386
6-1. Specifications
Electrical system
Differential
Battery
Specific gravity reading at
68F (20C):12.6 12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(Voltage checked 20 minutes after the
key is removed with all the lights turned
off)
Charging rates5A max.
Oil capacity
Front0.74 qt. (0.70 L, 0.61 lmp.qt.)
Rear
IS350:
1.42 qt. (1.35 L, 1.19 lmp.qt.)
IS250 (2WD models):
1.20 qt. (1.15 L, 1.01 lmp.qt.)
IS250 (AWD models):
1.10 qt. (1.05 L, 0.92 lmp.qt.)
Oil type and
viscosity
IS250 (AWD)
Hypoid gear oil API GL-5
Above 0F (-18C): SAE90
Below 0F (-18C): SAE80W
or SAE80W-90
Others
Toyota Genuine Differential
Gear Oil LT 75W-85 GL-5,
Toyota Genuine Differential
Synthetic Gear Oil or equivalent

394
6-1. Specifications
Light bulbs
*: If equipped
A: D4S discharge bulbs
B: H11 halogen bulbs
C: Wedge base bulbs (amber)
D: HB3 halogen bulbs
E: Wedge base bulbs (clear)
F: HB4 halogen bulbs
G: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights
High beam
Low/high* beam (discharge bulbs)
Low beam* (halogen bulbs)
9005
D4S
H1165
35
55D
A
B
Front turn signal lights21C
Parking lights1685E
Front fog lights900655F
Tr u n k l i g h t5G
Rear turn signal lights744021E
Back-up lights92116E
Outer foot lights5E
Interior
Vanity lights8E
Interior lights
Front
Rear
10
3.0E
G
Overhead courtesy lights
Front
Rear
3.8
3.0E
G
Door courtesy lights3.8E

395
6-1. Specifications
6
Vehicle specifications
Fuel information
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Lexus has a fuel tank opening that only
accommodates the special nozzle on unleaded fuel pumps.
■If premium gasoline is not available
If 91 rating gasoline cannot be obtained, you may use unleaded gasoline with an
octane rating as low as 87 (Research Octane Rating 91).
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating
or driving uphill. This is normal and there is no need for concern.
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gasoline you
are using. If driveability problems persist, try changing the brand of gasoline. If this
does not correct the problem, consult your Lexus dealer.
Your vehicle must use only unleaded gasoline.
Premium unleaded gasoline with an octane rating of 91 (Research Octane
Number 96) or higher required for optimum engine performance.
At minimum, the gasoline you use should meet the specifications of
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.

409
6-2. Customization
6
Vehicle specifications
ItemFunctionDefault settingCustomized
setting
Po w e r w i n -
dows
(
P. 4 5 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Wireless remote control
linked operationONOFF
Moon roof
(
P. 4 8 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Linked operation of com-
ponents when door key is
used
Slide onlyTilt only
Wireless remote control
linked operationONOFF
Linked operation of com-
ponents when wireless
remote control used
Slide onlyTilt only
Automatic
light control
system
(
P. 122)
Light sensor sensitivityLevel 3Level 1 to 5
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
0 seconds
60 seconds
90 seconds

410
6-2. Customization
ItemFunctionDefault settingCustomized
setting
Windshield
wipers and
washer
(
P. 1 2 6 )
Switching operation when
the vehicle is stationaryONOFF
Drip prevention functionONOFF
Ti m e e l a p s e d b e f o r e t h e
drip prevention function
operatesVa r i a b l e
depending on
the vehicle
speed
3 seconds
Lexus parking
assist-sensor
(
P. 1 4 2 )
Back sensor operation
display and buzzerONOFF
Buzzer volumeLevel 3Level 1 to 5
Distance which a sensor
detects150 cm (4.9 ft.)60 cm (2.0 ft.)
Illumination
(
P. 2 0 9 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedONOFF
Operation after the
engine switch turned OFFONOFF
Front foot well lightingONOFF
Shift lever lightingONOFF
Outer foot lightONOFF

