Lexus IS300h 2013 Owner's Manual

1793-4. Adjusting the steering wheel and mirrors
3
Operation of each component
IS300h_EE(OM53B95E)
Auto anti-glare inside rear view mirror
Responding to the level of brightness of the headlights of vehicles behind,
the reflected light is automatically reduced.
Changing automatic anti-glare
function mode
ON/OFF
When the automatic anti-glare func-
tion is in ON mode, the indicator
illuminates.
The function will set to ON mode
each time the power switch is turned
to ON mode.
Pressing the button turns the func-
tion to OFF mode. (The indicator
also turns off.)
To prevent sensor error (vehicles with auto anti-glare inside rear view mirror)
Indicator
To ensure that the sensors operate properly,
do not touch or cover them.
CAUTION
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident, result-
ing in death or serious injury.

1803-4. Adjusting the steering wheel and mirrors
IS300h_EE(OM53B95E)
To select a mirror to adjust, press
the switch.
Left
Right
Pressing the same switch again
will put the switch in neutral.
To adjust the mirror, press the
switch.
Up
Right
Down
Left
Outside rear view mirrors
Adjustment procedure
1
1
2
2
1
2
3
4

1813-4. Adjusting the steering wheel and mirrors
3
Operation of each component
IS300h_EE(OM53B95E)
Using the switch
Press the switch to fold the mir-
rors.
Press it again to extend them to
the original position.
Setting automatic mode (if equipped)
Automatic mode allows the folding or extending of the mirrors to be
linked to locking/unlocking of the doors.
Press the “AUTO” switch to set
automatic mode.
The indicator will come on.
Pressing the switch once more
will return to manual mode.
Automatically folding and extending the mirrors
Indicator

1823-4. Adjusting the steering wheel and mirrors
IS300h_EE(OM53B95E)
Mirror angle can be adjusted when
The power switch is in ACCESSORY or ON mode.
Linked mirror function when reversing (if equipped)
When either “L” or “R” of the mirror select switch is selected, the outside rear
view mirrors will automatically angle downwards when the vehicle is reversing
in order to give a better view of the ground. To disable this function, select nei-
ther “L” nor “R”.
If the mirror angle adjustment switch is operated while the linked mirror func-
tion is in operation, the angle and position of the mirrors can be remembered,
and the mirrors will operate at the angle adjusted to the last time the linked mir-
ror function was operated.
However, because the mirrors move based on the angle they are in when the
linked mirror function is not operating, the mirror angle when the linked mirror
function is operating will also be changed if the mirrors are adjusted while the
function is not operating.
When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on
the rear window defogger to turn on the outside rear view mirror defoggers. (P.
404)
Automatic adjustment of the mirror angle (if equipped)
A desired mirror face angle can be entered to memory and recalled automatically
by the driving position memory. (P. 168)
Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the outside
rear view mirrors will activate in conjunction with the anti-glare inside rear view
mirror to reduce reflected light. (P. 179)
Using automatic mode in cold weather
When automatic mode is used in cold weather, the door mirror could freeze up
and automatic stowing and return may not be possible. In this case, remove any
ice and snow from the door mirror, then either operate the mirror using manual
mode or move the mirror by hand.
Customization
The automatic mirror folding and extending operation can be changed.
(Customizable features: P. 575)

1833-4. Adjusting the steering wheel and mirrors
3
Operation of each component
IS300h_EE(OM53B95E)
CAUTION
Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an acci-
dent, resulting in death or serious injury.
Do not adjust the mirrors while driving.
Do not drive with the mirrors folded.
Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot and
burn you.

184
IS300h_EE(OM53B95E)3-5. Opening, closing the windows and moon roof
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: To stop the window partway, operate
the switch in the opposite direction.
Press the switch to lock the passen-
ger window switches.
The indicator will come on.
Use this switch to prevent children
from accidentally opening or closing
a passenger window.
Power windows
Opening and closing procedures
1
2
3
4
Window lock switch
Indicator

1853-5. Opening, closing the windows and moon roof
3
Operation of each component
IS300h_EE(OM53B95E)
The power windows can be operated when
The power switch is in ON mode.
Operating the power windows after turning the hybrid system off
The power windows can be operated for approximately 45 seconds after the
power switch is turned to ACCESSORY mode or turned off. They cannot, how-
ever, be operated once either front door is opened.
Jam protection function
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.
When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on the
relevant door.
After stopping the vehicle, the window can be closed by holding the power
window switch in the one-touch closing position while the power switch is
turned to ON mode.
If the window still cannot be closed even by carrying out the operation as
explained above, initialize the function by performing the following procedure.
Hold the power window switch in the one-touch closing position. Continue
holding the switch for a further 6 seconds after the window has closed.
Hold the power window switch in the one-touch opening position. Continue
holding the switch for a further 2 seconds after the window has opened com-
pletely.
Hold the power window switch in the one-touch closing position once again.
Continue holding the switch for a further 2 seconds after the window has
closed.
If you release the switch while the window is moving, start again from the begin-
ning.
If the window continues to close but then re-open slightly even after performing
the above procedure correctly, have the vehicle inspected by any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
1
2
3

1863-5. Opening, closing the windows and moon roof
IS300h_EE(OM53B95E)
Door lock linked window operation
The power windows can be opened and closed using the mechanical key.*
(P. 548)
The power windows can be opened and closed using the wireless remote con-
trol.* (P. 136)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
When the 12-volt battery is disconnected
The window lock switch is disabled. If necessary, press the window lock switch
after reconnecting the 12-volt battery.
Power windows open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the power switch is turned off and the driver’s door
is opened with the power windows open.
Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features: P. 575)
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
Closing the windows
Check to make sure that all passengers do not have any part of their body in a
position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in some
instances, even death.
Jam protection function
Never use any part of your body to intentionally activate the jam protection
function.
The jam protection function may not work if something gets caught just
before the window fully closes.

1873-5. Opening, closing the windows and moon roof
3
Operation of each component
IS300h_EE(OM53B95E)
Opens the moon roof*
The moon roof stops slightly before
the fully open position to reduce
wind noise.
Press the switch again to fully open
the moon roof.
Closes the moon roof*
*
: Lightly press either way of the moon
roof switch to stop the moon roof
partway.
Tilts the moon roof up*
Tilts the moon roof down*
*
: Lightly press either way of the moon
roof switch to stop the moon roof
partway.
Moon roof

: If equipped
Use the overhead switches to open and close the moon roof and tilt it up
and down.
Opening and closing
1
2
Tilting up and down
1
2

1883-5. Opening, closing the windows and moon roof
IS300h_EE(OM53B95E)
The moon roof can be operated when
The power switch is in ON mode.
Operating the moon roof after turning the hybrid system off
The moon roof can be operated for approximately 45 seconds after the power
switch is turned to ACCESSORY mode or turned off. It cannot, however, be
operated once either front door is opened.
Jam protection function
If an object is detected between the moon roof and the frame while the moon roof
is closing or tilting down, travel is stopped and the moon roof opens slightly.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade will
open automatically when the moon roof is opened.
Door lock linked moon roof operation
The moon roof can be opened and closed using the mechanical key.* (P. 548)
The moon roof can be opened and closed using the wireless remote control.*
(P. 136)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
