Page 97 of 628
GX460_OM_OM60T19U_(U)
972. Instrument cluster
2
Instrument cluster
The settings of the following items can be changed. (P. 584)
For functions that can be enabled or disabled, the function switches between on and
off each time is pressed.
■LDA (Lane Departure Alert) ( P. 250)
■BSM (Blind Spot Monitor)* ( P. 361)
■PCS (Pre-Collision System) ( P. 239)
■Intuitive parking assist* ( P. 270)
■Vehicle settings
●Tire pressure warning system (P. 473)
●Scheduled maintenance* (P. 449)
●Oil maintenance (P. 462)
■Meter settings
Select to set the following items.
●Language
Select to change the language on the display.
●Units
Select to change the unit for measure.
● Eco Driving Indicator Light
Select to activate/deactivate th e Eco Driving Indicator Light.
● Switch settings
You can register 1 screen as the top screen. To register, press and hold
while the desired screen is displayed.
●Initialization
Registered or changed meter settings w ill be deleted or returned to their
default setting.
*: If equipped
Settings display
Page 175 of 628
GX460_OM_OM60T19U_(U)
1754-1. Before driving
4
Driving
NOTICE
■When driving the vehicle
●Do not depress the accelerator and brake pedals at the same time during driving, as
this may restrain the engine output.
●Do not use the accelerator pedal or depre ss the accelerator and brake pedals at the
same time to hold the vehicle on a hill.
■When parking the vehicle
Always set the parking brake, and shift the sh ift lever to P. Failure to do so may cause
the vehicle to move or the vehicle may acce lerate suddenly if the accelerator pedal is
accidentally depressed.
■Avoiding damage to vehicle parts
●Do not turn the steering wheel fully in either direction and hold it there for an
extended period of time.
Doing so may damage the power steering pump.
●When driving over bumps in the road, drive as slowly as possible to avoid damaging
the wheels, underside of the vehicle, etc.
■If you get a flat tire while driving
A flat or damaged tire may cause the following situations . Hold the steering wheel
firmly and gradually depress the brake pedal to slow down the vehicle.
●It may be difficult to control your vehicle.
●The vehicle will make abnormal sounds or vibrations.
●The vehicle will lean abnormally.
Information on what to do in case of a flat tire. ( P. 531)
■When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may cause the
following serious damage to the vehicle:
●Engine stalling
●Short in electrical components
●Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be sure to have
your Lexus dealer check the following:
●Brake function
●Changes in quantity and quality of oil and fluid used for the engine, transmission,
transfer, differentials, etc.
●Lubricant condition for the propeller shaft, bearings and suspension joints (where
possible), and the function of all joints, bearings, etc.
Page 235 of 628
GX460_OM_OM60T19U_(U)
2354-5. Using the driving support systems
4
Driving
WARNING
■To avoid malfunction of the front camera
Observe the following precautions.
Otherwise, the front camera may not operate properly, possibly leading to an accident
resulting in death or serious injury.
●Keep the windshield clean at all times.
• If the windshield is dirty or covered with an oily film, water droplets, snow, etc.,
clean the windshield.
• If a glass coating agent is applied to the wi ndshield, it will still be necessary to use
the windshield wipers to remove water droplets, etc. from the area of the wind-
shield in front of the front camera.
• If the inner side of the wind shield where the front camera is installed is dirty, con-
tact your Lexus dealer.
●If the part of the windshield in front of the front camera is fogged up or covered with
condensation or ice, use the windshield defogger to remove the fog, condensation or
ice. ( P. 388)
●If water droplets cannot be properly removed from the area of the windshield in front
of the front camera by the wi ndshield wipers, replace the wiper insert or wiper blade.
●Do not attach window tint to the windshield.
●Replace the windshield if it is damaged or cracked.
After replacing the windshield, the front ca mera must be recalibrated. Contact your
Lexus dealer for details.
●Do not allow liquids to contact the front camera.
●Do not allow bright lights to shine into the front camera.
●Do not dirty or damage the front camera.
When cleaning the inside of the windshield , do not allow glass cleaner to contact the
lens of the front camera. Also, do not touch the lens.
If the lens is dirty or damaged, contact your Lexus dealer.
●Do not subject the front camera to a strong impact.
●Do not change the installation position or direction of the front camera or remove it.
●Do not disassemble the front camera.
●Do not attach objects, such as stickers, trans-
parent stickers, etc., to the outer side of the
windshield in front of the front camera
(shaded area in the illustration).
