Lexus IS300h 2013 Owner's Manual

209
4
Driving
IS300h_EE(OM53B95E)4-2. Driving procedures
Check that the parking brake is set.
Check that the shift lever is in P.
Firmly depress the brake pedal.
and a message will be displayed on the multi-information display.
If it is not displayed, the hybrid system cannot be started.
Press the power switch.
Continue depressing the brake pedal
until the hybrid system is completely
started.
The hybrid system can be started
from any power switch mode.
Check that the “READY” indicator is on.
The vehicle will not move when the “READY” indicator is off.
Power (ignition) switch
Performing the following operations when carrying the electronic key on
your person starts the hybrid system or changes power switch modes.
Starting the hybrid system
1
2
3
4
5

2104-2. Driving procedures
IS300h_EE(OM53B95E)
Stop the vehicle.
Shift the shift lever to P.
Set the parking brake. (P. 224)
Press the power switch.
Release the brake pedal and check that the display on the meters is off.
Modes can be changed by pressing the power switch with brake pedal
released. (The mode changes each time the switch is pressed.)
Off*
The emergency flashers can be used.
The multi-information display will
not be displayed.
ACCESSORY mode
Some electrical components such as
the audio system can be used.
“ACCESSORY” will be displayed
on the meters.
ON mode
All electrical components can be
used.
“IGNITION ON” will be displayed
on the meters.
*: If the shift lever is in a position other
than P when turning off the hybrid
system, the power switch will be
turned to ACCESSORY mode, not
to off.
Stopping the hybrid system
Changing power switch modes
1
2
3
4
5
1
2
3

2114-2. Driving procedures
4
Driving
IS300h_EE(OM53B95E)
If the hybrid system is stopped with the shift lever in a position other than
P, the power switch will not be turned off but instead be turned to
ACCESSORY mode. Perform the following procedure to turn the switch
off:
Check that the parking brake is set.
Shift the shift lever to P.
Check that “Turn Power OFF” is displayed on the multi-information
display and then press the power switch once.
Check that “Turn Power OFF” on the multi-information display is off.
Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes or ON
mode (the hybrid system is not operating) for more than an hour with the shift
lever in P, the power switch will automatically turn off. However, this function
cannot entirely prevent 12-volt battery discharge. Do not leave the vehicle with
the power switch in ACCESSORY or ON mode for long periods of time when
the hybrid system is not operating.
Sounds and vibrations specific to a hybrid vehicle
P. 8 2
Electronic key battery depletion
P. 133
When the ambient temperature is low, such as during winter driving conditions
It may take time before the “READY” indicator comes on.
Conditions affecting operation
P. 151
Notes for the entry function
P. 152
If the hybrid system does not start
Check that the shift lever is securely set in P. The hybrid system may not start if
the shift lever is displaced out of P.
The immobilizer system may not have been deactivated. (P. 90)
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
When stopping the hybrid system with the shift lever in a position
other than P
1
2
3
4

2124-2. Driving procedures
IS300h_EE(OM53B95E)
Steering lock
After turning the power switch off and opening and closing the doors, the steer-
ing wheel will be locked due to the steering lock function. Operating the power
switch again automatically cancels the steering lock.
When the steering lock cannot be released
Steering lock motor overheating prevention
To prevent the steering lock motor from overheating, operation of the motor may
be suspended if the hybrid system is turned on and off repeatedly in a short
period of time. In this case, refrain from operating the hybrid system. After about
10 seconds, the steering lock motor will resume functioning.
When “Check Entry & Start System” is displayed on the multi-information dis-
play
The system may be malfunctioning. Have the vehicle inspected by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped profes-
sional immediately.
If the “READY” indicator does not come on
If the “READY” indicator does not come on when you press the power switch
with the shift lever in P and the brake pedal depressed, contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional
immediately.
If the hybrid system is malfunctioning
P. 516
If the electronic key battery is depleted
P. 545
Operation of the power switch
When operating the power switch, one short, firm press is enough. If the switch
is pressed improperly, the hybrid system may not start or the power switch
mode may not change. It is not necessary to press and hold the switch.
If attempting to restart the hybrid system immediately after turning the power
switch off, the hybrid system may not start in some cases. After turning the
power switch off, please wait a few seconds before restarting the hybrid system.
If the smart entry & start system has been deactivated by a customized setting
P. 548 “Steering Lock active” will be displayed on
the multi-information display.
Check that the shift lever is in P. Press the
power switch while turning the steering
wheel left and right.

2134-2. Driving procedures
4
Driving
IS300h_EE(OM53B95E)
CAUTION
When starting the hybrid system
Always start the hybrid system while sitting in the driver’s seat. Do not depress
the accelerator pedal while starting the hybrid system under any circumstances.
Doing so may cause an accident resulting in death or serious injury.
Caution while driving
If hybrid system failure occurs while the vehicle is moving, do not lock or open
the doors until the vehicle reaches a safe and complete stop. Activation of the
steering lock in this circumstance may lead to an accident, resulting in death or
serious injury.
Stopping the hybrid system in an emergency
If you want to stop the hybrid system in an emergency while driving the vehi-
cle, press and hold the power switch for more than 2 seconds, or press it briefly
3 times or more in succession. (P. 499)
However, do not touch the power switch while driving except in an emergency.
Turning the hybrid system off while driving will not cause loss of steering or
braking control, but the power assist to these systems will be lost. This will
make it more difficult to steer and brake, so you should pull over and stop the
vehicle as soon as it is safe to do so.
NOTICE
To prevent 12-volt battery discharge
Do not leave the power switch in ACCESSORY or ON mode for long periods
of time without the hybrid system on.
If “ACCESSORY” or “IGNITION ON” is displayed on the meters while the
hybrid system is not operating, the power switch is not off. Exit the vehicle
after turning the power switch off.
Do not stop the hybrid system when the shift lever is in a position other than
P. If the hybrid system is stopped in another shift lever position, the power
switch will not be turned off but instead be turned to ACCESSORY mode. If
the vehicle is left in ACCESSORY mode, 12-volt battery discharge may
occur.
When starting the hybrid system
Do not depress the accelerator pedal unnecessarily.
If the hybrid system becomes difficult to start, have your vehicle checked by
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional immediately.
Symptoms indicating a malfunction with the power switch
If the power switch seems to be operating somewhat differently than usual,
such as the switch sticking slightly, there may be a malfunction. Contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional immediately.

