4756-3. Do-it-yourself maintenance
6
Maintenance and care
◆Registering ID codes
Every tire pressure warning valve and transmitter has a unique ID code.
When replacing a tire pressure warning valve and transmitter, it is necessary
to register the ID code.
When registering the ID codes, perform the following procedure.
Park the vehicle in a safe place, wait for approximately 20 minutes, and
then start the engine. ( P. 200)
Press or of the meter control switches and select .
Press or of the meter control switches and select “Vehicle
Settings”, and then press .
Press or of the meter control switches and select “TPWS”, and
then press .
Press or of the meter
control switches and select
“Change Wheel Set”, and then
press and hold until the tire
pressure warning light starts
slowly blinking 3 times.
Then a message will be displayed on
the multi-information display.
When registration is being performed, the tire pressure warning light will blink for
approximately 1 minute then illuminate and “--” will be displayed for the inflation
pressure of each tire on the multi-information display.
Drive at approximately 25 mph (40 km /h) or more for approximately 10 to
30 minutes.
Registration is complete when the tire pressure warning light turns off and the
inflation pressure of each tire is displayed on the multi-information display.
Even if the vehicle is not driven at approxim ately 25 mph (40 km/h) or more, reg-
istration can be completed by driving for a long time. However, if registration does
not complete after driving for 1 hour or more, perform the procedure again from
the beginning.
Initialize the tire pressure warning system. ( P. 474)
1
2
3
4
5
6
7

476
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
■When to replace your vehicle’s tires
Tires should be replaced if:
●The treadwear indicators are showing on a tire.
●You have tire damage such as
cuts, splits, cracks deep enough to expose the fabric, and
bulges indicating internal damage
●A tire goes flat repeatedly or cannot be properly repaired due to the size or location of
a cut or other damage
If you are not sure, consult with your Lexus dealer.
■Replacing tires and wheels
If the ID code of the tire pressure warning valve and transmitter is not registered, the tire
pressure warning system will not work proper ly. After driving for about 20 minutes, the
tire pressure warning light blinks for 1 minu te and stays on to indicate a system malfunc-
tion.
■Tire life
Any tire over 6 years old must be checked by a qualified technician even if it has seldom
or never been used or damage is not obvious.
■Routine tire inflation pressure checks
The tire pressure warning syst em does not replace routine tire inflation pressure checks.
Make sure to check tire inflat ion pressure as part of your routine of daily vehicle checks.
■Maximum load of tire
Check that the number given by dividing the maximum load by 1.10 of the replacement
tire is greater than 1/2 of the Gross Axle We ight Ratings (GAWR) of either the front axle
or the rear axle, whichever is greater.
For the GAWR, see the Certification Label. For
the maximum load of the tire, see the load limit
at maximum cold tire inflation pressure men-
tioned on the sidewall of the tire. ( P. 573)

GX460_OM_OM60T19U_(U)
4796-3. Do-it-yourself maintenance
6
Maintenance and care
■The initialization operation
●Make sure to carry out initialization after adjusting the tire inflation pressure.
Also, make sure the tires are cold before carryi ng out initialization or tire inflation pres-
sure adjustment.
●If you have accidentally turned the engine swit ch off during initialization, it is not neces-
sary to manually restart the in itialization again, as initialization will restart automatically
the next time the engine switch is turned to IGNITION ON mode.
●If you accidentally perform initialization when initialization is not necessary, adjust the
tire inflation pressure to the specified leve l when the tires are cold, and conduct initial-
ization again.
●While the position of each tire is being de termined and the inflation pressures are not
being displayed on the multi-info rmation display, if the inflation pressure of a tire drops,
the tire pressure warning light will come on.
■Warning performance of the tire pressure warning system
The warning of the tire pressu re warning system will change in accordance with the con-
ditions under which it was init ialized. For this reason, the system may give a warning even
if the tire pressure does not reach a low enough level, or if the pressure is higher than the
pressure that was adjusted to when the system was initialized.
■When initialization of the tire pressure warning system has failed
●Do not move the vehicle backward during in itialization. Initialization is started again
from the beginning and it ma y take longer than usual.
●Initialization may take longer to complete if the vehicle is driven on an unpaved road.
When performing initialization, drive on a paved road if possible. Depending on the
driving environment and cond ition of the tires, initialization will be completed in
approximately 10 to 30 minutes.
• If initialization is not comp lete after driving approximately 30 minutes, continue
driving for a while.
• If initialization is not complete after driv ing approximately 1 hour, park the vehicle in
a safe place for approximately 20 minutes. Then drive straight (with occasional left
and right turns) at approximat ely 25 mph (40 km/h) or more
* for approximately 10
to 30 minutes.
If initialization is still not complete, have the vehicle inspected by your Lexus dealer.
*: Except when making a left/right turn
●In the following situations, th e tire inflation pressure will not be recorded and the system
will not operate properly. Perform initialization again.
• If, when attempting to start initialization , the tire pressure warning light does not
blink 3 times.
• If, when the vehicle has been driven for ab out 20 minutes after performing initializa-
tion, the tire pressure warning light blinks for approximately 1 minute and then illumi-
nates.

