Lexus IS300h 2013 Owner's Manual

129
3
Operation of
each component
IS300h_EE(OM53B95E)
3-1. Key information
Keys .................................. 130
3-2. Opening, closing and
locking the doors and
trunk
Doors ................................ 136
Trunk................................. 143
Smart entry & start system 149
3-3. Adjusting the seats
Front seats ......................... 164
Rear seats .......................... 166
Driving position memory.. 168
Head restraints .................. 173
3-4. Adjusting the steering
wheel and mirrors
Steering wheel .................. 176
Inside rear view mirror ..... 178
Outside rear view mirrors . 180
3-5. Opening, closing the
windows and moon roof
Power windows................. 184
Moon roof ......................... 187

130
IS300h_EE(OM53B95E)3-1. Key information
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart entry & start
system (P. 149)
• Operating the wireless remote
control function
Mechanical keys
Key number plate
Card key (electronic key) (if
equipped)
Operating the smart entry & start
system (P. 149)
Locks the doors (P. 136)
Closes the windows and moon
roof
* (P. 136)
Unlocks the doors (P. 136)
Opens the windows and moon
roof
* (P. 136)
Opens the trunk (P. 144)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
Keys
The keys
1
2
3
4
Wireless remote control
1
2
3
4
5

1313-1. Key information
3
Operation of each component
IS300h_EE(OM53B95E)
To take out the mechanical key,
push the release button and take the
key out.
The mechanical key can only be
inserted in one direction, as the key
only has grooves on one side. If the
key cannot be inserted in a lock cyl-
inder, turn it over and re-attempt to
insert it.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with the
electronic key. If the electronic key
battery is depleted or the entry func-
tion does not operate properly, you
will need the mechanical key. (P.
548)
Using the mechanical key

1323-1. Key information
IS300h_EE(OM53B95E)
Card key (if equipped)
The card key is not waterproof.
The mechanical key that is stored inside the card key should be used only if a
problem arises, such as when the card key does not operate properly.
If it is difficult to take out the mechanical key, push down the lock release but-
ton using a pen tip etc. If it is still difficult to pull it out, use a coin etc.
When required to leave the vehicle’s key with a parking attendant
Set the luggage security system (P. 145) on and lock the glove box (P. 414)
as circumstances demand.
Remove the mechanical key for your own use and provide the attendant with the
electronic key only.
If you lose your mechanical keys
New genuine mechanical keys can be made by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional using the other
mechanical key and the key number stamped on your key number plate. Keep the
plate in a safe place such as your wallet, not in the vehicle.
To store the mechanical key in the card
key, insert it while pressing the lock
release button.
If the battery cover is not installed and the
battery falls out or if the battery was
removed because the key got wet, reinstall
the battery with the positive terminal fac-
ing the Lexus emblem.

1333-1. Key information
3
Operation of each component
IS300h_EE(OM53B95E)
When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any
buttons on the electronic key while inside the aircraft cabin. If you are carrying
an electronic key in your bag etc., ensure that the buttons are not likely to be
pressed accidentally. Pressing a button may cause the electronic key to emit radio
waves that could interfere with the operation of the aircraft.
Electronic key battery depletion
The standard battery life is 1 to 2 years. (The card key battery life is about a
year and a half.)
If the battery becomes low, an alarm will sound in the cabin when the hybrid
system is stopped. (P. 527)
As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery when
necessary. (P. 472)
• The smart entry & start system or the wireless remote control does not oper-
ate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
To avoid serious deterioration, do not leave the electronic key within 1 m (3 ft.)
of the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers
Replacing the battery
P. 472
Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask any
authorized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional for details.
If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.

