GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
(f) “ABS” Warning Light
The light comes on when the ignition key is turned to the “ON”
position. If the anti−lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the following systems do not operate, but
the brake system still operates conventionally.
 Anti− lock brake system
 Brake assist system
 Active traction control system
 Vehicle skid control system
 Downhill assist control system
 Hill− start assist control system
When the “ABS” warning light is on (and the brake system
warning light is off), the anti −lock brake system does not
operate, so that the wheels will lock up during a sudden braking
or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
 The light comes on while you are driving. A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Either of the following conditions may occur, but do not
indicate a malfunction:

The light may stay on for about 60 seconds after the ignition
key is turned to the “ON” position. It is normal if it turns off
after a while.
 Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
(g) Open Door Warning Light
This light remains on until all the side doors and back door are
completely closed.
(h) Unengaged “Park” Warning Light
This light warns that the transmission “Park” mechanism is not
engaged. If the four −wheel drive control is in the “N” position
while the selector lever is in the “P” position, the transmission
will disengage and the wheels will not lock.
CAUTION
To restore the park function, shift the fourwheel drive
control out of “N”.
(i) Automatic Transmission Fluid Temperature Warning Light
This light warns that the automatic transmission fluid
temperature is too high.
If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in “P” and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go off, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(j) “VSC TRAC” Warning Light
The light warns that there is a problem somewhere in the
following.
Vehicle skid control system
 Active traction control system
 Downhill assist control system
 Hill− start assist control system
The light will come on when the ignition key turned to “ON”, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the “ON” position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the “VSC TRAC” warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
(k) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
(l) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on even
for one block. It may ruin the engine.
(m) Engine Oil Replacement Reminder Light
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to “ON”
and will go off after about a few seconds.
When you drive for about 8000 km (5000 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to “ON” position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds
12000 km (7500 miles), the light will come on after the
ignition key is turned to “ON” position. The light will remain on
thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible. You need to reset the light after the engine oil replacement.
Reset the light by following the procedure below:
1. Turn the ignition key to the “OFF” position with the odometer
reading
shown. (For details, see “Odometer and trip meter” on
page 42.)
2. Turn the ignition key to the “ON” position while holding down
the trip meter reset knob.
Hold down the knob until the light goes off. Before the light
goes off, it illuminates for 3 seconds, flashes for 2 seconds and
illuminates for 1 second.
If the system fails to reset, the light will remain flashing. In this
case, return to step 1 and try again.
(n) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(o) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(p) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver’s door with the ignition key in the “ACC” or “LOCK”
position.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four−wheel drive control lever in “N” position and
the selector lever in “P” position and turn the ignition key to
“ACC”.
The following service reminder indicator should come on. It
goes off when you place the four −wheel drive control lever in
“H” or “L” position.
4. Turn the ignition key to “ON”.
The following service reminder indicators should come on.

w72a
w73
The following service reminder indicator goes off after a few
seconds.

The anti −lock brake system warning light, vehicle skid control
system off indicator light and vehicle skid control system and
active traction control system warning light may stay on for
about 60 seconds after the ignition key is turned to the “ON”
position. It is normal if they go out after a while.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
53
The following service reminder indicator should come on. It
goes off after about 6 seconds.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
MULTIINFORMATION DISPLAY
13PY018

1 “MODE” button 2 “” button

3 “” button 4 “RESET” button

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
54The multiinformation display provides various
information, including clock, outside temperature, and
your vehicle’s driving condition.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multi−information display, the
display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
You can adjust the brightness of the display. To adjust the
brightness, see “ADJUSTING THE BRIGHTNESS OF THE
DISPLAY” below. ADJUSTING THE BRIGHTNESS OF THE DISPLAY
The key must be in the “ACC” or “ON” position. To adjust the
brightness of
the display, push and hold the “MODE” button for
more than 2 seconds. “ILL” will appear on the display.
To increase the brightness − Push the “
” button.
To decrease the brightness − Push the “
” button.
You can adjust the brightness to 3 levels (when the tail lights
are off) or 6 levels (when the tail lights are on).
After adjusting, the display automatically return to the previous
display.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
55
Clock
The digital clock indicates the time when the key is in the
“ACC” or “ON” position.
To reset the time, push and hold the “MODE” button for 2
seconds. “ILL” will appear on the display. Then push the
“MODE” button once. The time will blink.
To reset the hour − Push the “
” button.
To reset the minutes − Push the “
” button.
To adjust the time to the nearest hour, push the “RESET”
button. For example, if the “RESET” button is depressed when
the time is between 1:01 − 1:29, the time will change to 1:00.
If the time is between 1:30 − 1:59, the time will change to 2:00.
If the electric power source has been disconnected, the time
display will automatically be set to 1:00.
Outside temperature and cruise information
The following information is shown with the ignition
switch turned on. Each time you push the “MODE” button,
the display toggles through this information.
 Outside temperature mode
 Average fuel consumption mode
 Instantaneous fuel consumption mode
 Driving range mode
 Average vehicle speed mode
 Barometer mode
 Altimeter mode
 Elapsed time mode
The displayed values indicate general driving conditions.
Accuracy varies with driving habits and road conditions.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
56
Outside temperature mode
In outside temperature mode, outside air temperatures
are displayed.
The displayed value is updated every 1 second.
The displayed temperature ranges from −22F (− 30C) up to
122 F (50C).
If there is some abnormality in the connection of the outside air
temperature sensor, “ −−” will appear on the display. If “ −−”
appears on the display, contact your Lexus dealer.
In some cases, “ −−” may appear momentarily when the ignition
is quickly turned to “ON”. It is normal if it goes out soon.
Average fuel consumption modeAverage fuel consumption is calculated and displayed
based on total driving distance and total fuel consumption
with the engine running.
The displayed value is updated every 10 seconds.
To reset the calculations, push and hold the “RESET” button for
more than 1 second.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
57

Instantaneous fuel consumption mode
Instantaneous fuel consumption is calculated and
displayed based on distance and fuel consumption for 2
seconds with the engine running.
The displayed value is updated every 2 seconds.
Note that an accurate figure may not be shown in the following
cases.
 When the vehicle is stopped with the engine running, the
display will indicate extremely high fuel consumption.
 When the vehicle is driving down a long slope, with the
engine brake applied, the display will indicate extremely low
fuel consumption.
To reset the calculations, push and hold the “RESET” button for
more than 1 second.
Driving range modeThe distance the vehicle can travel with the remaining fuel
is calculated and displayed based on the quantity of
remaining fuel and past fuel consumption.
The driving range display indicates the approximate distance
that you can drive until the fuel gauge reaches “E”. It is dif ferent
from the actual distance traveled.
The displayed value is updated every time the fuel required to
travel 0.6 miles (1 km) is consumed.
Every time you refuel the vehicle, the calculation is reset.
The actual driving range varies with driving habits and road
conditions. If fuel consumption is good, the driving range will
be longer. If fuel consumption is poor, the driving range will be
shorter.
If the low fuel level warning light comes on, refuel even if the
display indicates that the vehicle can be driven further.
