AUX Lexus IS250 2007 Using the audio system / LEXUS 2007 IS350/250 OWNER'S MANUAL (OM53578U)

1
2
3
4
5
6
7
iii
Multi-information display ............ 118
2-3. Operating the lights and
windshield wipers .................... 122
Headlight switch ............................ 122
Fog light switch .............................. 125
Windshield wipers and
washer............................................. 126
Headlight cleaner switch .......... 129
2-4. Using other driving
systems ...................................... 130
Cruise control ................................ 130
Dynamic radar cruise
control............................................. 133
Lexus parking assist-sensor...... 142
Driving assist systems.................. 148
PCS (Pre-Collision
System)........................................... 154
2-5. Driving information ................... 157
Cargo and luggage ...................... 157
Vehicle load limits ......................... 160
Winter driving tips .......................... 161
Trailer towing .................................. 165
Dinghy towing
(vehicles with an automatic
transmission) ................................ 166
Dinghy towing
(vehicles with a manual
transmission) ................................ 1673-1. Using the air conditioning
system and defogger .............. 170
Automatic air conditioning
system ............................................. 170
Rear window and outside rear
view mirror defoggers ............. 178
3-2. Using the audio system............. 179
Audio system type ........................ 179
Using the radio............................... 182
Using the CD player.................... 189
Playing back MP3 and
WMA discs................................... 195
Optimal use of the audio
system ............................................ 203
Using the AUX adapter............ 206
Using the steering wheel
audio switches ............................ 207
3-3. Using the interior lights .......... 209
Interior lights list............................ 209
• Interior lights and
personal lights ............................... 211
3-4. Using the storage features..... 213
List of storage features ............... 213
• Glove box ..................................... 213
• Console boxes ............................ 214
• Overhead console .................... 215
• Cup holders.................................. 216
3Interior features

viii
A
Power window
switches
P. 45
Pictorial indexInterior
Seat belts P. 34
Front passenger
airbag
P. 61
Knee airbags P. 61
Driver airbag P. 61
Floor mat P. 237
Bottle holders/door pockets P. 218
Head restraints P. 33
Front seats P. 26
Cup holders P. 216
SRS side airbags P. 61
Console box P. 214
Power outlet P. 227
Ashtrays P. 225
Cup holders P. 216
Armrest
Console box

P. 232
P. 214
AUX adapter P. 206

Interior features3
169
3-1. Using the air conditioning
system and defogger ........... 170
Automatic air conditioning
system .......................................... 170
Rear window and outside rear
view mirror defoggers........... 178
3-2. Using the audio system ......... 179
Audio system type ..................... 179
Using the radio ............................ 182
Using the CD player ................. 189
Playing back MP3 and
WMA discs................................ 195
Optimal use of the audio
system ......................................... 203
Using the AUX adapter ......... 206
Using the steering wheel
audio switches ......................... 207
3-3. Using the interior lights ....... 209
Interior lights list........................ 209
• Interior lights and
personal lights............................. 211
3-4. Using the storage
features ................................... 213
List of storage features............. 213
• Glove box .................................. 213• Console boxes .......................... 214
• Overhead console ................. 215
• Cup holders ............................... 216
• Bottle holders/door
pockets ........................................ 218
3-5. Other interior features......... 219
Sun visors ...................................... 219
Vanity mirror ............................... 220
Clock................................................ 221
Satellite switches ....................... 222
Ashtrays ........................................ 225
Cigarette lighter........................ 226
Power outlet ................................ 227
Seat heaters ................................ 228
Seat heaters and
ventilators .................................. 230
Armrest ......................................... 232
Rear sunshade............................ 233
Extended trunk .......................... 235
Coat hooks .................................. 236
Floor mat ...................................... 237
Trunk features ............................. 238
Garage door opener................. 241
Compass ...................................... 246

