INTERIOR EQUIPMENT
58
SS14018

Rear
To use the cup holder, push the cup holder portion of the
center console box.
The cup holder is designed for holding cups or drink±cans
securely in its holes.
CAUTION
Do not place anything else other than cups or
drink±cans in the cup holder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
 Rear only: To reduce the chance of injury in case of
an accident or sudden stop while driving, keep the
cup holder closed when not in use.
WARNING REFLECTOR HOLDER
SS14092

1To loosen 2To tighten
This belt is designed to hold the warning reflector.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Although the warning reflector itself is not included as an
original equipment, this belt can be used to store the warning
reflector.
Make sure the warning reflector is securely held.

INTERIOR EQUIPMENT
59
TIE±DOWN HOOKS
SV14003
To secure your luggage, use the tie±down hooks as
shown above.
See ºLuggage stowage precautionsº on page 61 for
precautions to observe for loading luggage.
CAUTION
To avoid personal injury, keep the tie±down hooks
stored under the carpet when not in use.
FLOOR MAT
SS14019
Use a floor mat of the correct size.
If the floor carpet and floor mat have a hole, then it is designed
for use with a locking clip. Fix the floor mat with locking clip into
the hole in the floor carpet.

INTERIOR EQUIPMENT
60
SS14021a
CAUTION
Make sure the floor mat is properly placed on the floor
carpet. If the floor mat slips and interferes with the
movement of the pedals during driving, it may cause an
accident.
FIRST±AID KIT HOLDER
SS14022a

1To loosen 2To tighten
This belt is designed to hold the first±aid kit.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Make sure the first±aid kit is securely held.

INTERIOR EQUIPMENT
61
LUGGAGE STOWAGEPRECAUTIONS
When stowing luggage or cargo in the vehicle, observe
the following:
Put luggage or cargo in the trunk when at all possible. Be
sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the weight as
far forward as possible helps maintain vehicle balance.
 For better fuel economy, do not carry unnecessary weight.
CAUTION
Do not place anything on the package tray behind the
rear seatback. Such items may be thrown about and
possibly injure people in the vehicle during sudden
braking or in an accident.
 Do not drive with objects left on top of the instrument
panel. They may interfere with the driver's field of
view. Or they may move during sharp vehicle
acceleration or turning, and impair the driver's
control of the vehicle. In an accident they may injure
the vehicle occupants.
NOTICE
Do not load the vehicle beyond the vehicle capacity
weight specified on the tire pressure label.

INTERIOR EQUIPMENT
62

SECTION 1 ± 5
63
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Trunk lid 65
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Fuel tank cap 67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Moon roof 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .

EXTERIOR EQUIPMENT
64
HOOD
SS15001
1. To open the hood, pull the hood lock release lever
under the instrument panel. The hood will spring up
slightly.
SV15005
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
SV15002
3. Hold the hood open by inserting the support rod into
the slot.
CAUTION
After inserting the support rod into the slot, make sure
the rod supports the hood securely from falling down on
to your head or body.
NOTICE
Be sure to return the support rod to its clip beforeclosing the hood. Closing the hood with the support rod
up could cause the hood to bend.

EXTERIOR EQUIPMENT
65
SS15021
In case of unlocking the support rod, lift up the hood a
little, move the support rod and unlock it as shown by the
arrow marks in the illustration.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. and return the support rod to its
clips±this prevents rattles. Then lower the hood and make
sure it locks into place. If necessary, press down gently on the
front edge to lock it.
CAUTION
Before driving, be sure that the hood is securely locked.
Otherwise, the hood may open unexpectedly while
driving and an accident may occur.
TRUNK LID
SS15005c
To unlock the trunk lid, insert the master key and turn it
clockwise.
To close the trunk lid, lower it and press down on it. After
closing the trunk lid, try pulling it up to make sure it is securely
closed.
The trunk lid can be unlocked using the wireless remote control
key. For details, see page 13.
If the theft deterrent system is set, unlock the trunk lid with the
wireless remote control. (For details, see page 120.)

EXTERIOR EQUIPMENT
66
CAUTION
Keep the trunk lid closed while driving. This not only
keeps the luggage from being thrown out, but also
prevents exhaust gases from entering the vehicle.
 Always lock the trunk lid and all doors, and keep
away the vehicle keys out of children's reaches.
 Never leave children unattended in the vehicle.
Unsupervised children may lock themselves in the
vehicle or trunk and suffer serious injuries or death.
Lock release lever
SS15006
To open the trunk lid from the driver's seat, pull up on the
lock release lever.
Internal trunk release handle
SV15008
If a person is locked in the trunk, he or she can pull down
the phosphorescent handle on the inside of trunk lid in
case of emergency to open the trunk lid.
The phosphorescent (glow±in±the±dark) handle will continue
to glow for a time after the trunk lid is closed. Exposing the
handle to stronger light will cause it to glow longer.

EXTERIOR EQUIPMENT
67
Luggage security system
SS15013
After closing the trunk lid, insert the master key and turn
it counterclockwise to deactivate the lock release lever.
At this time, the trunk lid can be opened only by the
phosphorescent handle lever inside the trunk.
FUEL TANK CAP
SS15008
1. To open the fuel filler door, pull the lever up.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refueling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.
