INTERIOR EQUIPMENT
90
PERSONAL LIGHTS
1ªDOORº position2ªOFFº position
To turn on the personal light, push the lens. To turn the
light off, push the lens once again.
The personal light switch has the following positions:
ªDOORº Ð Turn the lights on when any side door is opened
without pushing the lens. The light goes off when all the doors
are closed. For details, see ªIlluminated entry systemº on page
90.
ªOFFº Ð Turn the lights on only when you push the lens.
ILLUMINATED ENTRY SYSTEM
14PY027

INTERIOR EQUIPMENT
91

1Foot lights
2Ignition switch light
3Personal lights (with the ªDOORº position)
4Center console spot lights
5Inside door handle lights
6Center interior light (with the ªDOORº position)
7Running board lights
All of the lights except the center console spot lights will
come on when any of the side doors are opened.* After all
the doors are closed, the lights remain on for about 15
seconds before fading out.**
NOTE:
* The operating condition can be changed.** The duration of lighting can be changed, and the footlights and inside door handle lights can be set not to comeon.Ask your Lexus dealer for details.
However, in the following cases, the lights go out immediately:
 All of the lights except the center console spot lights Ð All
the side doors and back door are locked.
 Ignition switch light, personal lights and center interior light
Ð All the side doors are closed and the ignition key is in the
ªACCº or ªONº position.
 Running board lights Ð The vehicle speed exceeds about
8 km/h (5 mph). When
any of the side doors is unlocked, all of the lights except
the center console spot lights will come on and remain on for
about 15 seconds before fading out.
To prevent the battery being discharged, all of the lights will
automatically turn off when the ignition key removed and the
door is left opened for about 30 minutes.
Ignition switch light, personal lights and center interior
light
The ignition switch light, personal lights and center interior light
also come on and remain on for about 15 seconds before
fading out when the ignition switch is turned to the ªLOCKº
position.
Foot lights and inside door handle lights
The foot lights and inside door handle lights also come on when
the ignition switch is in the ªONº position with the selector lever
in the ªPº position. When the selector lever is moved out of ªPº\
position, the intensity of the foot lights and inside door handle
lights will be reduced.*
NOTE: * The intensity of the foot lights and inside door handle lightscan be set not to be reduced.Ask your Lexus dealer for details.
Center console spot lights
The center console spot lights come on when the ignition
switch is in the ªACCº or ªONº position.

INTERIOR EQUIPMENT
92
CIGARETTE LIGHTER ANDASHTRAY
Front
To use the cigarette lighter and ashtray, first push against
the cigarette lighter and ashtray covers. Then when the
cigarette lighter cover opens, press in the cigarette lighter.
After it finishes heating up, it automatically pops out ready
for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
ªACCº position to use the lighter. When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, press down on the lock spring plate and
pull out.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always completely close the
ashtray after use.

INTERIOR EQUIPMENT
93
Rear
To use the ashtray, raise the lid.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, raise the lid and pull it out.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always completely close the
ashtray after use.
POWER OUTLETS
12 VDC
The power outlet is designed for power supply for car
accessories.
The ignition key must be in the ªACCº or ªONº position for t\
he
power outlet to be used.

INTERIOR EQUIPMENT
94
NOTICE
To prevent the fuse from being blown, do not use theelectricity over the total vehicle capacity of 12VDC/120W.
To prevent the battery from being discharged, do notuse the power outlet longer than necessary when theengine is not running.
Close the power outlet lid when the power outlet isnot in use. Inserting anything other than anappropriate plug that fits the outlet, or allowing anyliquid to get into the outlet may cause electricalfailure or short circuits.
11 5 VA C
This power outlet is designed for use as a power supply
for electric appliances in the vehicle. The key must be in the ªONº position for the power outlet to be
used.
The maximum capacity for this power outlet is 115 V
AC/100W.
If you attempt to use an appliance that requires more than 115
VAC or 100W, the protection circuit will activate and cut the
power supply. The power supply will restart automatically
when you use an appliance that operates within the 115
VAC/100W limits.

INTERIOR EQUIPMENT
95
Main switch
To use the power outlet, push the main switch on the
instrument panel.
An indicator light will illuminate to indicate that the power outlet
is ready for use.
Push the main switch once again to turn the power outlet off.
When the power outlet is not in use, make sure that the main
switch is turned off.