206
3-2. Using the audio system
Using the AUX adapter
■Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle's audio controls. All other adjust-
ments must be made on the portable audio device itself.
■When using a portable audio device connected to the power outlet
Noise may occur during playback. Use the power source of the portable audio
device.
This adapter can be used to connect a portable audio device and listen to it
through the vehicle’s speakers.
Connect the portable audio
device.
Press .STEP1
STEP2

207
3-2. Using the audio system
3
Interior features
Using the steering wheel audio switches
Turning on the power
Press when the audio system is turned OFF.
The audio system can be turned off by holding the switch down for 1 second
or more.
Changing the audio source
Press when the audio system is turned ON. The audio source
changes as follows each time the switch is pressed.
FM1FM2CD changerAUXAMSAT1SAT2SAT3
Adjusting the volume
Press + on to increase the volume and - to decrease the volume.
Hold down the switch to continue increasing or decreasing the volume.
Some audio features can be controlled using the switches on the steering
wheel.
Power on, select audio
source
Vo l u m e
Radio: Select radio stations
CD: Select tracks, files (MP3
and WMA) and discs

416
Alphabetical index
Alphabetical index
A/C (Air conditioning system) ........ 170
ABS (Anti-lock brake system) ......... 148
AFS (Adaptive front lighting
system) .................................................... 123
Adaptive front lighting system
(AFS)........................................................ 123
Air conditioning filter .......................... 299
Air conditioning system (A/C)
Air conditioning filter ....................... 299
Automatic air conditioning
system .................................................... 170
Airbags
Airbag operating conditions........... 63
Airbag precautions for your
child.......................................................... 67
Airbag warning light ........................340
Curtain shield airbag operating
conditions.............................................. 64
Curtain shield airbag
precautions .......................................... 67
Front passenger occupant
classification system.......................... 72
General airbag precautions ........... 67
Locations of airbags.............................. 61
Modification and disposal of
airbags ...................................................... 71
Proper driving posture ............. 59, 67
Side airbag operating
conditions.............................................. 64
Side airbag precautions .................... 67
SRS airbags ............................................... 61
Alarm ............................................................ 56
Antenna ..................................................... 186
Anti-lock brake system (ABS) ......... 148
Armrest..................................................... 232
Ashtrays .................................................... 225Audio system
Antenna............................................... 186
AUX adapter ...................................... 206
CD player/changer ........................... 189
MP3/WMA disc................................. 195
Optimal use ......................................... 203
Radio ......................................................... 182
Steering wheel audio switch.........207
Automatic air conditioning
system ......................................................170
Automatic headlight leveling
system ...................................................... 124
Automatic light control system......... 122
Automatic transmission
Automatic transmission .....................101
If the shift lever cannot be
shifted from P....................................367
S mode ..................................................... 103
AUX adapter ......................................... 206
BA (Brake assist) ................................... 148
Back-up lights
Wattage ................................................. 394
Battery
Checking................................................279
If the vehicle has discharged
battery .................................................. 372
Preparing and checking
before winter........................................ 161
Bottle holders.......................................... 218
Brake
Fluid ...........................................................278
Parking brake........................................108
Brake assist (BA) ................................... 148A
B

427
GAS STATION INFORMATION
Auxiliary catch lever
P. 2 6 6Trunk opener
P. 2 3Fuel filler door
P. 5 1
Hood lock release lever
P. 2 6 6Fuel filler door opener
P. 5 1Tire inflation pressure
P. 3 8 9
Fuel tank capacity17.2 gal. (65L, 14.3 lmp.gal.)
Fuel typeUnleaded gasoline only P. 52, 383
Cold tire inflation
pressureP. 3 8 9
Engine oil capacity
(Drain and refill)
qt. (L, Imp.qt.)
IS250 IS250
(2WD models) (AWD models) IS350
With filler 6.6 (6.3, 5.5) 6.8 (6.4, 5.7) 6.6 (6.3, 5.5)
Without filler 6.2 (5.9
, 5.2)6.3 (6.0, 5.3) 6.2 (5.9, 5.2)
Engine oil type
Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 384
Recommended oil viscosity: SAE-5W-30
