1-3. Adjustable components (seats, mirrors, steering wheel)
Front seats
CAUTION
Seat adjustment
Do not recline the seat more than necessary when the vehicle is in motion to
reduce the risk of sliding under the lap belt.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen or your neck may contact the shoul-
der belt, increasing the risk of death or serious injury in the event of an acci-
dent.
Seat position switch
Seatback angle switch
Seat cushion (front) angle switch
Vertical height adjustment switch
Lumbar support switch

65
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
To cancel seat position recall
Perform any of the following operations.
Push the “SET” button.
Push button “1”, “2” or “3”.
Adjust the seat using the switches (only cancels seat position recall).
If the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas-
senger or squeeze your body against the steering wheel.

67
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
Operating the seat position memory after turning the “ENGINE START
STOP” switch OFF
Memorized position can be activated up to 180 seconds after the front pas-
senger door is opened, even after turning the “ENGINE START STOP”
switch OFF.
To cancel seat position recall
Perform any of the following operations.
Push the “SET” button.
Push button “1”, “2” or “3”.
Adjust the seat position using the switches.
If the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas-
senger.

68
1-3. Adjustable components (seats, mirrors, steering wheel)
IS F_EE
Head restraints
Removing the head restraints (front seats)
Vertical adjustment (front
seats)
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Folding operation (rear seats)
To stow the head restraint by
folding it forward, pull the
head restraint up while push-
ing the lock release button.
Only the button on the right
stay (when facing the front of
the vehicle) can be used to
Lock release but-
Lock release but-
Pull the head restraint up while pushing
the lock release button.

77
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
The steering wheel can be adjusted when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automat-
ically by the driving position memory. (P. 6 2 )
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
It is possible to deactivate the auto tilt-away function.
(Customizable features P. 484)

82
1-3. Adjustable components (seats, mirrors, steering wheel)
IS F_EE
The mirrors can be operated when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
When the mirrors are fogged up
Turn on the mirror defoggers to defog the mirrors. (P. 236)
One-touch adjustment of the mirror angle
A desired mirror face angle can be entered to memory and adjusted with the
touch of a button. (P. 6 2 )
Linked mirror function when reversing
The outside rear view mirrors will automatically angle downwards when the
vehicle is reversing in order to give a better view of the ground. However,
this function will not operate when the mirror select switch is in the neutral
position (between “L” and “R”).
Auto anti-glare function
When the anti-glare inside rear view mirror is set to automatic mode, the
outside rear view mirrors will activate in conjunction with the anti-glare
inside rear view mirror to reduce reflected light. (P. 7 9 )

104
1-7. Safety information
IS F_EE
CAUTION
While driving
Do not adjust the position of the driver's seat while driving.
Doing so could cause the driver to lose control of the vehicle.
Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint, increasing the risk of
death or serious injury to the driver or passenger.
Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat
tracks and stop the seat from locking in place. This may lead to an acci-
dent. The adjustment mechanism may also be damaged.
Adjusting the seat position:
Take care when adjusting the seat position to ensure that other passengers
are not injured by the moving seat.
Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

218
2-4. Using other driving systems
IS F_EE
When passing an oncoming vehicle on a right-turn (right-hand drive
countries) or left-turn (left-hand drive countries)
When your vehicle rapidly closes on the vehicle in front
When a grade separation/interchange, sign, billboard, or other structure
appears to be directly in the vehicle's line of travel.
When an overhead billboard or other metallic structure appears to be in
the vehicle’s direct line of travel due to driving on a hill.
When an extreme change in vehicle height occurs
When the axis of the radar is out of adjustment
When passing through certain toll gates
When driving on a bridge.
When the system is activated in the situations described above there is also a
possibility that the seat belts will retract quickly and the brakes will be
applied with a force greater than normal. When the seat belt is locked in the
retracted position, stop the vehicle in a safe place, release the seat belt and
refasten.
When there is a malfunction in the system
Warning lights and/or warning messages will turn on or flash. (P. 425,
431)
Situations in which the pre-crash safety system does not function properly
The system may not function effectively in situations such as the following:
On roads with sharp bends or uneven surfaces
If a vehicle suddenly moves in front of your vehicle, such as at an inter-
section
If a vehicle suddenly cuts in front of your vehicle, such as when overtak-
ing
In inclement weather such as heavy rain, fog, snow or sand storms
When your vehicle is skidding with the VSC system off
When an extreme change in vehicle height occurs
When the axis of the radar is out of adjustment
Automatic cancelation of the pre-crash safety system
When a malfunction occurs due to sensor contamination, etc. that results in
the sensors being unable to detect obstacles, the pre-crash safety system will
be automatically disabled. In this case, the system will not activate even if
there is a collision possibility.

495
Alphabetical index
IS F_EE
First-aid kit storage belt ............347
Floor mat ...................................345
Fluid
Washer ..................................378
Fog lights
Replacing light bulbs ............407
Switch ...................................175
Wattage .................................481
Footwell lights ...........................320
Front fog lights
Replacing light bulbs ............407
Switch ...................................175
Wattage .................................481
Front passenger's seat belt
reminder light..........................428
Front position lights
Replacing light bulbs ............407
Switch ...................................172
Wattage .................................481
Front seats
Adjustment .............................61
Driving position memory .......62
Seat position memory .............66
Front turn signal lights
Wattage .................................481Fuel
Capacity ............................... 474
Fuel gauge............................ 161
Fuel pump shut off system... 424
Gas station information ....... 504
Information .......................... 482
Refueling ............................... 89
Fuel door..................................... 89
Fuel filler door ............................ 89
Fuel pump shut off system ....... 424
Fuses ......................................... 393
Gas station information ............ 504
Gauges ...................................... 161
Glove box ................................. 325
Glove box light ......................... 325
Hands-free system for mobile
phone* .................................... 293
Hazard lights
Switch .................................. 416
Head restraints
Adjusting .............................. 68
Headlight cleaner...................... 179F
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s
G
H

498
Alphabetical index
IS F_EE
Seat belts
Adjusting the seat belt ........... 70
Child restraint system
installation ......................... 124
Cleaning and maintaining
the seat belts ...................... 354
Emergency locking retractor . 72
How to wear your seat belt .... 70
How your child should wear
the seat belt.......................... 73
Pregnant women, proper seat
belt use ................................ 73
Reminder light ..................... 428
Seat belt pretensioners ........... 72
Seat heaters ............................... 339
Seat position memory ................. 66
Seats
Adjustment............................. 61
Adjustment precautions ......... 61
Child seats/child restraint
system installation ............. 124
Cleaning ............................... 353
Driving position memory....... 62
Front passenger seat position
memory ............................... 66
Head restraints ....................... 68
Properly sitting in the seat ... 103
Seat heaters .......................... 339
