air filter Lexus GX460 2021 Owner's Manual /

5
1
8 7
6
5
4
3
2
GX460_OM_OM60T19U_(U)
9
6-1. Maintenance and care Cleaning and protecting the vehicle exterior ................ 442
Cleaning and protecting the vehicle interior.................. 445
6-2. Maintenance Maintenance requirements ............................ 448
General mainte nance................451
Emission inspection and maintenance (I/M)
programs.................................... 454
6-3. Do-it-yourself maintenance Do-it-yourself service precautions................................ 455
Hood ............................................... 458
Engine compartment ............... 459
Tires ..................................................472
Tire inflation pressure .............. 484
Wheels ...........................................488
Air conditioning filter ............... 490
Electronic key battery.............. 492
Checking and replacing fuses.............................................. 494
Headlight aim .............................. 497
Light bulbs .................................... 499 7-1. Essential information
Emergency flashers ..................508
If your vehicle has to be stopped in
an emergency .......................... 509
If the vehicle is trapped in rising water ................................. 510
7-2. Steps to take in an emergency If your vehicle needs to be towed .................................. 511
If you think something is wrong.............................................516
Fuel pump shut off system........ 517
If a warning light turns on or a warning buzzer
sounds .......................................... 518
If a warning message is displayed .................................... 527
If you have a flat tire ....................531
If the engine will not start ........ 545
If the electronic key does not operate properly ............. 547
If the vehicle battery is discharged.................................550
If your vehicle overheats......... 553
If the vehicle becomes stuck ............................................. 556
6Maintenance and care7When trouble arises

GX460_OM_OM60T19U_(U)
3895-1. Using the air conditioning system and defogger
5
Interior features
■Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove raindrops, dew
and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
■Micro dust and pollen filter mode
Pollen is removed from the air and the air flows to the upper part of the body.
Touch on the option control screen.
When the micro dust and pollen filter mo de is on, is displayed on the air
conditioning control screen.
In order to prevent the windshield from fo gging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the mi cro dust and pollen filter mode is turned
off.
■Windshield wiper de-icer (if equipped)
This feature is used to prevent ice fr om building up on the windshield and
wiper blades.
Touch on the option control screen.
When the windshield wiper de-icer is on , is displayed on the air condition-
ing control screen.
The windshield wiper de-icer will automati cally turn off after a period of time.
■The windshield wiper de-icer can be operat ed when (vehicles with windshield wiper
de-icer)
The engine switch is in IGNITION ON mode.
■When the windshield wiper de-icer is on (vehicles with windshield wiper de-icer)
The windshield wiper de-icer will automatically turn off after approximately 15 minutes.
WARNING
■When the windshield wiper de-icer is on (vehicles with windshield wiper de-icer)
Do not touch the glass at the lower part of th e windshield or the side of the front pillars
as the surfaces can become very hot and burn you.

3925-1. Using the air conditioning system and defogger
GX460_OM_OM60T19U_(U)
■Automatic mode for air intake control (vehicles with rear air conditioning system)
In automatic mode, the system detects exhaust gas and other pollutants and automati-
cally switches between outside air and recirculated air modes.
When the dehumidification function is off, and the fan is operating, turning automatic
mode on will activate the dehumidification function.
■When the outside temperature is low
The dehumidification function may not operate even when “A/C” is touched.
■Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the outside air mode.
●During use, various odors from inside and outside the vehicle may enter into and accu-
mulate in the air conditioning system. This may then cause odor to be emitted from the
vents.
●To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior
to turning the vehicle off.
• The start timing of the blower may be dela yed for a short period of time immediately
after the air conditioning system is started in automatic mode.
■Air conditioning filter
P. 490
■Air conditioning system refrigerant
●The meaning of each symbol on the label are as follows:
●A label regarding the refrigerant of the air
conditioning system is attached to the hood at
the location shown in the following illustration.
Caution
Air conditioning system
Air conditioning system lubricant type
Requires registered technician to ser-
vice air conditioning system
Flammable refrigerant

441
GX460_OM_OM60T19U_(U)
6Maintenance and care
6-1. Maintenance and careCleaning and protecting the vehicle exterior ................ 442
Cleaning and protecting the vehicle interior.................. 445
6-2. Maintenance Maintenance requirements ............................448
General maintenance............... 451
Emission inspection and maintenance (I/M)
programs .................................... 454
6-3. Do-it-yourself maintenance Do-it-yourself service precautions................................455
Hood ...............................................458
Engine compartment ............... 459
Tires ................................................. 472
Tire inflation pressure...............484
Wheels .......................................... 488
Air conditioning filter ...............490
Electronic key battery .............. 492
Checking and replacing fuses .............................................. 494
Headlight aim .............................. 497
Light bulbs..................................... 499