INTERIOR EQUIPMENT
96
NOTICE
To prevent the battery from being discharged, do notuse the power outlet longer than necessary when theengine is not running.
Close the power outlet lid when the power outlet isnot in use. Inserting anything other than anappropriate plug that fits the outlet, or allowing anyliquid to get into the outlet may cause electricalfailure or short circuits.
The power outlet is not designed for the following electric
appliances even though their power consumption is
under 115 VAC/100W. These appliances may not operate
properly.
 Appliances with high initial peak wattage: Cathode±ray
tube type televisions, compressor±driven refrigerators,
electric pumps, electric tools, etc.
 Measuring devices which process precise data: Medical
equipment, measuring instruments, etc.
 Other appliances requiring an extremely stable power
supply: Microcomputer±controlled electric blankets, touch
sensor lamps, etc.
Certain electrical appliances may cause radio noise.GLOVE BOX
1Unlock2Open3Lock
To use the glove box:
Open by pulling the lever.
Lock by inserting the master key and turning it clockwise.

INTERIOR EQUIPMENT
97
Unlock by inserting the master key and turning it
counterclockwise.
With the tail lig
hts on, the glove box light will come on when the
glove box door is open.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.
REAR CONSOLE BOX
To access the rear console box, push the center of the lid.
The rear console box light comes on when the tail lights are
turned on.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the rear console box closed
while driving.

INTERIOR EQUIPMENT
98
GARAGE DOOR OPENER
The garage door opener (Universal
Transceiver) is manufactured under license from
HomeLink
 and can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting
systems, and security systems, etc.
(a) Programming the HomeLink
1Indicator light2Buttons
The HomeLink in your vehicle has 3 buttons and you can
store one program for each button.
To ensure correct programming into the HomeLink
, install a
new battery in the hand±held transmitter prior to programming. The battery side of the hand±held transmitter must be pointed
away from the HomeLink
 during the programming process.
For Canadian users, follow the procedure in ªProgramming an
entrance gate/programming all devices in the Canadian
marketº.
1. Decide which of 3 HomeLink
 buttons you want to program.
2. Place your hand±held garage transmitter 25 to 75 mm (1 to
3 in.) away from the surface of the HomeLink
.
Keep the indicator light on the HomeLink
 in view while
programming.
3. Simultaneously press and hold the hand±held garage
transmitter button along with the selected HomeLink
 button.
4. When the indicator light on the HomeLink
 changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
5. Test the operation of the HomeLink
 by pressing the newly
programmed button. If programming a garage door opener,
check to see if the garage door opens and closes.
If the garage door does not operate, identify if your garage
transmitter is of the ªRolling Codeº type. Press and hold the
programmed HomeLink
 button. The garage door has the
rolling code feature if the indicator light (on the HomeLink)
flashes rapidly and then remains lit after 2 seconds. If your
garage transmitter is the ªRolling Codeº type, proceed to the
heading ªProgramming a rolling code systemº.

INTERIOR EQUIPMENT
99
6. Repeat steps 2 through 5 for each remaining HomeLink

button to program another device.Programming a rolling code system
If your device is ªRolling Codeº equipped, it is necessary
to follow steps 1 through 4 under the heading
ªProgramming the HomeLink
º before proceeding with
the steps listed below.
1. Locate the ªtrainingº button on the ceiling mounted garage
door opener motor. The exact location and color of the button
may vary by brand of garage door opener. Refer to the owner's
guide supplied by the garage door opener manufacturer for the
location of this ªtrainingº button.
2. Press the ªtrainingº button on the ceiling mounted garage
door opener motor.
Following this step, you have 30 seconds in which to initiate
step 3 below.
3. Press and release the vehicle's programmed HomeLink

button twice. The garage door may open. If the door does
open, the programming process is complete. If the door does
not open, press and release the button a third time. This third
press and release will complete the programming process by
opening the garage door.
The ceiling mounted garage door opener motor should now
recognize the HomeLink
 unit and be able to activate the
garage door up/down.
4. Repeat steps 1 through 3 for each remaining HomeLink

button to program another rolling code system.
