Page 126 of 648
1263-2. Opening, closing and locking the doors and trunk
IS350/300/200t_U (OM53D76U)
■When the vehicle is not driven for extended periods
●To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the
vehicle.
●The smart access system wi th push-button start can be deactivated in advance.
( → P. 602)
■To operate the system properly
●Make sure to carry the electr onic key when operating the system. Do not get the elec-
tronic key too close to the vehicle when operating the system from the outside of the
vehicle.
Depending on the position and holding condit ion of the electronic key, the key may not
be detected correctly and the system may no t operate properly. (The alarm may go off
accidentally, or the door lock prev ention function may not operate.)
●Do not leave the electronic key inside the luggage compartment.
The key confinement prevention function ma y not operate, depending on the location
of the key (close to a spare tire, the inside edge of the luggage compartment), condi-
tions (inside a metal bag, close to metallic objects) and the radio waves in the surround-
ing area. ( →P. 119)
■If the smart access system with push-button start does not operate properly
●Locking and unlocking the doors and opening the trunk: Use the mechanical key.
(→ P. 559)
●Starting the engine: →P. 560
■Customization
Settings (e. g. smart access system with push-button start) can be changed.
(Customizable features: →P. 602)
■If the smart access system with push-button start has been deactivated in a customized
setting
●Locking and unlocking the d oors and opening the trunk:
Use the wireless remote cont rol or mechanical key. (→P. 111, 117, 559)
●Starting the engine and changing engine switch modes: →P. 560
●Stopping the engine: →P. 172
Page 476 of 648
4767-3. Do-it-yourself maintenance
IS350/300/200t_U (OM53D76U)
Check if the treadwear indicators are showing on the tires. Also check the tires
for uneven wear, such as excessive wear on one side of the tread.
Check the spare tire condition and pressure if not rotated. New tread
Worn tread
Treadwear indicator
The location of treadwear indicato rs is shown by a “TWI” or “Δ” mark, etc., molded
into the sidewall of each tire.
Replace the tires if the treadwear indicators are showing on a tire.
Tires
Replace or rotate tires in accordance with maintenance schedules and tread-
wear.
Checking tires
1
2
3
Page 520 of 648
5208-2. Steps to take in an emergency
IS350/300/200t_U (OM53D76U)
■Electric power steering system warning light (warning buzzer)
When the battery charge becomes insufficien t or the voltage temporarily drops, the
electric power steering system warning li ght may come on and the warning buzzer may
sound.
■When the tire pressure warning light comes on
Check the tire inflation pressu re and adjust to the appropriate level. Pushing the tire
pressure warning reset switch will not tu rn off the tire pressure warning light.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such as natural air
leaks and tire inflation pressure changes caus ed by temperature. In this case, adjusting
the tire inflation pressure will turn off the warning light (after a few minutes).
■When a tire is replaced with the spare tire
The compact spare tire is not equipped with a tire pressure warning valve and transmit-
ter. If a tire goes flat, the tire pressure warning light will not turn off even though the flat
tire has been replaced with the spare tire.
■Conditions that the tire pressure wa rning system may not function properly
→ P. 481
■If the tire pressure warning light freque ntly comes on after blinking for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1 minute when the
engine switch is turned to IGNITION ON mo de, have it checked by your Lexus dealer.
■Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.
WARNING
■If both the ABS and the brake sy stem warning lights remain on
Stop your vehicle in a safe place immediat ely and contact your Lexus dealer. The vehi-
cle will become extremely unstable during br aking, and the ABS system may fail, which
could cause an accident resultin g in death or serious injury.
■When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
When steering wheel operations are heavier than usual, grip the steering wheel firmly
and operate it using more force than usual.
■If the tire pressure warning light comes on
Be sure to observe the following precaution s. Failure to do so could cause a loss of
vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pressure
immediately.