416
Alphabetical index
Alphabetical index
A/C (Air conditioning system) ........ 170
ABS (Anti-lock brake system) ......... 148
AFS (Adaptive front lighting
system) .................................................... 123
Adaptive front lighting system
(AFS)........................................................ 123
Air conditioning filter .......................... 299
Air conditioning system (A/C)
Air conditioning filter ....................... 299
Automatic air conditioning
system .................................................... 170
Airbags
Airbag operating conditions........... 63
Airbag precautions for your
child.......................................................... 67
Airbag warning light ........................340
Curtain shield airbag operating
conditions.............................................. 64
Curtain shield airbag
precautions .......................................... 67
Front passenger occupant
classification system.......................... 72
General airbag precautions ........... 67
Locations of airbags.............................. 61
Modification and disposal of
airbags ...................................................... 71
Proper driving posture ............. 59, 67
Side airbag operating
conditions.............................................. 64
Side airbag precautions .................... 67
SRS airbags ............................................... 61
Alarm ............................................................ 56
Antenna ..................................................... 186
Anti-lock brake system (ABS) ......... 148
Armrest..................................................... 232
Ashtrays .................................................... 225Audio system
Antenna............................................... 186
AUX adapter ...................................... 206
CD player/changer ........................... 189
MP3/WMA disc................................. 195
Optimal use ......................................... 203
Radio ......................................................... 182
Steering wheel audio switch.........207
Automatic air conditioning
system ......................................................170
Automatic headlight leveling
system ...................................................... 124
Automatic light control system......... 122
Automatic transmission
Automatic transmission .....................101
If the shift lever cannot be
shifted from P....................................367
S mode ..................................................... 103
AUX adapter ......................................... 206
BA (Brake assist) ................................... 148
Back-up lights
Wattage ................................................. 394
Battery
Checking................................................279
If the vehicle has discharged
battery .................................................. 372
Preparing and checking
before winter........................................ 161
Bottle holders.......................................... 218
Brake
Fluid ...........................................................278
Parking brake........................................108
Brake assist (BA) ................................... 148A
B

417
Alphabetical index
Care
Exterior ................................................... 252
Interior..................................................... 254
Seat belts ............................................... 255
Cargo capacity ....................................... 157
Cargo hooks .......................................... 238
CD changer .............................................189
CD player..................................................189
Chains.......................................................... 161
Child restraint system (CRS)
Booster seats, definition..................... 77
Booster seats, installation ................... 81
Convertible seats, definition ............ 77
Convertible seats, installation .......... 81
Front passenger occupant
classification system ......................... 72
Infant seats, definition .......................... 77
Infant seats, installation......................... 81
Installing CRS with lower
anchorages .......................................... 84
Installing CRS with seatbelts ............ 81
Installing CRS with top straps ........ 85
Child safety
Airbag precautions ..............................67
Battery precautions................ 281, 374
Child restraint system ......................... 77
Child-protectors................................... 20
How your child should wear
the seatbelt ............................................ 37
Installing child restraints .................... 80
Moon roof precautions ..................... 50
Power window lock switch ............. 45
Power window precautions............. 47
Removed electronic key battery
precautions ....................................... 303
Seat belt comfort guide..................... 35
Seat belt extender precautions ..... 39Seat belt precautions ..........................38
Seat heater precautions........229, 231
Trunk precautions................................. 25
Child-protectors ...................................... 20
Cigarette lighter.................................... 226
Cleaning
Exterior.................................................... 252
Interior ..................................................... 254
Seat belts ................................................255
Clock ...........................................................221
Coat hooks .............................................. 236
Compass .................................................. 246
Condenser .............................................. 278
Console box ............................................ 214
Cooling system
Engine overheating...........................375
Cornering assist sensors .................... 142
Cruise control
Cruise control....................................... 130
Dynamic radar cruise control....... 133
Cup holder ............................................... 216
Curtain shield airbags..............................61
Customizable features .......................406
Daytime running light system ........... 123
Defogger
Rear window ......................................... 178
Side mirror.............................................. 178
Dimension............................................... 380
Dinghy towing ................................166, 167
Display
Dynamic radar cruise control....... 133
Satellite switch mode ....................... 222
Trip information ..................................... 119
Warning message ............................. 344
Do-it-yourself maintenance ............. 263C
D

418
Alphabetical index
Door courtesy lights
Door courtesy lights.........................209
Wattage.................................................. 394
Door pockets........................................... 218
Doors
Door glasses ........................................... 45
Door lock.................................................... 19
Side mirrors ............................................. 43
Driver's seat belt reminder light ...... 341
Driving
Correct posture .................................... 59
Procedures .............................................. 90
Driving position memory ......................28
Electric power steering (EPS) .......... 148
Electronic key
If your electronic key battery
is discharged .................................... 369
Emergency, in case of
If the engine will not start ............... 366
If the shift lever cannot be
shifted from P ................................... 367
If the vehicle has discharged
battery .................................................. 372
If the warning buzzer sounds ...... 339
If the warning light turns on .......... 339
If the warning message is
displayed ............................................ 344
If you have a flat tire .........................358
If you lose your keys.........................368
If you think something is
wrong ................................................... 335
If your electronic key battery
is discharged .................................... 369
If your vehicle becomes stuck......377If your vehicle needs to be
towed ................................................... 328
If your vehicle overheats.................375
Engine
Compartment ..................................... 269
Engine switch ......................................... 98
Hood ....................................................... 266
How to start the engine .................... 98
Identification number ........................ 381
If the engine will not start ............... 366
Overheating .........................................375
Engine compartment cover ............... 271
Engine coolant
Capacity ................................................ 385
Checking................................................276
Preparing and checking
before winter........................................ 161
Engine coolant temperature
gauge ...................................................... 109
Engine immobilizer system ................. 54
Engine oil
Capacity ................................................ 384
Checking................................................ 272
Preparing and checking
before winter........................................ 161
Engine oil maintenance data ........... 275
EPS (Electric power steering) ......... 148
Event data recorder ............................ 337
First-aid kit storage belt ..................... 238
Floor mat .................................................. 237
Fluid
Brake ........................................................278
Washer................................................... 282
E
F