480
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
■When registering ID codes
●ID code registration is performed while driving at a vehicle speed of approximately 25
mph (40 km/h) or more.
●Before performing ID code registration, make
sure that no wheels with tire pressure
warning valve and transmitters installed are near the vehicle.
●Initialize the tire pressure warning system after ID code registration. Initialization is dis-
abled if the system was init ialized before registration.
●After ID code registration, the tires are hot by driving. Initialize the tire pressure warn-
ing system after the tires become cold.
●ID codes can be registered by yourself, bu t depending on the driving conditions and
driving environment, registration may take some time to complete.
■Canceling the change wheel set mode
●If turning the engine switch off when in th e change wheel set mode before driving, the
change wheel set mode is canceled.
●After driving when in the ch ange wheel set mode, the change wheel set mode cannot
be canceled. To cancel the mode, perform th e procedure for ID code registration again
and turn the engine switch off before driving.
●If the change wheel set mode is canceled, the ID codes that have already been regis-
tered are communicated. When communication is finished, the tire pressure warning
light will turn off.
■When ID code registration has failed
●Registration may take long time or the ID codes may not be registered in the following
situations.
• When the vehicle is moved ba ckward during registration.
Registration is started again from the beginning and it may take longer than usual.
• When another vehicle is running the side of the vehicle such as in heavy traffic. It may take longer to detect the vehicle’s tire pressure warning valves and transmit-
ters.
• If tire pressure warning valves an d transmitters are in the vehicle.
The ID codes may not be registered.
●When performing registration , drive on a paved road if possible. Depending on the
driving environment and conditio n of the tires, registration will be completed in approx-
imately 10 to 30 minutes.
• If registration is not comple te after driving approximately 30 minutes, continue driv-
ing for a while.
• If registration is not complete after driving approximately 1 hour, park the vehicle in a safe place for approximately 20 minutes. Then drive straight (with occasional left
and right turns) at approximat ely 25 mph (40 km/h) or more
* for approximately 10
to 30 minutes.
If registration is still not complete, have the vehicle inspected by your Lexus dealer.
*: Except when making a left/right turn
●When the tire pressure warning light does not blink slowly 3 times, the ID code will not
be registered and the system will not operate properly. Perform registration again.

482
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
WARNING
■Tire pressure warning system operation
The tire pressure warning system may not provide warning immediat
ely if a tire bursts
or if sudden air leakage occurs.
■When inspecting or replacing tires
Observe the following precautions to preven t accidents. Failure to do so may cause
damage to parts of the drive train as well as dangerous handling characteristics, which
may lead to an accident result ing in death or serious injury.
●Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
●Do not use tire sizes other than those recommended by Lexus.
●Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
●Do not mix summer, all season and snow tires.
●Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.
■When initializing the tire pressure warning system
Do not initialize tire inflatio n pressure without first adjustin g the tire inflation pressure to
the specified level. Otherwise, the tire pre ssure warning light may not come on even if
the tire inflation pressure is low, or it ma y come on when the tire inflation pressure is
actually normal.

496
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (
P. 499)
●If the replaced fuse blows again, have th e vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
WARNING
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to th e vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage rati ng than indicated, or use any other object
in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wi re, even as a temporary fix.
●Do not modify the fuses or the fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload dete rmined and repaired by your Lexus dealer,
as soon as possible.