1343-1. Key information
IS300h_EE(OM53B95E)
NOTICE
To prevent key damage
Do not drop the keys, subject them to strong shocks or bend them.
Do not expose the keys to high temperatures for long periods of time.
Do not get the keys wet or wash them in an ultrasonic washer etc.
Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
Do not disassemble the keys.
Do not attach a sticker or anything else to the surface of the electronic key.
Do not place the keys near objects that produce magnetic fields, such as TVs,
audio systems and induction cookers, or medical electrical equipment, such as
low-frequency therapy equipment.
Carrying the electronic key on your person
Carry the electronic key 10 cm (3.9 in.) or more away from electric appliances
that are turned on. Radio waves emitted from electric appliances within 10 cm
(3.9 in.) of the electronic key may interfere with the key, causing the key to not
function properly.
In case of a smart entry & start system malfunction or other key-related prob-
lems
Take your vehicle with all the electronic keys provided with your vehicle,
including the card key, to any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.

1353-1. Key information
3
Operation of each component
IS300h_EE(OM53B95E)
NOTICE
When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional immediately with all remaining electronic keys and
the card key that were provided with your vehicle.
Handling the card key
Do not apply excess force when inserting the mechanical key into the card
key. Doing so may damage the card key.
If the battery or card key terminals get wet, the battery may corrode.
If the key is dropped into water, or if drinking water etc. is spilled on the key,
immediately remove the battery cover and wipe the battery and terminals. (To
remove the battery cover, lightly grasp and pull it.) If the battery is corroded,
have any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional replace the battery.
Do not crush the battery cover or use a screwdriver to remove the battery
cover. Forcibly removing the battery cover may bend or damage the key.
If the battery cover is frequently removed, the battery cover may become
loose.
When installing the battery, make sure to check the direction of the battery.
Installing the battery in the wrong direction may cause the battery to deplete
rapidly.
The surface of the card key may be damaged, or its coating may peel off in the
following situations:
• The card key is carried together with hard objects, such as coins and keys.
• The card key is scraped with a sharp object, such as the tip of a mechanical
pencil.
• The surface of the card key is wiped with thinner or benzene.

136
IS300h_EE(OM53B95E)3-2. Opening, closing and locking the doors and trunk
The vehicle can be locked and unlocked using the entry function, wireless
remote control or door lock switches.
Entry function (if equipped)
Carry the electronic key to enable this function.
Grip the handle to unlock the
doors.
Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are
locked.
Touch the lock sensor (inden-
tation on the upper part of the
door handle) to lock the doors.
Wireless remote control
Locks all the doors
Press and hold to close the win-
dows and moon roof.
*
Unlocks all the doors
Press and hold to open the win-
dows and moon roof.
*
*
: These settings must be custom-
ized at any authorized Lexus
dealer or repairer, or another duly
qualified and equipped profes-
sional.
Doors
Unlocking and locking the doors from the outside
1
2
1
2

1373-2. Opening, closing and locking the doors and trunk
3
Operation of each component
IS300h_EE(OM53B95E)
Operation signals
The emergency flashers flash to indicate that the doors have been locked/
unlocked. (Locked: once; Unlocked: twice)
A buzzer sounds to indicate that the windows and moon roof are operating.
Security feature
If a door is not opened within approximately 30 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Welcome light illumination control
The front position, tail and license plate lights automatically turn on at night
when the doors are unlocked using the entry function or wireless remote control
if the light switch is in the “AUTO” position.
When the door cannot be locked by the lock sensor on the upper part of the door
handle (vehicles with entry function)
Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer
sounds continuously for 5 seconds. Fully close the door to stop the buzzer, and
lock the vehicle once more.
Setting the alarm (if equipped)
Locking the doors will set the alarm system. (P. 96)
If the smart entry & start system or the wireless remote control does not operate
properly
Use the mechanical key to lock and unlock the doors. (P. 548)
Replace the key battery with a new one if it is depleted. (P. 472) If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor areas
at the same time.

1383-2. Opening, closing and locking the doors and trunk
IS300h_EE(OM53B95E)
CAUTION
When closing the windows or moon roof using wireless remote control
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body in a
position where it could be caught when a window or moon roof is being oper-
ated.
To prevent inadvertent power windows and moon roof operation, never let a
small child have and use the wireless remote control.
Jam protection function
Never try jamming any part of your body to activate the jam protection func-
tion intentionally.
The jam protection function may not work if something gets caught just
before the window or moon roof fully closes.
