COMFORT ADJUSTMENT
90
CAUTION
Do not modify, remove, strike or open the front seat belt
pretensioner assemblies, airbag sensor or surrounding
area or wiring. Doing any of these may cause sudden
operation of the front seat belt pretensioners or disable
the system, which could result in death or serious
injury.
Failure to follow these instruction can result in death or
serious injury.
NOTICE
Do not perform any of the following changes without consulting your Lexus dealer. Such changes caninterfere with proper operation of the front seat beltpretensioners in some cases.
Installation of electronic devices such as a mobiletwo±way radio, cassette tape player or compact disc
player.
Repairs on or near the front seat belt retractor assemblies.
Modification of the suspension system.
Modification of the front end structure.
Attachment of a grille guard (bull bar, kangaroo bar,etc.), snowplow, winches or any other equipment tothe front end.
Repairs made on or near the front fenders, front endstructure or console.
Page 115 of 307
COMFORT ADJUSTMENT
102
NOTICE
Do not perform any of the following changes withoutconsulting your Lexus dealer. Such changes caninterfere with proper operation of the SRS airbagsystem in some cases.
Installation of electronic devices such as a mobiletwo±way radio, cassette tape player or compact disc
player.
Modification of the suspension system.
Modification of the front end structure and side structure of the passenger compartment.
Attachment of a grille guard (bull bar, kangaroo bar,etc.), snowplow, winches or any other equipment tothe front end.
Repairs made on or near the front fenders, front endstructure, console, steering column, steering wheel,dashboard near the front passenger airbag or frontseats.
SV16061
This SRS front airbag system has an indicator to inform the
driver of operating problems. If either of the following
conditions occurs, this indicates a malfunction of the airbags.
Contact your Lexus dealer as soon as possible to service the
vehicle.
When the ignition key is turned to the ºACCº or ºONº
position, the light does not come on, stays on or flashes.
The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side airbags fail.
Page 153 of 307
AUDIO
140
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.
Your audio system works when the ignition key is in the ºACCº
or ºONº position.
NOTICE
To prevent the battery from being discharged, do not leave the car audio on longer than necessary when theengine is not running.
(a) Turning the system on and off
SV22002
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
SV22003
Push ºAMº, ºFMº, ºT APEº or ºDISCº to turn on that mode.
The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or disc is not set, the cassette player or compact disc
player does not turn on.
You can turn off the cassette player by ejecting the cassette
tape. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape. If another function was previously playing, it will come on
again.
Page 155 of 307
AUDIO
142(c) Your radio antenna
To remove an antenna, carefully turn it counterclockwise.
NOTICE
To prevent damage to the antenna, make sure it is
removed before driving your vehicle through anautomatic car wash.
(d) Your cassette player
When you insert a cassette, the exposed tape should be to the
right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into the slot.
(e) Your automatic changer
SV22006
Your automatic changer can be store up to 6 discs and play
selected discs or continuously play all the discs set in the
player.
When you set discs into the player, make sure their labels face
up. If not, the player will display ºERR 1º and the disc number.
NOTICE
Never try to disassemble or oil any part of the compact disc player. Do not insert anything except acompact disc into the slot.
Do not insert a disc upon another one.
The player is intended for use with 12 cm (4.7 in.) discs only.
Page 163 of 307
AUDIO
150If no messages have been stored, or if there are no more
messages to be recalled, ºNO MSG STOREDº will appear on
the display, and the message display will be canceled. The
display then returns to show the program service name. The
message display will be canceled if you activate any function
that affects the display.
Message display can be canceled by pressing any of the
following buttons:
ºAMº, ºFMº, ºCDº, ºTAPEº, ºLOADº, ºSEEKº, ºTUNEº, any
preset, º
SCANº, any audio control, ºRDSº, or º
current station is not a traffic program and traffic
announcements is off, pushing ºTRAFº will cancel the display.
The message will be canceled after the entire message has
been displayed.
(g) ºALERTº display
The alert program type sends emergency alert messages. The
radio will receive alert messages if it is on and tuned to an RDS
station, or if the previous station was an RDS station. If the
radio receives an alert announcement, it will interrupt the
previous mode, display ºALERTº .
Cassette tape player operation
(a) Playing a cassette tape
SV22027
When you insert a cassette tape, the exposed tape should
face to the right.
The player will automatically start when you insert a cassette
tape. At this time, ºPLAYº appears on the display.
If a metal or chrome equivalent cassette tape is put in the
cassette player, the player will automatically adapt to it and
ºMTLº appears on the display.
To stop or eject the cassette tape, push the ºEJECTº button.
Auto±reverse feature: After the cassette player reaches the
end of a tape, it automatically reverses and begins to play the
other side, regardless of whether the cassette was playing or
fast forwarding.
Page 165 of 307
AUDIO
152(c) Automatic program selection
SV22017
ºRPTº button: The repeat feature automatically replays the
current program.
