STEP1
STEP2
STEP2
STEP3

489
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_OM_OM60J63U_(U)
Deleting a registered portable playerSelect “Delete Audio Player (D elete Audio)” using a voice com-
mand or the “TUNE/SEL” knob.
Pattern A Select the portable player to be deleted by either of the following
methods and select “Confirm” using a voice command or the
“TUNE/SEL” knob:
a. Press the talk switch and say the name of the desired portable
player.
b. Press the talk switch and sa y “List Audio Players”. When the
name of the desired portable pl ayer is read aloud, press the
talk switch.
Pattern B Select the desired portable player to be deleted using the
“TUNE/SEL” knob.
If the portable player to be deleted is paired as a Bluetooth
® phone, the
registration of the cellular phone can be deleted at the same time. A
voice guidance instruction to delete a cellular phone is heard.
Select “Yes” or “No” using a voice command or the “TUNE/SEL”
knob. (Bluetooth
® phone P. 493)
■The number of portable players that can be registered
Up to 2 portable players can be registered in the system.
STEP1
STEP2
STEP2
STEP3

490
3-3. Using the Bluetooth® audio system
GX460_OM_OM60J63U_(U)
Bluetooth® audio system setup
■System setup items and operation procedures
Pattern A
To enter the menu for each function , follow the steps below using a
voice command or
the “TUNE/SEL” knob:
( P. 513)
Pattern B Press the “TUNE/SEL” knob to select “BT•A MENU”.
Select “System Setup” using the “TUNE/SEL” knob.
Select one of the following items using the “TUNE/SEL” knob:
● Setting voice guidance volume
“Guidance Vol” (
P. 515)
● Displaying the Bluetooth
® device address and name
“Device Name” (
P. 515)
● Initializing the system
“Initialize” (
P. 515)
STEP1
STEP2
STEP3