419
Alphabetical index
Fog lights
Switch ........................................................ 125
Wattage ................................................. 394
Foot well lighting .................................. 209
Front fog lights
Switch ........................................................ 125
Wattage ................................................. 394
Front passenger occupant
classification system ............................ 72
Front passenger's seat belt
reminder light ....................................... 341
Front seats
Adjustment ...............................................26
Driving position memory ................. 28
Seat position memory .......................... 31
Front turn signal lights
Wattage ................................................. 394
Fuel
Capacity................................................. 383
Fuel gauge ..............................................109
Fuel pump shut off system ............ 336
Gas station information .................. 427
Information............................................ 395
Refueling ..................................................... 51
Fuel filler door............................................. 51
Fuel pump shut off system ................ 336
Fuses.......................................................... 304
Garage door opener............................ 241
Gas station information ...................... 427
Gauges.......................................................109
Glove box ................................................. 213
Glove box light........................................ 214
Head restraints
Adjusting ..................................................33Headlight aim .......................................... 318
Headlight cleaner .................................. 129
Headlights
Discharge headlights
precautions........................................325
Replacing light bulbs ......................... 319
Switch......................................................... 122
Wattage..................................................394
Heaters
Seat heaters ............................. 228, 230
Side mirror.............................................. 178
Hill-start assist control ......................... 148
Hood .......................................................... 266
Hooks
Cargo ......................................................238
Coat..........................................................236
Shopping bag ......................................238
I/M test...................................................... 262
Identification
Engine....................................................... 381
Vehicle ..................................................... 381
Illuminated entry system ..................... 210
Indicator lights...........................................115
Initialization
Items to initialize .................................... 411
Inside rear view mirror .......................... 42
Interior lights
Interior lights ........................................ 209
Switch.......................................................... 211
Wattage..................................................394
Jack
Positioning the jack ........................... 267
Replacing the wheel ........................ 358
Jack handle............................................. 358
G
H
I
J

420
Alphabetical index
Keys
Electronic key ............................................. 2
Engine switch.......................................... 98
If you lose your keys.........................368
If your electronic key battery
is discharged .................................... 369
Key number ................................................. 2
Keys ................................................................. 2
Mechanical key.......................................... 2
Wireless remote control..................... 16
Light bulbs
Replacing .................................................319
Wattage.................................................. 394
Lights
Door courtesy lights.........................209
Fog light switch..................................... 125
Headlights switch ................................ 122
Interior light switch................................ 211
Outer foot lights ................................. 209
Overhead courtesy light................209
Personal light switch ............................211
Replacing light bulbs..........................319
Scuff lighting .........................................209
Shift lever lighting .............................. 209
Turn signal lever ................................... 107
Vanity lights .......................................... 220
Wattage.................................................. 394
Load capacity .......................................... 160
Maintenance
Do-it-yourself maintenance ......... 263
General maintenance ..................... 259
Maintenance data............................. 380
Maintenance requirements .......... 257
Manual transmission............................. 105Meter
Instrument panel light control .........110
Meters.......................................................109
Mirrors
Inside rear view mirror ....................... 42
Side mirror heater............................... 178
Side mirrors.............................................. 43
Vanity mirrors ..................................... 220
Moon roof................................................... 48
MP3 disc........................................................ 195
Multi-information display........................118
Odometer ................................................ 109
Oil
Engine oil................................................ 272
Opener
Fuel filler door .......................................... 51
Hood ....................................................... 266
Trunk............................................................ 23
Outer foot lights
Outer foot lights................................. 209
Wattage ................................................. 394
Outside rear view mirrors
Adjusting and folding .......................... 43
Driving position memory ..................28
Outside temperature display ............. 119
Overhead console .................................215
Overhead courtesy lights
Overhead courtesy lights ............. 209
Wattage ................................................. 394
Overheating, Engine..............................375
Parking assist sensors........................... 142
Parking brake.......................................... 108K
L
M
O
P