GX460_OM_OM60T19U_(U)
4576-3. Do-it-yourself maintenance
6
Maintenance and care
WARNING
The engine compartment contains many mechanisms and fluids that may move suddenly,
become hot, or become electrically energize d. To avoid death or serious injury, observe
the following precautions:
■When working on the engine compartment
●Keep hands, clothing and tools away from the moving fan and engine drive belt.
●Be careful not to touch the engine, radiator, exhaust manifold, etc. right after driving
as they may be hot. Oil and other fluids may also be hot.
●Do not leave anything that may burn easily, such as paper or rags, in the engine com-
partment.
●Do not smoke, cause sparks or expose an open flame to fuel or the battery. Fuel and
battery fumes are flammable.
●Be extremely cautious when working on the battery. It contains poisonous and corro-
sive sulfuric acid.
■When working near the electric cooling fans or radiator grille
Be sure the engine switch is off. With the engine switch in IGNITION ON mode, the
electric cooling fans may auto matically start to run if the air conditioning is on and/or
the coolant temperature is high. ( P. 465)
■When working on or under the vehicle
Do not get under the vehicle with just the jack supporting it.
Always use automotive jack stands or other solid supports.
■Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting in
your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner f ilter removed may cause excessive engine wear due to dirt
in the air.

490
GX460_OM_OM60T19U_(U)6-3. Do-it-yourself maintenance
Air conditioning filter
Turn the engine switch off.
Open the glove box and remove the
glove box cover.
Remove the filter cover.
The air conditioning filter must be ch
anged regularly to maintain air condi-
tioning efficiency.
Removal method
1
2
3

GX460_OM_OM60T19U_(U)
4916-3. Do-it-yourself maintenance
6
Maintenance and care
Slide and pull out the filter. Replace
the filter with a new one.
The “UP” marks shown on the filter
should be pointing up.
■Changing interval
Inspect and replace the air cond itioning filter according to the maintenance schedule. In
dusty areas or areas with heavy traffic flow, early replacement may be required.
(For scheduled maintenance information, please refer to the “Owner’s Manual
Supplement” or “Scheduled Maintenance”.)
■If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
4
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the system.

614Alphabetical index
GX460_OM_OM60T19U_(U)
Alphabetical index
A/C ................................................ 384, 394Air conditioning filter....................... 490
ABS (Anti-lock Brake System)....... 355 Function ................................................. 355
Warning light ........................................ 519
Active Traction Control .................... 356
Air conditioning filter .......................... 490
Air conditioning system ......... 384, 394 Air conditioning filter....................... 490
Micro dust and pollen filter .......... 389
Airbags ........................................................ 36 Airbag operating conditions ........... 44
Airbag precautions for your child........................................ 39
Airbag warning light .......................... 518
Correct driving posture .................... 28
Curtain shield airbag operating conditions........................ 44
Curtain shield airbag precautions ........................................... 39
General airbag precautions............ 39
Locations of airbags ............................ 36
Modification and disposal of airbags ............................ 43
Side airbag operating conditions .............................................. 44
Side airbag precautions..................... 39
Side and curtain shield airbags operating conditions........................ 44
Side and curtain shield airbags precautions ........................................... 39
SRS airbags.............................................. 36
SRS warning light................................ 518
Alarm Alarm........................................................... 79
Warning buzzer .................................. 518 Anchor brackets...................................... 58
Antennas (smart access system
with push-button start) ..................... 125
Anti-lock brake system (ABS)........ 355 Function ..................................................355
Warning light .........................................519
Armrest ..................................................... 427
Assist grip ................................................ 428
Audio input
*
Audio system*
Automatic headlight leveling system ..................................... 215
Automatic High Beam ......................... 216
Automatic light control system ........ 214
Automatic transmission..................... 206 If the shift lever cannot be shifted from P ................................... 209
S mode.................................................... 207
AUX port
*
Auxiliary boxes .............................408, 411
AVS ........................................................... 343
Back door ................................................... 115
Back-up lights Replacing light bulbs .......................504
Wattage .................................................569
Battery ...................................................... 468 Battery checking ................................468
If the vehicle battery is discharged........................................ 550
Preparing and checking before winter .................................... 374
Warning light ........................................ 518
Bluetooth
®*
A
B