506
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
■LED lights
The headlights, parking lights/daytime running
lights, front side marker lights, fog lights,
side turn signal lights, high mounted stoplig ht, stop/tail lights and license plate lights con-
sist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Lexus
dealer to have the light replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:
●Large drops of water are built up on the inside of the lens.
●Water has built up inside the headlight.
WARNING
■Replacing light bulbs
●Turn off the headlights. Do not attempt to replace the bulb immediately after turning
off the headlights.
The bulbs become very hot and may cause burns.
●Do not touch the glass portion of the light bu lb with bare hands. When it is unavoid-
able to hold the glass portion, use and hold with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is sc ratched or dropped, it may blow out or crack.
●Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering th e headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.
●Do not attempt to repair or disassemble light bulbs, connectors, electric circuits or
component parts.
Doing so may result in death or se rious injury due to electric shock.
■To prevent damage or fire
●Make sure bulbs are fully seated and locked.
●Check the wattage of the bulb before installing to prevent heat damage.

507
GX460_OM_OM60T19U_(U)
7When trouble arises
7-1. Essential informationEmergency flashers ................. 508
If your vehicle has to be stopped in
an emergency ..........................509
If the vehicle is trapped in rising water ................................. 510
7-2. Steps to take in an emergency If your vehicle needs to be towed................................... 511
If you think something is wrong ............................................ 516
Fuel pump shut off system ........517
If a warning light turns on or a warning buzzer
sounds........................................... 518
If a warning message is displayed..................................... 527
If you have a flat tire ................... 531
If the engine will not start ........545
If the electronic key does not operate properly ............. 547
If the vehicle battery is discharged ................................ 550
If your vehicle overheats .........553
If the vehicle becomes stuck .............................................556

518
GX460_OM_OM60T19U_(U)7-2. Steps to take in an emergency
If a warning light turns on or a warning buzzer
sounds
Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system
. However, if this continues to occur,
have the vehicle inspecte d by your Lexus dealer.
Warning light and warning buzzer list
Warning lightWarning light/Details/Actions
(U.S.A.)
(Canada)
Brake system warning light (warning buzzer) Indicates that:
• The brake fluid level is low; or
• The brake system is malfunctioning.
 Immediately stop the vehicle in a safe place and contact your
Lexus dealer. Continuing to drive the vehicle may be dangerous.
Charging system warning light
Indicates a malfunction in the vehicle’s charging system
 Immediately stop the vehicle in a safe place and contact your
Lexus dealer.
Low engine oil pressure warning light*1
Indicates that the engine oil pressure is too low
 Immediately stop the vehicle in a safe place and contact your
Lexus dealer.
(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system
 Have the vehicle inspected by your Lexus dealer immediately.
High coolant temperature warning light (warning buzzer)*1
Indicates that the engine coolant temperature is too high
 Immediately stop the vehicle in a safe place. Handling method
( P. 553)
SRS warning light
Indicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system
 Have the vehicle inspected by your Lexus dealer immediately.

5197-2. Steps to take in an emergency
GX460_OM_OM60T19U_(U)
7
When trouble arises
(U.S.A.)
(Canada)
ABS warning light Indicates a malfunction in:
• The ABS; or
• The brake assist system
 Have the vehicle inspected by your Lexus dealer immediately.
(Flashes or illuminates)
PCS warning light
When a buzzer sounds simultaneously:
Indicates a malfunction has occu rred in the PCS (Pre-Collision
System).
 Have the vehicle inspected by your Lexus dealer immediately.
When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily unavail-
able, corrective action may be necessary.
 Follow the instructions displayed on the multi-information dis-
play. ( P. 238)
If the PCS (Pre-Collision System ) or VSC (Vehicle Stability Con-
trol) system is disabled, the PC S warning light will illuminate.
 P. 249
Slip indicator
Indicates a malfunction in:
• The Multi-terrain Select (if equipped);
• The Crawl Control (if equipped);
• The downhill assist cont rol system (if equipped);
• The VSC (Vehicle Stability Control) system;
• The TRAC (Traction Control) system;
• Active TRAC (Traction Control) system;
• Trailer Sway Control; or
• The hill-start assist control system
The light will flash when any of the above systems other than the
Multi-terrain Select are operating.
 Have the vehicle inspected by your Lexus dealer immediately.
(Flashes)
(U.S.A.)
(Flashes)
(Canada)Parking brake indicator
Indicates a malfunction in the parking brake system
 Have the vehicle inspected by your Lexus dealer immediately.
Kinetic dynamic suspension system warning light
Indicates a malfunction in the kin etic dynamic suspension system.
 Have the vehicle inspected by your Lexus dealer immediately.
Warning lightWarning light/Details/Actions