Push the º
RPTº button while the program is playing. When the
program ends, it will automatically be rewound and replayed.
Push the button again to turn off the repeat feature.
There must be at least 5 seconds of blank space between
programs for the repeat feature to work correctly.
ºSKIPº button: The skip feature allows you to fast forward
past long stretches of blank tape. This is especially useful at
the end of cassettes.
Push the ºSKIPº button. The player will automatically skip any
blank portions of 15 seconds or more and play the next
program. To cancel it, push the button once again.
SV22018
ºAutomatic program selectionº button: The automatic
program selection feature allows you to program your cassette
player to skip forward or backward to locate the song you want
to hear. You can skip up to nine programs at a time.
Push this button on the upper side to skip forward. ºFFº and
the number will appear on the display. Push the button until the
number you want to skip appears on the display. After that, the
player will automatically skip forward.
When the end of the tape is reached, the player automatically
reverses sides and resumes normal play.
Page 166 of 307
AUDIO
153
Push
this button on the lower side to skip backward. Push the
button until ºREWº and the number you want to skip appear on
the display.
If you set ºREW 1º, the player will rewind to the beginning
of the current program.
When counting the number of programs you want to rewind,
remember to count the current program as well. For
example, if you want to rewind to a song that is two before
the song you are listening to, push this button until ºREW
3º appears on the display.
When the beginning of the tape is reached, the player
automatically resumes normal play.
There must be at least 5 seconds of blank space between
programs for this feature to work correctly.
ºRPTº, ºSKIPº or ºAutomatic program selectionº
features: These features may not work well with some spoken
word, live or classical recordings.
Compact disc player operation
This compact disc player can store 6 discs in the player.
The discs can be inserted or ejected while the ignition
switch is at ºACCº or ºONº.
(a) How to insert and eject the compact discs
SV22032
1. Push the ºLOADº button. Push the button briefly for
one disc, and when inserting more than one disc, push
and hold the button until a beep sounds.
2. Insert the disc into the compact disc slot. A maximum
of 6 discs can be inserted into the player.
If the indicator blinking in amber at the next to the compact disc
slot turns into the green light, you can insert the disc into the
slot. The ºLOAD DISC 4º is displayed at that time. (If you push
LOAD, the indicator blinks in amber. ºWAIT DISC 4º is
displayed while the system is being under preparation for
inserting disc.
Page 167 of 307
AUDIO
154When the display shows ºDISC INº with all the indicators (1±6)
on, the player already has 6 discs inside, so you can not insert
any more.
If you do not insert the discs within 15 seconds after pushing
the ºLOADº button and ºLOADº is displayed, the operation will
be canceled automatically.
SV22020
3. When ejecting one disc, select the disc you want to
eject by the function button ºDISC º or ºDISC º, and
push the ºEJECTº button briefly. When ejecting more
than one disc, push and hold the ºEJECTº button until a
beep sounds and take out the disc ejected from the slot. (b) Playing a compact disc
SV22033
Push the ºDISCº button if the discs are already loaded in
the player.
The discs set in the player are played continuously, starting
with disc number 1. The disc number of the disc currently
being played, the track number and the time from the
beginning of the program appear on the display.
When
play of one disc ends, the first track of the following disc
starts. When play of the final disc ends, play of the first disc
starts again.
The player will skip any empty disc trays.
Page 168 of 307
AUDIO
155
(c) Selecting a desired disc
SV22034
Push the ºDISC º or ºDISC º button to select the disc
number.
Push the button several times until the desired disc number
appears on the display. When you release the button, the
player will start playing the selected disc from the first track. (d) Searching for a desired track
SV22023
Push the ºSCANº button briefly.
ºSCANº will appear on the display. The compact disc player
will play the next track for 10 seconds, then scan again. To
select a track, push the ºSCANº button a second time. If the
player reaches the end of the disc, it will continue scanning at
track 1.
After all the tracks are scanned in one pass, normal play
resumes.
Page 169 of 307
AUDIO
156(e) Searching for a desired disc
SV22024
Push the ºSCANº button until you hear a beep.
With ºD
SCANº on the display, the program at the beginning
of each disc will be played for 10 seconds. To continue
listening to the program of your choice, push the ºSCANº
button a second time.
After all the discs in the player are scanned in one pass, the
scan function is cancelled. (f) Selecting a desired track
SV22035
ºTRACKº button: Use for direct access to a desired track.
Push either side of the ºTRACKº button several times until the
desired track number appears on the display. As you release
the button, the player will start playing the selected track from
the beginning.
ºFast forwardº button.
Push the º
º button and hold it to fast forward the disc.
When you release the button, the compact disc player will
resume playing from that position.
ºReverseº button.
Push the º º button and hold it to reverse the disc. When
you release the button, the compact disc player will resume
playing.
