48Emissions Inspection and Maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On±Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see ºEmissions Inspection and Maintenance (I/M)
programsº on page 293.
(i) ºABSº Warning Light
The light comes on when the ignition key is turned to the ºONº
position. If the anti±lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ºABSº warning light is on (and the brake system
warning light is off), the anti±lock brake system, the brake
assist system, the traction control system and/or the vehicle
skid control system do not operate, but the brake system still
operates conventionally.
When the ºABSº warning light is on (and the brake system
warning light is off), the anti±lock brake system and/or the
traction
control system do/does not operate so that the wheels
could lock up during a sudden braking or braking on slippery
road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as soon
as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ºONº position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ºABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti±lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
(j) Open Door Warning Light and Buzzer
This light and buzzer remain on until all the doors are
completely closed.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
(k) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at
the first or second clickstop), it indicates that one or more of the
tail lights are burned out.
If it comes on when the brake pedal is depressed, one or more
stop lights are burned out.
Have defective bulbs replaced as soon as possible.
(l) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
nearly empty. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(m) ºTRAC OFFº Indicator / Warning Lights
This light comes on when the ignition switch is turned to ºONº,
and will go off after a few seconds. This means that the system
is operating properly.
If the light flashes, this indicates a malfunction in the traction
control system. Contact your Lexus dealer as soon as
possible to service the vehicle.
(n)Vehicle Skid Control System Warning Light
(With vehicle skid control system)
This light warns that there is a problem somewhere in the
vehicle skid control system or traction control system.
The light will come on when the ignition key is turned to ºONº,
and will go off after a few seconds.If the ºVSCº warning light comes on, the vehicle skid control
system and traction control system do not work. However, as
conventional braking operates when applied, there is no
problem to continue your driving.
If any of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle:

The ºVSCº warning light does not come on after the ignition
is turned to on.
 The ºVSCº warning light remains on after the ignition is
turned to on.
 The ºVSCº warning light comes on while driving without
pushing ºTRAC OFFº switch.
(o) Automatic Headlight Leveling System
Warning Light
This light warns that when there is a problem somewhere in the
automatic headlight leveling system.
If it comes on, have your vehicle checked by your Lexus dealer.
(p) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver's door with the ignition key in the ºACCº or ºLOCKº
position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Turn the ignition key to ºACCº.
The following service reminder indicator should come on. It
goes off after 6 seconds.
4. Turn the ignition key to ºONº.
The following service reminder indicators should come on.


or
or

or
The following service reminder indicators go off after a few
seconds.
or

The lights other than the slip indicator light may stay on for
about 60 seconds after the engine is started. It is normal if they
go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
INSTRUMENT PANEL LIGHTCONTROL
SV13019
To adjust the brightness of the instrument panel lights,
turn the knob.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52

SECTION 1 ± 4
53
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Interior lights 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Personal lights 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Ignition switch light 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Luggage compartment light 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
Outside temperature display 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Glove box 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Garage door opener 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Cup holders 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Auxiliary boxes 67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Warning reflector holder 68
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie±down hooks 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Luggage cover 70
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
In order to expand the luggage space 72
. . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
First±aid kit holder 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Luggage stowage precautions 77
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTERIOR EQUIPMENT
54
VANITY MIRRORS
SV14008
To use the vanity mirrors, swing the sun visor down and
open the cover.
The vanity light comes on when you open the cover.
Sun visors
SS14002
1To block out glare from the front , swing the sun visor
down.
2To block out glare from the side, remove the sun visor
from the hook and swing it to the side.

INTERIOR EQUIPMENT
55
INTERIOR LIGHTS
SS14003
To turn on the interior light, slide the switch.
With the switch in the ºDOORº position, the light comes on
when any of the doors are opened. After all the doors are
closed, the light remains on for about 15 seconds and then
goes out.
However, in the following cases, the light goes out
immediately:
1. All the doors are closed when the ignition key is in ºACCº
or ºONº position.
2. The ignition key is turned to ºACCº or ºONº when the light
is still on.
3. All the doors are locked when the light is still on.
4. One door is closed with the lock button pushed in while the
other doors are locked.
PERSONAL LIGHTS
SS14005

With moon roof
SS14006

Without moon roof
To turn on the personal light, push the switch. To turn it
off, push the switch again.

INTERIOR EQUIPMENT
56
IGNITION SWITCH LIGHT
SS14007
For easy access to the ignition switch, the ignition switch
light comes on when any of the doors are opened.
The light remains on for about 15 seconds and goes out after
all the doors are closed. However, the light goes out
immediately when all the doors are locked or the ignition key
is in the ºACCº or ºONº position.
LUGGAGE COMPARTMENT LIGHT
SV14009
To turn on the luggage compartment light, open the back
door or push the switch. Closing the back door will turn
the light off.

INTERIOR EQUIPMENT
57
CLOCK
SV14032
The digital clock indicates the time with the ignition key at
the ºACCº or ºONº position. To reset the hour, press the
ºHº button. To reset the minutes, press the ºMº button.
To adjust the time to the nearest hour, press the º:00º
button.
For example, if the º:00º button is pressed when the time is
between 9:30 ± 9:59 or between 10:01 ± 10:29, the time will
change to 10:00.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00 (one
o'clock).
When the headlight switch is in the first or second click stop,
you can also adjust the brightness of the display using the
instrument panel light control dial.
OUTSIDE TEMPERATURE DISPLAY
SV14030

Vehicles sold in U.S.A.
SV14031

Vehicles sold in Canada
This display shows the outside temperature when the
ignition switch is on.
