For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xPage
1Automatic transmission second start
indicator light 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 49
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 51
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 303 . . . . . .
6Driver’s seat belt reminder light 45
. . . . . . . . . . . . . . . .
7Turn signal indicator light 25
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 44
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 25
. . . . . . . . . . . .
10“ABS” warning light 48
. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 49
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 24
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 312
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 51
. . . . . . . . . .
16Engine coolant temperature gauge 41
. . . . . . . . . . . . . Page
17Discharge warning light
50
. . . . . . . . . . . . . . . . . . . . . . .
18Low engine oil pressure warning light 50
. . . . . . . . . .
19Malfunction indicator lamp 47
. . . . . . . . . . . . . . . . . . . .
20Slip indicator light 322, 324, 327, 329
. . . . . . . . . . . . .
21Vehicle skid control system off
indicator light 324 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Center differential lock indicator light 309
. . . . . . . .
23“VSC TRAC” warning light 50
. . . . . . . . . . . . . . . . . . . . .
24Downhill assist control system
indicator light 326 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Rear height control indicator lights 319
. . . . . . . . . . .
26Security indicator light 12, 175
. . . . . . . . . . . . . . . . . . .
27SRS warning light 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Trip meter reset knob 42
. . . . . . . . . . . . . . . . . . . . . . . . .
29Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . .
30Low fuel level warning light 51
. . . . . . . . . . . . . . . . . . . .
31Fuel gauge 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

KEYS AND DOORS
22The back door can be locked and unlocked together with the
side doors by means of the power door lock system. (For
instructions, see “Locking with power door lock switch” on
page 20.)
See “Luggage stowage precautions” on page 81 for
precautions when loading luggage.
CAUTION

Keep the back door closed while driving. This not
only keeps the luggage from being thrown out but
also prevents exhaust gases from entering the
vehicle.
 If the open back door hides the rear stop and tail
lights or rear turn signal lights while you are parked,
other road users must be warned of the presence of
your vehicle by a warning triangle or other device.
Back door stopper
 1 Lock2 Unlock
For your safety, lock the back door with the door stopper
when you fully open the back door.
When closing the back door, check that the back door stopper
is unlocked.
CAUTION
 When keeping the back door open, use only the lock
lever of the back door stopper without touching the
other parts.
 To avoid serious person al injury, make sure not to get
your hands caught in the back door stay when
closing the back door.

SWITCHES
28The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see “Adding
washer fluid” on page 454.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may
scratch the glass.
Raindrop detection type

1 Automatic control adjuster

2 Washer on To turn the wipers on, move the lever down until you reach
the desired speed setting.
The ignition switch must be in the “ON” position.
There are 3 settings:
“AUTO” position: Automatic operation
“LO” position: Low speed operation
“HI” position: High speed operation
Automatic operation
The wiper speed is determined by the amount of raindrops
and sunlight detected by the automatic wiper control
sensor.
Twist
the automatic control adjuster in the “–” direction to
lower the sensitivity, and the “+” direction to boost the
sensitivity.
The sensor is on the inside of the windshield as shown above.

SWITCHES
30To make the washer squirt, pull the lever toward you and
release it.
If the wiper lever is in the “OFF” position, the wipers will
automatically make 3 wipes and then a single wipe later to
sweep the windshield completely.* The interval between the
3 wipes and the last wipe will depend on the vehicle speed. The
last sweep does not happen if the vehicle speed exceeds about
170 km/h (106 mph).
NOTE:
*The last single wipe can be deactivated.
Ask your Lexus dealer for details.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see “Adding
washer fluid” on page 454.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may
scratch the glass.
REAR WINDOW WIPER AND WASHER SWITCH
 1 Washer on during wiping

2 Washer on
To turn the wipers on, twist the knob at the end of the lever.
The ignition key must be in the “ON” position.
There are 2 settings:
“INT” position: Intermittent operation
“ON” position: Low speed operation
If you stop the vehicle with the rear window wiper switch in the
“ON” position, the wiper speed automatically changes from low
speed to intermittent operation speed.
To make the washer squirt, twist the knob downward to
position 2.

SWITCHES
31
To make the washer squirt while operating in “ON”
position, twist the knob upward to position 1.
The knob automatically returns from these positions after you
release it.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see “Adding
washer fluid” on page 454.
NOTICE
Do not operate the rear window wiper if the rear window
is dry. It may scratch the glass.
REAR WINDOW DEFOGGER
SWITCH
 Vehicles with navigation system
 Vehicles without navigation system

Finish
SECTION 1 – 3
39
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder indicators
Fuel gauge40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Engine coolant temperature gauge 41
. . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 43
. . . . . . . . . . . . . .
Multi−information display 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
40
FUEL GAUGE
 Low fuel level warning light
The gauge indicates the approximate quantity of fuel
remaining in the tank when the ignition switch is on.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches “E” or the low fuel level warning light\
comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible. It is not a malfunction even if the needle of the fuel gauge
returns to “E” when the ignition switch is turned to the “START”
position.
See the inner back cover for fuel capacity and recommended
fuel selection.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
43
SERVICE REMINDER INDICATORSAND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver’s seat
belt.
(c)Fasten front
passenger’s seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Take vehicle to Lexus
dealer.
IF THIS INDICATOR ORBUZZER COMES ON ...DO THIS.
(f)
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(g)Close all side doors
and back door.
(h)Shift four− wheel drive
control out of “N”.
(i)Stop and check.
(j)Take vehicle to Lexus
dealer.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
44IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(k)Stop and check.
(l)Stop and check.
(m)Replace engine oil.
(n)Fill up tank.
(o)Add washer fluid.
(p)Key reminder buzzerRemove key.
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the “ON” position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
in the “ON” position even after the parking brake is released.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
When the hydraulic brake booster fails ...
If the hydraulic booster causes a problem resulting in poor
braking performance, the warning light comes on and buzzer
sounds continuously.
Have your vehicle checked at your Lexus dealer in the
following cases:
 The light does not come on even if the parking brake is
applied when the ignition key is in the “ON” position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
45
CAUTION
If any of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
 The warning buzzer comes on together with the
warning light.
In either case, this can indicate that the brakes may not
work properly and your stopping distance will become
longer. Depress the brake pedal firmly and bring the
vehicle to an immediate stop.
 The brake system warning light remains on together
with the “ABS” warning light.
In this case, not only the antilock brake system will fail,
but also the vehicle will become extremely unstable
during braking.
Any of the following conditions may occur, but do not
indicate the malfunction:
 The light may stay on for about 60 seconds after the ignition
key is turned to the “ON” position. It is normal if it turns off
after a while.
 Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns off and
the buzzer stops sounding after a few seconds.
 You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Driver’s Seat Belt Reminder Light and
Buzzer
This light and buzzer remind you to buckle up the driver’s seat
belt.
Once the ignition key is turned to “ON” or “START”, the
reminder light flashes and buzzer sounds if the driver’s seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.