A: From the top of the windshield to approxi-
mately 0.4 in. (1 cm) below the bottom of the
front camera
B: Approximately 7.9 in. (20 cm) (Approxi-
mately 4.0 in. [10 cm] to the right and left
from the center of the front camera)
Page 329 of 628
GX460_OM_OM60T19U_(U)
3294-5. Using the driving support systems
4
Driving
■Multi-terrain Monitor cameras
●Camera positions
The cameras of the Multi-terrain Monitor system are installed as follows.Side camera (left and right
sides)
Front camera
Rear camera
●Using the cameras
If dirt or foreign matter (such as water droplets, snow, mud, etc.) is adhering
to the camera, it cannot transmit a clear image. In this case, flush it with a
large quantity of water and wipe the camera lens with a soft and wet cloth.
1
2
3
NOTICE
■How to use the cameras
●Observe the following precautions. Failure to do so may prevent the Multi-terrain
Monitor from operating properly.
• Do not strike the camera area, or allow any objects to bump into it
If the camera or surrounding area has re ceived a strong impact, the camera posi-
tion, installation angle, etc., may deviate. If the camera is accidentally subjected to
an impact, have the vehicle inspected at your Lexus dealer.
• Do not remove, disassemble or modify the camera or surrounding parts
Doing so may result in the camera malfunct ioning. This also may result in a loss of
waterproof performance.
• If the camera lens is dirty, follow the above procedures to clean it
If the camera lens is damaged it cannot transmit a clear image.
Do not allow organic solvent, car wax, oil film remover, glass coating, etc. to con-
tact the camera cover
Doing so will negatively affect the camera co ver (resin). If this happens, wipe it off
immediately.
• When the outside temperature is cold, do not cause any sudden changes in tem-
perature, such as by applying hot water
●When washing the vehicle, do not apply water with a high-pressure washer to the
camera or surrounding area. Doing so ma y cause the camera to receive a strong
impact, and the camera may not operate properly
Page 529 of 628
5297-2. Steps to take in an emergency
GX460_OM_OM60T19U_(U)
7
When trouble arises
■If a message that indica tes the malfunction of front camera is displayed
The following systems may be suspended until the problem shown in the message is
resolved. ( P. 238, 518)
●PCS (Pre-Collision System)
●LDA (Lane Departure Alert)
●Automatic High Beam
●Dynamic radar cruise control
■If “Radar Cruise Control Unavailable” is shown
The dynamic radar cruise control sy stem cannot be used temporarily.
Use the system when it becomes available again.
■If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the maintenance
schedule
* should be performed s oon. Comes on approximatel y 4500 miles (7200 km)
after the message has been reset. If necessary, perform main tenance. Please reset the
message after the maintenance is performed. ( P. 449)
*: Refer to the separate “Scheduled Maintena nce” or “Owner’s Manual Supplement” for
the maintenance interval applicable to your vehicle.
■If “Maintenance Required Visit Your Dealer” is shown (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance on the
maintenance schedule
*.
Comes on approximately 5000 miles (8000 km) after the message has been reset.
(The indicator will not work properly unless the message has been reset.) Perform the
necessary maintenance. Please reset the message after the maintenance is performed.
( P. 449)
*: Refer to the separate “Scheduled Maintena nce” or “Owner’s Manual Supplement” for
the maintenance interval applicable to your vehicle.
■If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil should be scheduled to be changed.
Check the engine oil and change it if necessa ry. After changing the engine oil, make sure
to reset the message. ( P. 462)
■If “OIL MAINTENANCE REQU IRED” “Oil Maintenance Required Visit Your Dealer”
is shown
Indicates that the engine oil should be scheduled to be changed.
Check and change the engine o il, and oil filter by your Lexus dealer. After changing the
engine oil, make sure to reset the message. ( P. 462)
■If “Check Access System with Elec. Key” is shown
The smart access system with push-button star t may be malfunctioning. Have the vehicle
inspected by your Lexus dealer immediately.
Page 563 of 628
GX460_OM_OM60T19U_(U)
5638-1. Specifications
8
Vehicle specifications
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value be fore the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme lo ad conditions.
How to read oil container label:
The International Lubricant Specifi-
cation Advisory Co mmittee (ILSAC)
Certification Mark is added to some
oil containers to help you select the
oil you should use.
Outside temperature
Page 593 of 628
593
GX460_OM_OM60T19U_(U)8-3. Items to initialize
8
Vehicle specifications
Items to initialize
*1: U.S.A. only
*2: If equipped
The following item must be initialize
d for normal system operation after such
cases as the battery being reconnected , or maintenance being performed on
the vehicle:
ItemWhen to initializeReference
Message indicating mainte-
nance is required
*1After the maintenance is per-
formedP. 449
Oil maintenanceP. 462
Tire pressure warning system
• When rotating the tires
• When the tire inflation pressure is changed by changing tire size.
(When there are multiple speci-
fied pressures)
• After registering the ID codes
P. 474
Power windowWhen functioning abnormallyP. 161
Moon roofP. 164
Multi-terrain Monitor*2After reconnecting or changing the
batteryP. 337
