Lexus IS200t 2016 Navigation Manual / LEXUS 2016 IS200T,IS300,IS350 OWNERS MANUAL (OM53D18U)
Manufacturer: LEXUS, Model Year: 2016, Model line: IS200t, Model: Lexus IS200t 2016Pages: 600, PDF Size: 7.94 MB
Page 271 of 600

2714-6. Driving tips
4
Driving
IS350/300/200t_U (OM53D18U)
Park the vehicle and move the shift lever to P without setting the parking brake.
The parking brake may freeze up, preventing it from being released. If necessary,
block the wheels to prevent inadvertent sliding or creeping.
Except vehicles with 18-inch tires
Use the correct tire chain size when mounting the tire chains.
Chain size is regulated for each tire size.
Side chain
(0.12 in. [3 mm] in diameter)
Cross chain
(0.16 in. [4 mm] in diameter)
Vehicles with 18-inch tires
Tire chains cannot be mounted.
Snow tires should be used instead.
Regulations regarding the use of tire chains vary depending on location and type
of road. Always check local regulations before installing chains.
■Tire chain installation
Observe the following precautions wh en installing and removing chains:
●Install and remove tire chains in a safe location.
●Install tire chains on the rear tires. Do not install tire chains on the front tires.
●Install tire chains on rear tires as tightly as possible. Retighten chains after driving 1 /4
1 /2 mile (0.5 1.0 km).
●Install tire chains following the instru ctions provided with the tire chains.
When parking the vehicle
Selecting tire chains
1
2
Regulations on the use of tire chains
Page 272 of 600

2724-6. Driving tips
IS350/300/200t_U (OM53D18U)
CAUTION
■Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of ve hicle control and cause death or serious injury.
●Use tires of the specified size.
●Maintain the recommended level of air pressure.
●Do not drive in excess of 75 mph (120 km/h), regardless of the type of snow tires
being used.
●Use snow tires on all, not just some wheels.
●Do not use LKA (Lane Keeping Assist) system.
■Driving with tire chains (except vehicles with 18-inch tires)
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely, and may
cause death or serious injury.
●Do not drive in excess of the speed limit specified for the tire chains being used, or 30
mph (50 km/h), whichever is lower.
●Avoid driving on bumpy road surfaces or over potholes.
●Avoid sudden acceleration, ab rupt steering, sudden braking and shifting operations
that cause sudden engine braking.
●Slow down sufficiently before entering a cu rve to ensure that vehicle control is main-
tained.
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Lexus dealers or legitimate tire
retailers.
This is because the removal and attachment of snow tires affects the operation of the
tire pressure warning valves and transmitters.
■Fitting tire chains (except vehicles with 18-inch tires)
The tire pressure warning valves and transmitters may not function correctly when tire
chains are fitted.
Page 273 of 600

2734-6. Driving tips
4
Driving
IS350/300/200t_U (OM53D18U)
Page 274 of 600

274
IS350/300/200t_U (OM53D18U)
5-1. Basic OperationsLexus Display Audio System .......................................... 276
Steering wheel audio switches........................................ 281
Mobile Assistant......................... 282
USB/AUX ports ......................... 284
5-2. Setup Setup menu .................................. 286
General settings ......................... 287
Voice settings .............................. 290
Display settings ............................ 291
5-3. Using the audio system Selecting the audio source .......................................... 292
Optimal use of the audio system .......................................... 293
Audio settings.............................. 294
Audio menu screen operation .....................................297
5-4. Using the radio Radio operation ......................... 300
Lexus DisplayAudio system
5
Page 275 of 600

275
Lexus DisplayAudio system
5
IS350/300/200t_U (OM53D18U)
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation................ 306
5-6. Using an external device Listening to an iPod .................... 312
Listening USB memory device ............................................ 315
Using the AUX port................... 319
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 320
Registering a Bluetooth
®
device ...........................................322
Selecting a Bluetooth
®
device ...........................................323
Connecting a Bluetooth
®
audio player ............................... 324
Connecting a Bluetooth
®
phone ...........................................325
Displaying a Bluetooth
®
device details ............................ 326
Detailed Bluetooth
®
settings........................................ 327
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ............................................328 5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone ...........................................330
Making a call ................................ 332
Receiving a call ........................... 335
Speaking on the phone............ 336
Using a Bluetooth
®
phone message........................338
Using the steering wheel switches.......................................340
Bluetooth
® phone
settings ......................................... 341
5-10. Phonebook Contact settings ......................... 343
Messaging setting...................... 346
5-11. Bluetooth
®
What to do if... (Troubleshooting).................... 347
Bluetooth
®.................................... 351
5-12. Other function “Information” screen ................. 356
USB photo ....................................358
Weather information ................360
Voice command system ............361
LEXUS Enform Remote ......... 365
Page 276 of 600