2144-2. Driving procedures
IS300h_EE(OM53B95E)
Turns EV drive mode on/off
When EV drive mode is turned on,
“EV MODE” will be displayed on
the multi-information display. Press-
ing the switch when in EV drive
mode will return the vehicle to nor-
mal driving (using the gasoline
engine and electric motor [traction
motor]).
Situations in which EV drive mode cannot be turned on
It may not be possible to turn EV drive mode on in the following situations. If it
cannot be turned on, a buzzer will sound and a message will be shown on the
multi-information display.
The temperature of the hybrid system is high.
The vehicle has been left in the sun, driven on a hill, driven at high speeds, etc.
The temperature of the hybrid system is low.
The vehicle has been left in temperatures lower than about 0C (32F) for a
long period of time etc.
The gasoline engine is warming up.
The hybrid battery (traction battery) is low.
The remaining battery level indicated in the “Energy monitor” display is low.
(P. 123)
Vehicle speed is about 45 km/h (28 mph) or more.
The accelerator pedal is depressed firmly or the vehicle is on a hill, etc.
The windshield defogger is in use.
EV drive mode
In EV drive mode the electric motor (traction motor), powered by the
hybrid battery (traction battery), is used to drive the vehicle.
This mode allows you to drive in residential areas early in the morning
and late at night, or in indoor parking lots etc. without concern for noises
and gas emissions.

2154-2. Driving procedures
4
Driving
IS300h_EE(OM53B95E)
Switching to EV drive mode when the gasoline engine is cold
If the hybrid system is started while the gasoline engine is cold, the gasoline
engine will start automatically after a short period of time in order to warm up. In
this case, you will become unable to switch to EV drive mode.
After the hybrid system has started and the “READY” indicator has illuminated,
press the EV drive mode switch before the gasoline engine starts to switch to EV
drive mode.
Automatic cancelation of EV drive mode
When driving in EV drive mode, the gasoline engine may automatically restart in
the following situations. When EV drive mode is canceled, a buzzer will sound
and the EV drive mode indicator will flash and go off.
The hybrid battery (traction battery) becomes low.
The remaining battery level indicated in the “Energy monitor” display is low.
(P. 123)
Vehicle speed becomes more than about 45 km/h (28 mph).
The accelerator pedal is depressed firmly or the vehicle is on a hill, etc.
When it is possible to inform the driver of automatic cancelation in advance, a
prior notice screen will appear on the multi-information display.
Possible driving distance when driving in EV drive mode
EV drive mode’s possible driving distance ranges from a few hundred meters to
approximately 2 km (1.2 mile). Driving is possible at speeds of less than approx-
imately 45 km/h (28 mph). However, depending on vehicle conditions, there are
situations when EV drive mode cannot be used.
(The distance that is possible depends on the hybrid battery [traction battery]
level and driving conditions.)
Fuel economy
Your Lexus is designed to achieve the best possible fuel economy during normal
driving (using the gasoline engine and electric motor [traction motor]). Driving
in EV drive mode more than necessary may lower fuel economy.
CAUTION
Caution while driving
When driving in EV drive mode, pay special attention to the area around the
vehicle. Because there is no engine noise, pedestrians, people riding bicycles or
other people and vehicles in the area may not be aware of the vehicle starting
off or approaching them, so take extra care while driving.

2164-2. Driving procedures
IS300h_EE(OM53B95E)
While the power switch is in ON mode, move the shift lever with the
brake pedal depressed.
When shifting the shift lever between P and D, make sure that the vehicle is
completely stopped.
Hybrid transmission
Shifting the shift lever

2174-2. Driving procedures
4
Driving
IS300h_EE(OM53B95E)
*1: To improve fuel efficiency and reduce noise, shift the shift lever to D for nor-
mal driving.
*2: By selecting shift ranges using S mode, you can control accelerating force and
engine braking force.
Sport mode/Eco drive mode
P. 2 8 3
Snow mode
Snow mode can be selected to suit the conditions when driving on slip-
pery road surfaces, such as snow.
Press the switch.
Press the switch again to return to
normal mode.
Shift position purpose
Shift positionObjective or function
PParking the vehicle/starting the hybrid system
RReversing
NNeutral
DNormal driving*1
SS mode driving*2 (P. 219)
Selecting the driving mode

2184-2. Driving procedures
IS300h_EE(OM53B95E)
To drive using temporary shift range selection, operate the “-” paddle
shift switch. Changing the shift range enables the level of engine braking
force to be selected. The shift range can then be selected by operating the
“-” and “+” paddle shift switches.
Upshifting
Downshifting
The selected shift range, from D1 to
D6, will be displayed in the meter.
The initial shift range when the “-”
paddle shift switch is operated is
automatically set to D2, D3, D4 or
D5 according to the vehicle speed.
To return to normal D position driv-
ing, the “+” paddle shift switch must
be held down for a period of time.
Shift ranges and their functions
You can choose from 6 levels of engine braking force.
A lower shift range will provide greater engine braking force than a
higher shift range, and the engine revolutions will also increase.
Selecting shift ranges in the D position
1
2
