5718-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D76U)
WARNING
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicles, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution.
■When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an acci-
dent resulting in deat h or serious injury.
NOTICE
■To avoid damaging the transmission and other components
●Avoid spinning the rear wheels and depressing the accelerator pedal more than nec-
essary.
●If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed.

5728-2. Steps to take in an emergency
IS350/300/200t_U (OM53D76U)

573
Vehicle specifications9
IS350/300/200t_U (OM53D76U)
9-1. SpecificationsMaintenance data (fuel, oil level, etc.) .................. 574
Fuel information.......................... 587
Tire information ..........................590
9-2. Customization Customizable features ............602
9-3. Initialization Items to initialize ............................ 611

574
IS350/300/200t_U (OM53D76U)9-1. Specifications
*1:Unladen vehicle
*2:Vehicles with 255/35R18 tires
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length184.3 in. (4680 mm)
Overall width71.3 in. (1810 mm)
Overall height*156.3 in. (1430 mm)
Wheelbase110.2 in. (2800 mm)
Tread*1
Front60.4 in. (1535 mm)
Rear61.0 in. (1550 mm)
60.6 in. (1540 mm)
*2
Vehicle capacity weight (Occupants + lug-
gage)825 lb. (375 kg)

5759-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D76U)
■Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for your vehicle.
This is the primary identification number fo r your Lexus. It is used in register-
ing the ownership of your vehicle.
This number is stamped on the top
left of the instrument panel and in the
engine compartment.
This number is also on the Certifica-
tion Label.
Vehicle identification
IS350/IS300IS200t

5769-1. Specifications
IS350/300/200t_U (OM53D76U)
■Engine number
The engine number is stamped on the engine block as shown.
IS350/IS300IS200t
Engine
IS350/IS300IS200t
Model3.5 L 6-cylinder (2GR-FSE)
engine2.0 L 4-cylinder (8AR-FTS)
engine
Type 6-cylinder V type,
4-cycle, gasoline 4-cylinder in line,
4-cycle, gasoline
(with turbocharger)
Bore and stroke
3.70 ×
3.27 in.
(94.0 × 83.0 mm) 3.39
× 3.39 in.
(86.0 × 86.0 mm)
Displacement 210.9 cu. in. (3456 cm3) 121.9 cu. in. (1998 cm3)
Valve clearance
(engine cold)Automatic adjustment
Drive belt tensionAutomatic adjustment
Fuel
Fuel typeUnleaded gasoline only
Octane Rating91 (Research Octane Number 96) or higher
Fuel tank capacity
(Reference)17.5 gal. (66.3 L, 14.6 Imp. gal.)

5779-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D76U)
■Oil capacity (Drain and refill [Reference*])
*: The engine oil capacity is a reference quantity to be used when changing the engineoil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.
Lubrication system
IS350 (2WD)IS350/IS300 (AWD)IS200t
With filter6.6 qt.
(6.2 L, 5.5 Imp. qt.)6.8 qt.
(6.4 L, 5.6 Imp. qt.)4.9 qt.
(4.6 L, 4.0 Imp. qt.)
Without filter6.2 qt.
(5.9 L, 5.2 Imp. qt.)6.3 qt.
(6.0 L, 5.3 Imp. qt.)4.5 qt.
(4.3 L, 3.8 Imp. qt.)

5789-1. Specifications
IS350/300/200t_U (OM53D76U)
■Engine oil selection (IS350/IS300)
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value be fore the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme lo ad conditions.
How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.
Outside temperature

5799-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D76U)
■Engine oil selection (IS200t)
“Toyota Genuine Motor Oil SAE 0W-20 for Direct Injection Turbo Gasoline
Engines” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine
Motor Oil SAE 0W-20 for Direct Injection Turbo Gasoline Engines” or
equivalent to satisfy the fo llowing grade and viscosity.
Oil grade: “Toyota Genuine Motor Oil SAE 0W-20 for Direct Injection Turbo
Gasoline Engines” or ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Outside temperature

5809-1. Specifications
IS350/300/200t_U (OM53D76U)
Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value be fore the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme lo ad conditions.
How to read oil container label:
The International Lubricant Specifi cation Advisory Committee (ILSAC) Cer-
tification Mark is added to some oil containers to help you select the oil you
should use.
