Lexus IS300h 2013 Owner's Manual

1001-3. Theft deterrent system
IS300h_EE(OM53B95E)
Canceling and automatic re-enabling of the intrusion sensor and tilt sensor
The alarm will still be set even when the intrusion sensor and tilt sensor are can-
celed.
After the intrusion sensor and tilt sensor are canceled, pressing the power
switch or unlocking the doors using the entry function or wireless remote con-
trol will re-enable the intrusion sensor and tilt sensor.
The intrusion sensor and tilt sensor will automatically be re-enabled when the
alarm system is deactivated.
Intrusion sensor detection considerations
The sensor may trigger the alarm in the following situations:
Places with extreme vibrations or noises, or situations in which the vehicle is
subject to repeated impacts or vibrations:
• When parked in a parking garage
• When the vehicle is transported on a ferry, trailer, train, etc.
• When ice adhering to the vehicle is removed
• When the vehicle is in an automatic or high-pressure car wash
• When in a hail or lightning storm
A window or the moon roof is open.
In this case, the sensor may detect the fol-
lowing:
• Wind or the movement of objects such
as leaves and insects inside the vehicle
• Ultrasonic waves emitted from devices
such as the intrusion sensors of other
vehicles
• The movement of people outside the
vehicle
Unstable items, such as dangling accesso-
ries or clothes hanging on the coat hooks,
are in the vehicle.

1011-3. Theft deterrent system
1
For safety and security
IS300h_EE(OM53B95E)
Tilt sensor detection considerations (if equipped)
The sensor may trigger the alarm in the following situations:
The vehicle is transported by a ferry, trailer, train, etc.
The vehicle is parked in a parking garage.
The vehicle is inside a car wash that moves the vehicle.
Any of the tires loses air pressure.
The vehicle is jacked up.
An earthquake occurs or the road caves in.
NOTICE
To ensure the intrusion sensor function correctly
Installing accessories other than genuine Lexus parts or leaving objects
between the driver’s seat and front passenger’s seat may reduce the detection
performance.
To ensure that the sensors operate prop-
erly, do not touch or cover them.
Do not spray air fresheners or other prod-
ucts directly into the sensor holes.

1021-3. Theft deterrent system
IS300h_EE(OM53B95E)

103
2Instrument cluster
IS300h_EE(OM53B95E)
2. Instrument cluster
Warning lights and
indicators ........................ 104
Gauges and meters ............ 109
Multi-information display..115
Energy monitor/
consumption screen ........ 121

104
IS300h_EE(OM53B95E)2. Instrument cluster
Except F SPORT models
F SPORT models
The units used on the meters may differ depending on the target region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster and center
panel inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations display all
warning lights and indicators illuminated.

1052. Instrument cluster
2
Instrument cluster
IS300h_EE(OM53B95E)
Warning lights inform the driver of malfunctions in the indicated vehicle
systems.
*1: These lights turn on when the power switch is turned to ON mode to indicate
that a system check is being performed. They will turn off after the hybrid sys-
tem is on, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or turn off. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
*2: The light flashes to indicate a malfunction.
*3: This light illuminates on the center panel.
Warning lights
*1Brake system warning
light
(P. 507)*1Slip indicator
(P. 508)
*1Brake system warning
light (P. 507)*1 Automatic headlight lev-
eling system warning
light (P. 509)
*1Charging system warning
light (P. 507)Open door warning light
(P. 509)
*1Malfunction indicator
lamp (P. 507)Low fuel level warning
light (P. 509)
*1SRS warning light
(P. 508)
Driver’s and front passen-
ger’s seat belt reminder
light
(P. 509)
*1ABS warning light
(P. 508)*3Rear passengers’ seat belt
reminder lights (P. 509)
*1Electric power steering
system warning light
(P. 508)*1Master warning light
(P. 509)
*1, 2
(if
equipped)
Pre-crash safety system
warning light (P. 508)
*1Tire pressure warning
light
(P. 509)

1062. Instrument cluster
IS300h_EE(OM53B95E)
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
(P. 222)

(if
equipped)
Lexus parking assist-sen-
sor indicator (P. 267)
Tail light indicator
(P. 226)
*1, 2 Slip indicator
(P. 287)
Headlight high beam
indicator (P. 226)
*1VSC OFF indicator
(P. 288)
(if
equipped)
Automatic High Beam
indicator (P. 229)
*1, 3
(if
equipped)
Pre-crash safety system
warning light (P. 293)
(if
equipped)
Front fog light indicator
(P. 233)
*4, 5
(if
equipped)
BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators (P.
299)
Rear fog light indicator
(P. 233)
*6Security indicator
(P. 90, 96)
(if
equipped)
Cruise control indicator
(P. 245, 249)*7Low outside temperature
indicator (P. 1 1 0 )
(if
equipped)
Dynamic radar cruise
control indicator (P.
249)“READY” indicator
(P. 209)
(if
equipped)
Cruise control “SET”
indicator (P. 245, 249)EV indicator (P. 81)

1072. Instrument cluster
2
Instrument cluster
IS300h_EE(OM53B95E)
*1: These lights turn on when the power switch is turned to ON mode to indicate
that a system check is being performed. They will turn off after the hybrid sys-
tem is on, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or turn off. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than
usual to indicate that the system is operating.
*4: In order to confirm operation, the BSM outside rear view mirror indicators
illuminate in the following situations:
• When the power switch is turned to ON mode while the BSM main switch
is set to ON.
• When the BSM main switch is set to ON while the power switch is in ON
mode.
If the system is functioning correctly, the BSM outside rear view mirror indi-
cators will turn off after a few seconds.
(if
equipped)
LDA (Lane Departure
Alert) indicator (P.
261)*8EV drive mode indicator
(P. 214)
*9
EV drive mode indicator
(P. 214)
*9
(if
equipped)
“SPORT S” indicator
(P. 283)
*8
Eco drive mode indicator
(P. 283)
*9
(if
equipped)
“SPORT S+” indicator
(P. 283)
*9Eco drive mode indicator
(P. 283)*8Snow mode indicator
(P. 217)
*8“SPORT” indicator
(P. 283)*9Snow mode indicator
(P. 217)
*9
(if
equipped)
“SPORT” indicator
(P. 283)
*1, 6“PASSENGER AIR
BAG” indicator
(P. 54)

1082. Instrument cluster
IS300h_EE(OM53B95E)If the BSM outside rear view mirror indicators do not illuminate or do not turn
off, there may be a malfunction in the system.
If this occurs, have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.

1092. Instrument cluster
2
Instrument cluster
IS300h_EE(OM53B95E)
*5: This light illuminates on the outside rear view mirrors.
*6: This light illuminates on the center panel.
*7: When the outside temperature is approximately 3°C (37°F) or lower, the indi-
cator will flash for approximately 10 seconds, then stay on.
*8: Except F SPORT models
*9: F SPORT models
CAUTION
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not come
on when you start the hybrid system, this could mean that these systems are not
available to help protect you in an accident, which could result in death or seri-
ous injury. Have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional immediately if
this occurs.
