light Lexus IS F 2011 User Guide

IS F_EE
19
Personal lights P. 323
Interior lights P. 322
A
: If equipped
*2: Refer to “Navigation System Owner's
Anti-glare inside rear view mirror
P. 78Personal lights
P. 323Moon roof switches P. 85
Interior lights
P. 322
Vanity mirrors
P. 331Sun visors P. 330
Coat hooks P. 344
SRS curtain shield airbags
P. 105

IS F_EE
21
Seat heater switches P. 339
Automatic transmission shift lever P. 149
Shift lock override button
P. 456
Cigarette lighter 
Ashtray

Auxiliary box

P. 337
P. 336
P. 329
C
: If

IS F_EE
22
Pictorial indexInstrument panel
(Right-hand drive vehicles)
Headlight switch
Turn signal lever
Fog light switch P. 172
P. 158
P. 175
Paddle shift switches P. 152, 154
Gauges and meters
P. 161
Multi-information display
P. 167
Windshield wiper
and washer switch
P. 176
Engine (ignition)
switch
P. 145
Trunk opener
main switch
P. 57
Glove box P. 325
Tilt and telescopic
steering control switch
P. 76
Parking brake pedal P. 159
Hood release lever
P. 362
Horn P. 160

IS F_EE
25
VSC off switch
P. 206
SNOW mode switch P. 151
D
Distance switch  P. 184
Headlight cleaner switch P. 179
Satellite switches P. 333
Fuel filler door opener P. 89
EInstrument panel light control knob P. 162
: If equipped
*2: Refer to the “Navigation System Owner’s
Trunk opener P. 57

IS F_EE
28
CAUTION
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your
vehicle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the cigarette lighter, the windows, the moon roof, or other features of the
vehicle. In addition, heat build-up or extremely cold temperatures inside the
vehicle can be fatal to children.
Your vehicle contains batteries and/or accumulators. Do not discard them into
the environment but cooperate with separate collection (Directive 2006/66/
EC).

37
1-1. Key information
1
Before driving
IS F_EE
To prevent key damage
Observe the following:
Do not drop the keys, subject them to strong shocks or bend them.
Do not expose the keys to high temperatures for a long period of time.
Do not get the keys wet or wash them in an ultrasonic washer etc.
Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
Do not disassemble the keys.
Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems, glass top ranges, or medical electrical equipment,
such as low-frequency therapy equipment.
Precautions for handling the card keys
Do not apply excess force when inserting the mechanical key to the card
key. Doing so may damage the card key.
If the battery or card key terminals get wet, the battery may corrode and
the card key may stop working.
If the key is dropped into water, or if drinking water etc. is spilled on the
key, immediately remove the battery cover and wipe the battery and ter-
minals. (To remove the battery cover, lightly grasp and pull it.) If the bat-
tery is corroded, have any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional, replace the battery.
Do not crush the battery cover or use a screwdriver to remove the battery
cover. Forcibly removing the battery cover may bend or damage the key.
If the battery cover is frequently removed, the battery cover may become
loose.
When installing the battery, make sure to check the direction of the bat-
tery.
Installing the battery in the wrong direction may cause the battery to
deplete rapidly.
The surface of the card key may be damaged, or its coating may peel off
in the following situations.
• The card key is carried together with hard objects, such as coins or
keys.
• The card key is scraped with a sharp object, such as a tip of mechanical
pencil.
• The surface of the card key is wiped with thinners or benzene.

60
1-2. Opening, closing and locking the doors and trunk
IS F_EE
Trunk light
When the trunk light switch is set to on, the trunk light turns on when the
trunk is opened.
Trunk handle
Using the mechanical key
The trunk can be also opened using the mechanical key. (P. 458)
Which key to the vehicle is to leave with a parking attendant after disabling
the trunk opener main switch
P. 3 4
On
Off
Use the trunk handle when closing the
trunk.
Be careful not to pull the trunk lid side-
ways when closing the trunk with the
handle.

62
1-2. Opening, closing and locking the doors and trunk
IS F_EE
CAUTION
Using the trunk
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.
Remove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to fall closed again
after it is opened.
When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.
If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.
Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.
Do not attach any accessories other than genuine Lexus parts to the trunk
lid. Such additional weight on the trunk lid may cause the lid to fall closed
again after it is opened.
The trunk lid may fall if it is not
opened fully. It is more difficult to
open or close the trunk lid on an
incline than on a level surface, so
beware of the trunk lid unexpectedly
opening or closing by itself. Make
sure that the trunk lid is fully open
and secure before using the trunk.
When closing the trunk lid, take extra
care to prevent your fingers etc. from
being caught.
When closing the trunk lid, make
sure to press it lightly on its outer
surface. If the trunk handle is used to
fully close the trunk lid, it may result
in hands or arms being caught

75
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
CAUTION
Seat belt damage and wear
Inappropriate handling of the pretensioner may prevent it from operating
properly resulting in death or serious injury.
Do not damage the seat belts by allowing the belt, plate, or buckle to be
jammed in the door.
Inspect the seat belt system periodically. Check for cuts, fraying, and
loose parts. Do not use a damaged seat belt until it is replaced. Damaged
seat belts cannot protect an occupant from death or serious injury.
Ensure that the belt and tab are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.
Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there's no obvious damage.
Do not attempt to install, remove, modify, disassemble or dispose of the
seat belts. Have any necessary repairs carried out by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Seat belt pretensioners
If the pretensioner has activated, the SRS warning light will come on. In that
case, the seat belt cannot be used again and must be replaced at any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.

79
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
Anti-glare inside rear view mirror
Adjusting the height of rear view mirror
Adjust the height of the rear
view mirror by moving it up
and down.
In automatic mode, sensors are used to detect the headlights of vehi-
cles behind and automatically reduce the reflected light.
Turns automatic mode on/off
The indicator comes on when
automatic mode is turned on.
The anti-glare mirror default
mode is automatic. The anti-
glare mirror is automatically
set to automatic whenever the
“ENGINE START STOP”
switch is turned IGNITION
ON d