●If the tire pressure warning light comes on even after tire inflation pressure adjust-
ment, it is probable that you have a flat tire . Check the tires. If a tire is flat, change it
with the spare tire and have the flat tire repaired by the nearest Lexus dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose
control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.
Page 547 of 648
5478-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D76U)
Location of the spare tire, jack and tools
Jack handle
Screwdriver
Wheel nut wrenchTowing eyelet
Spare tire
Jack1
2
3
4
5
6
Page 555 of 648
5558-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D76U)
WARNING
■When using the compact spare tire
●Remember that the compact spare tire provided is specifically designed for use with
your vehicle. Do not use your comp act spare tire on another vehicle.
●Do not use more than one compact spare tires simultaneously.
●Replace the compact spare tire with a standard tire as soon as possible.
●Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking.
■When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:
Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:
•AWD system
■Speed limit when using the compact spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is
installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure to observe
this precaution may lead to an accident causing death or serious injury.
■After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their storage
location to reduce the possibilit y of personal injury during a collision or sudden brak-
ing.
• ABS & Brake assist
•VSC
•TRAC
• Dynamic radar cruise control
•PCS
•EPS
• AFS (if equipped) • Adaptive Variable Suspension System
(if equipped)
• LDA (Lane Departure Alert with
steering control)
• Lexus parking assist monitor (if equipped)
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)
Page 591 of 648
5919-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D76U)
Tire size (→ P. 593)
TUBELESS or TUBE TYPE
A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire
has a tube inside the tire and the tube maintains the air pressure.
Radial tires or bias-ply tires
A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply
tire.
Summer tires or all season tires (→ P. 480)
An all season tire has “M+S” on the side wall. A tire not marked “M+S” is a summer
tire.
Maximum cold tire inflation pressure (→ P. 597)
This means the pressure to which a tire may be inflated.
Load limit at maximum cold tire inflation pressure (→ P. 597)
Tire ply composition and materials
Plies are layers of rubber-c oated parallel cords. Cords are the strands which form the
plies in a tire.
Uniform tire quality grading
For details, see “Uniform Tire Quality Grading” that follows.
DOT and Tire Identification Number (TIN) (→ P. 592)
Location of trea dwear indicators (→ P. 476)
“TEMPORARY USE ONLY”
A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded
on its sidewall. This tire is designed for temporary emergency use only.
1
2
3
4
5
6
7
8
9
10
11
Page 643 of 648
643Alphabetical index
IS350/300/200t_U (OM53D76U)
Shift lock system..................................... 182
Shift position and gear position ..........79
Side airbags ............................................... 36
Side marker lights.................................. 188Light switch ............................................188
Replacing light bulbs ....................... 502
Side mirrors ..............................................146 Adjusting and folding........................ 146
BSM (Blind Spot Monitor)............248
Linked mirror function when reversing ..................................147
Mirror position memory .................. 134
Side turn signal lights ........................... 184 Replacing light bulbs ....................... 502
Turn signal lever .................................. 184
Side windows ...........................................149
Slip indicator............................................ 518
Smart access system with push-button start ....................... 122 Antenna location .................................. 122
Entry functions ................................. 111, 117
Starting the engine .............................. 172
SMS (Short message service)......... 367
Snow mode ...............................................178
Snow tires ................................................ 296 Spare tire ................................................. 546
Inflation pressure................................584
Storage location ................................. 547
Spark plug .................................................581
Specifications..........................................574
Speedometer ............................................. 79
Speed indicator.......................................... 81
Steering lock ............................................ 174 Column lock release ......................... 174
Steering wheel ........................................ 142 Adjustment.............................................. 142
Audio switches ...................................306
Heated steering wheel .....................410
Power easy access system ............. 134
Steering wheel position memory .............................. 134
Stop lights Replacing light bulbs .......................502
Storage feature ....................................... 415
Stuck If the vehicle becomes stuck........ 570
Sun visors................................................... 421
Sunshade Rear .......................................................... 423
Roof ............................................................154