276
IS350/300/200t_U (OM53D18U)5-1. Basic Operations
Lexus Display Audio System
: If equipped
Use the following buttons to start listening to the audio system.
Display Audio operation buttons
Eject a disc.
Seek up or down for a radio station, or to access a desired track or file.
Except radio and A/V mode: Pause or resume playing a track.
Radio and A/V mode: Turn mute on/off
Select a radio station band, track or file.
Disc slot
Display the media top screen.
Display the radio top screen.
Press to turn the audio system on/o ff, and turn to adjust the volume.1
2
3
4
5
6
7
8
Page 277 of 600

2775-1. Basic Operations
5
Lexus Display Audio system
IS350/300/200t_U (OM53D18U)
■“Menu” screen
To display the “Menu” screen, press the button on the controller unit.
ButtonFunction
“Radio”Display the radio top screen ( P. 300)
“Media”Display the media top screen ( P. 306, 312, 315, 319)
“Climate”Automatic air conditioning system ( P. 3 6 8 )
“Phone”Display the phone top screen ( P. 3 3 0 )
“Info”Display the “Information” screen ( P. 3 5 6 )
“Setup”Setup menu ( P. 2 8 6 )
“Display”Display settings ( P. 2 9 1 )
Page 278 of 600

2785-1. Basic Operations
IS350/300/200t_U (OM53D18U)
By using the Lexus Display Audio controller, you can control the audio system,
hands-free system, etc. Display the “Source” screen or
audio top screen ( P. 2 9 2 )
Display the “Menu” screen
( P. 2 7 7 )
Display the previous screen
Turn or move the controller to select
a function and number.
Move the controller to display the
left or right side of screen.
Push the controller to enter the selected function and number.
■Using the Lexus Display Audio controller
Select: Turn or move the control-
ler.
Enter: Push the controller.
■Basic screen operation
When a list is displayed, use the appropriate button to scroll through the list.
Indicator turns on when you can
select the list by turning the con-
troller.
Indicator turns on when you can
return to the previous screen by
pressing the back button.
Indicator turns on when you can
move the controller left to view
additional screen text.
Indicator turns on when you can move the controller right to view addi-
tional screen text.
Lexus Display Audio controller
1
2
3
4
1
2
1
2
3
4
Page 279 of 600

2795-1. Basic Operations
5
Lexus Display Audio system
IS350/300/200t_U (OM53D18U)
■Input mode
Letters and numbers are inputted via the screen.Turn the controller to select the
desired character and press the
controller to input the character.
When this indicator is shown, you
can change input fields by moving
the controller forward.
When this indicator is shown, you
can change character types by
moving the controller to the right
and then selecting the desired
character type.
Select to erase characters one by one. Select and hold to erase all charac-
ters.
Select to complete data input.
■Input field mode
When in the input field you can move the cursor to the desired position.
Turn the controller to move the
cursor left or right.
When this indicator is shown, you
can move the cursor to the right
input field by moving the control-
ler to the right.
When this indicator is shown, you
can move the cursor to the left
input field by moving the control-
ler to the left.
When this indicator is shown, you can change to input mode by moving the
controller backward.
Inputting letters and numbers
1
2
3
4
5
1
2
3
4
Page 280 of 600

2805-1. Basic Operations
IS350/300/200t_U (OM53D18U)
■When using the screen
●Under extremely cold conditions, the Lexus Display Audio controller may react slowly.
●If the screen is cold, the display may be dark, or the system may seem to be operating
slightly slower than normal.
●The screen may seem dark and hard to see when viewed through sunglasses. Change
your angle of viewing, adjust the display on the “Display” screen ( P. 291) or remove
your sunglasses.
■Using cellular phones
Interference may be heard through the audio system's speakers if a cellular phone is
being used inside or close to the vehi cle while the audio system is operating.
CAUTION
■Using the Lexus Display Audio controller
Be careful when touching the Lexus Display Audio controller in extreme temperatures
as it may become very hot or cold due to the temperature inside the vehicle.
■Laser product
●USE OF CONTROL OR ADJUSTMENT OR PERFORMANCE OF PROCE-
DURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARD-
OUS RADIATION EXPOSURE.
●THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL
INCREASE EYE HAZARD.
NOTICE
■To prevent Lexus Display Audio controller malfunction
●Do not allow the Lexus Display Audio controller to come into contact with food, liq-
uid, stickers or lit cigarettes as doing so may cause it to change color, emit a strange
odor or stop functioning.
●Do not subject the Lexus Display Audio controller to excessive pressure or strong
impact as the controller may bend or break off.
■To prevent battery discharge
Do not leave the audio system on longer than necessary when the engine is off.
■To avoid damaging the audio system
Take care not to spill drinks or other fluids on the audio system.
